A.J.Antunes Roundup VS-200A-A1 Owner's Manual

Roundup variety steamer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MaNufactuRiNg
NuMbERs:
91 0 0 2 00
91 0 0 2 50
Variety Steamer
Model VS-200A-A1
C
US
C
US
CM
P/N 1010591 Rev. E 03/12
Owner
s manual
'

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Roundup VS-200A-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for A.J.Antunes Roundup VS-200A-A1

Summary of Contents for A.J.Antunes Roundup VS-200A-A1

  • Page 1 MaNufactuRiNg NuMbERs: 91 0 0 2 00 91 0 0 2 50 Variety Steamer Model VS-200A-A1 P/N 1010591 Rev. E 03/12 Owner s manual ’...

  • Page 2: Table Of Contents

    VAriety SteAMer (VS-250) table Of cOntents Owner Information .............2 Operation ..............9 general ..............2 Operating instructions ..........9 Warranty information ..........2 maintenance ..............13 service/technical assistance ........3 Daily Cleaning ............13 Important safety Information ........4 Monthly cleaning .............13 specifications .............6 cleaning steam chamber ........15 Electrical Ratings ............6 troubleshooting ............11 Electrical cord &...

  • Page 3: Owner Information

    VAriety SteAMer (VS-250) Owner InfOrmatIOn (continued) service/technical assistance Refer to the service agency directory and fill in the information below: if you experience any problems with the installation or operation of your unit, contact your local Roundup authorized service agency authorized service agency.

  • Page 4: Important Safety Information

    VAriety SteAMer (VS-250) ImpOrtant safety InfOrmatIOn in addition to the warnings and cautions in this manual, the following warnings and cautions appear use the following guidelines for safe operation of the throughout this manual and should be carefully observed. unit. • Read all instructions before using equipment.
  • Page 5 VAriety SteAMer (VS-250) ImpOrtant safety InfOrmatIOn (continued) • warnInG electrIcal sHOcK HazarD. • To ensure proper steaming characteristics, faIlure tO fOllOw tHese InstructIOns some calcium/mineral deposits must be pres- cOulD result In serIOus InJury Or ent on the Generator surface. If, during clean- DeatH. ing, the surface does become free of deposits, add plain tap water to the surface and allow it - electrical ground is required on this unit.

  • Page 6: Specifications

    HazarD. model & Voltage watts amps Hertz faIlure tO fOllOw tHe InstructIOns In mfg. no. tHIs manual cOulD result In serIOus Vs-200a-a1 InJury Or DeatH. 208-240 3800 18.3 50/60 9100200 • Electrical ground is required on this appliance. Vs-200a-a1 208-240 3800 18.3...

  • Page 7: Installation

    VAriety SteAMer (VS-250) InstallatIOn unpacking needle plate 1. Remove unit and all packing materials from shipping carton. O-ring 2. the unit should contain the following: • Owner’s Manual Diffuser • Authorized Service Agency Directory • Petro Gel Tube • Inlet Hose and Strainer Assembly • Black Drain Tubing nOte: If any parts are missing or damaged, contact antunes technical service ImmeDIately at 1-877-392-7854 or 630-784-1000.

  • Page 8: Operation

    VAriety SteAMer (VS-250) OperatIOn Operating Instructions 1. turn the power on and allow the unit to warmup for approximately 20 minutes. nOte: Do nOt operate the unit during the warmup period. this could cause flooding in the unit. 2. Press the MOMENtaRY switch (figure 2) on the power switch front panel to clear the water line of any air.

  • Page 9: Maintenance

    VAriety SteAMer (VS-250) maIntenance Daily cleaning warnInG refer to the instructions for cleaning and handling nOte: frequency of cleaning is determined by the unit within the Important safety Information water conditions, usage, and water filter systems. section of this manual. 1.

  • Page 10: Monthly Cleaning

    VAriety SteAMer (VS-250) maIntenance (continued) monthly cleaning cleaning steam chamber nOte: frequency of cleaning is determined by 1. turn the power off, unplug the power cord, and water conditions, usage, and water filter systems. allow the unit to cool for approximately 30 minutes.

  • Page 11: Troubleshooting

    VAriety SteAMer (VS-250) trOublesHOOtInG warnInG To avoid possible personal injury and/or damage to the unit, inspection, test, and repair of electrical equip- ment should be performed by qualified service personnel. the unit should be unplugged when servicing, except when electrical tests are required. problem possible cause corrective action unit does not operate. Power cord not correctly plugged in. Plug in the power cord correctly.

  • Page 12: Wiring Diagram

    VAriety SteAMer (VS-250) wIrInG DIaGram WIRING DIAGRAM NOTE: ALL WIRES TO BE 18 GA. AWM-105°C UNLESS OTHERWISE SPECIFIED 14 GA. TFE-200°C GENERATOR HIGH LIMIT SOLENOID POT. SOLID STATE TIMER MOMENTARY THERMOSTAT SWITCH P/N 1010591 Rev. E 03/12 A.J. Antunes & Co.

  • Page 13: Replacement Parts

    VAriety SteAMer (VS-250) replacement parts P/N 1010591 Rev. E 03/12 A.J. Antunes & Co.
  • Page 14 VAriety SteAMer (VS-250) replacement parts (continued) Item part Description Qty. Item part Description Qty. 0010452 Needle Plate assy. 28 4030189 Hi-Limit Thermostat (Mfg. No. 9100200 only) 0200121 O-ring 7000344 Hi-Limit Thermostat 7000388 generator, 3800W (240V) (Mfg. No. 9100250 only) 040K103 Insulation Kit 0501140 bulkhead 0501139 generator Retainer...

  • Page 15: Notes

    VAriety SteAMer (VS-250) nOtes P/N 1010591 Rev. E 03/12 A.J. Antunes & Co.

  • Page 16: Limited Warranty

    lImIteD warranty Equipment manufactured by Roundup Food Equipment Division of A.J. Antunes & Co. has been con- structed of the finest materials available and manufactured to high quality standards. these units are warranted to be free from electrical and mechanical defects for a period of one (1) year from date of purchase under normal use and service, and when installed in accordance with manufacturer’s recom- mendations.
