Rear Panel Functions

1. A/C Input - Connects the amplifier to A/C power via the power cord supplied. Unless
otherwise specified, your amplifier is designed to operate on 120 volts A/C, 60 cycles.
2. Fuse- 3 AG Type, 250 Volt, SLO-BLO
3. Power Switch- Turns power on.
4. Speaker Output Jacks- There are 2 speaker output jacks. Nominal impedance is 4-8 ohms.
NEVER OPERATE YOUR AMPLIFIER WITHOUT A PROPER SPEAKER LOAD CONNECTED.
Be sure to match the impedance of your cabinet with the impedance (output) of the amplifier.
5. Effects Send- Use this jack to send the amplifiers signal to outboard effects.
6. Effects Return- Use this jack to connect the output of your effects to the amplifier.
7. Footswitch Jack- The footswitch connects here. The clean/lead and tone bypass functions
can only be activated via the footswitch.
NOTE: All switches are ON in the "up" position

Fuse Chart

All Fuses are 3AG Type 250 Volt, SLO-BLO
Export 100 Volt/Domestic Export 220, 230, 240 Fuses:
2A- Jet and Jet Signature 1A- Jet and Jet Signature
FOOT SWITCH
