☆ The door station provides a quick order "**43" if the room number
encoding method conforms to the rules of table 3.Use order "**40" to
eliminate the comparative table of the module address and the room
number".
☆ The manipulating setting of the extension phone number: press **15
and come up with Y011 after completes steps 1, 2, 3 (Y stands for the
address, the 2
is the room number).Entering three numerals if you want to revise the
address, and press the key "*" if you don't want to. It'll show four
numerals after finishing the above steps.Please enter four numerals to
revise (namely room number), press "*" if do not revise (namely
examination), and then it will demonstrate the next encoding address. If
the four figures have been in table (namely repetition), and it'll show
the repetitious number address. Then please enter 0000,that mean you
don't use this address.
☆ The module(see the picture in the right corner),
the address of module ranges from 0101 to 9904.
Namely the coding sites are
floors are 01 to 99), room number are 01 to 04.
The first 8,421 is decimal and the latter 8,421 is
the single. There are eight pairs of two sides
contact pin.
nd rd
and 3 figure stand for the coding site, and the 4
www.cusamintercom.com
01 to 99 (namely
8
th
figure
