NEW Panaray
MA12EX Modular Line Array Loudspeaker
®
The newest addition to the Panaray MA12 loudspeaker family, the Panaray MA12EX modular line array loudspeaker is designed to deliver high
speech intelligibility and full-range music from 75 Hz to 13 kHz (-3 dB), without additional bass augmentation, in both indoor and outdoor
acoustically demanding spaces. Twelve 2.25" (57mm) high-excursion, weather-resistant drivers mounted in an Articulated Array
design deliver 160º of horizontal dispersion and narrow vertical pattern control. The Panaray MA12EX loudspeaker delivers full-range performance
1
at 150 watts, and speech-only performance at 300 watts. The loudspeaker can be mounted in single or multiple loudspeaker configurations. It is
well-suited for indoor and outdoor applications such as houses of worship, multipurpose spaces, recreation, retail, restaurants, auditoriums,
transportation hubs, gymnasiums, atriums and malls.
Modular Line Array Loudspeaker
Panaray MA12
®
The Panaray MA12 modular line array loudspeaker is designed for acoustically demanding indoor spaces where speech intelligibility is critical and
speech reproduction is the main requirement. To deliver full-range music performance, bass augmentation is required. Twelve 2.25" (57mm)
mid/high-frequency drivers mounted in a vertical line array deliver 145º of horizontal dispersion and narrow vertical pattern control. The MA12
loudspeaker delivers 300 watts of power handling and can be mounted in single or multiple loudspeaker configurations. This loudspeaker is
well-suited for indoor applications such as houses of worship, auditoriums, transportation hubs, atriums, malls, gymnasiums and multipurpose spaces.
PRODUCT FEATURES
Indoor Applications
Outdoor Applications
Articulated Array ® Loudspeaker Design
Speech-Only Applications
Speech and Full-Range Music Applications
SYSTEM PERFORMANCE (Single Module)
Frequency Response (-3 dB)
2
Frequency Range (-10 dB)
2
Calculated Maximum SPL @ 1m 3
Input Power Rating (continuous/peak)
Axial Sensitivity (SPL/1W @ 1m)
5
Nominal Horizontal Coverage (-6 dB)
Nominal Vertical Coverage (-6 dB)
6
Nominal Impedance (transformer bypass)
Minimum Impedance
Crossover Frequency
Recommended High-Pass Filter
TRANSDUCERS
Driver Complement
PHYSICAL
Enclosure Material
Grille
Connectors
Suspension Attachment
Dimensions (H x W x D)
Net Weight
Shipping Weight
Color
1
4
MA12
•
•
(with added bass augmentation)
155 Hz – 12 kHz
100 Hz – 16 kHz
113 dB
300W/1200W
88 dB
145°
20°
8g
6.2g
N/A
125 Hz
Twelve 2.25" (57mm) mid/high-frequency drivers
Powder-coated aluminum
Powder-coated steel
Two parallel wired Neutrik Speakon NL4 connectors
®
One two-conductor barrier strip
4 x M6 threaded inserts
38.8" x 4.2" x 5.1"
(986mm x 107mm x 130mm)
18.7lbs
20.8lbs
Available in black or white, paintable
Family Comparison Guide
loudspeaker
®
MA12EX
•
•
•
•
•
75 Hz – 13 kHz
58 Hz – 16 kHz
109 dB
150W/600W
7
87 dB
160°
20°
8g
7.1g
N/A
65 Hz
Twelve 2.25" (57mm) high-excursion, weather-resistant drivers
Powder-coated aluminum
Powder-coated aluminum
Two parallel wired Neutrik Speakon
®
Two two-conductor barrier strips
6 x M6 threaded inserts
38.8" x 4.1" x 5.5"
(986mm x 104mm x 140mm)
20.8lbs
22.9lbs
Available in black or white, paintable
NL4 connectors
