TM
Automatic Sprinkler System Controller
TM
User's Guide
KwikDial Features:
• Three Independent Watering Programs
• Watering Schedule by 7-Day Calendar,
Day Interval or Odd/Even Days
TM
• Three Start Times Per Program
• Multi-language Display Option
Outdoor Model
• 24-hour Memory Back-up Without Battery
• Automatic Valve Testing Mode
• Rain Delay Mode
• Remote Control Ready
• Rain Sensor Ready
Indoor Model
Advertisement
Table of Contents
Related Manuals for Irritrol KwikDial
Summary of Contents for Irritrol KwikDial
- Page 1 Automatic Sprinkler System Controller User’s Guide KwikDial Features: • Three Independent Watering Programs • Watering Schedule by 7-Day Calendar, Day Interval or Odd/Even Days • Three Start Times Per Program • Multi-language Display Option Outdoor Model • 24-hour Memory Back-up Without Battery •...
-
Page 2: Specifications
Specifications Dimensions - Indoor Models Maximum Load Per Station: 6" W x 9" H x 3" D 0.4 Amps @ 24 V a.c. (15.3 cm W x 22.9 cm H x 7.6 cm D) Maximum Load For Pump/Master Valve: Dimensions - Outdoor Models 0.4 Amps @ 24 V a.c. -
Page 3: Table Of Contents
• Test Mode ............15 • Connecting the Power Source...... 6–7 • Rain Delay Mode..........15 Programming ...........8–13 • Turning Off the KwikDial ......... 15 • Setting the Date/Time........8 Special Functions..........16–18 • Planning Your Watering Schedule....8 • Water Budget ..........16 •... -
Page 4: Kwikdial Components
5B- Power Connection Wires (outdoor domestic and KwikDial Components Australian models only) 5C- Power Connection Terminals (outdoor international 1 - LCD Display models only). 2 - Control Dial - Select controller programming and Buttons - Press to increase or decrease operating functions. - Page 5 (International Models) See Troubleshooting. Note: Power connection access cover removed for illustration.
-
Page 6: Controller Installation
Figure 1 Controller Installation Installing the Cabinet 1. For safe, reliable operation, select an installation site which can ideally provide the following conditions: • For Indoor model controllers – Inside a garage or other structure which will provide protection from the weather. -
Page 7: Connecting The Valves
Connecting a Pump Start Relay Figure 2 CAUTION: To prevent controller damage, ensure the pump start relay current draw does not exceed 0.4 amps. Do not connect the pump motor starter directly to the controller. 1. Connect a wire pair to the 24 V a.c. pump start relay. Route the wires into the controller housing with the valve wires. -
Page 8: Rain Switch Sensor Installation
Rain Sensor Installation (optional) Connecting the Power Source A rain sensor can be connected directly to the KwikDial Indoor Models to automatically interrupt watering when it begins to rain. 1. Route 6" (15 cm) of the transformer wire cable into... -
Page 9: Connecting The Power Source
Connecting the Power Source (continued) Figure 6 Outdoor Models WARNING AC power wiring must be installed and connected by qualified personnel only. All electrical components and installation procedures must comply with all applicable local and national electrical codes. Some codes may require a means Figure 7 of disconnection from the AC power source installed in the fixed wiring and having a contact... -
Page 10: Programming
5. Repeat steps 3–4 to adjust the remaining fields of the start times per watering day. Date/Time display. Important: The KwikDial can run only one program 6. Return the control dial to the Auto position when watering cycle at a time. Therefore, when setting more finished. - Page 11 (Example) Program A Program B Program C Calendar Days Tue & Fri Watering Day Schedule 2-day 3-day Day Interval Even Even Even Odd/Even Run Time Run Time Run Time Station Location Parkway Lawn 10 min Front Lawn 10 min Front Shrubs 5 min Back Lawn 25 min...
- Page 12 Program A Program B Program C Calendar Days Watering Day Schedule Day Interval Even Even Even Odd/Even Run Time Run Time Run Time Station Location Program Start Times...
-
Page 13: About The Kwikdial Memory
Just set the current time 1. Turn control dial to the Odd/Even position. and date and the KwikDial is ready to control your 2. Press the button as needed to select the desired sprinkler system automatically. -
Page 14: Setting A Day Interval Schedule
For example, watering will occur tomorrow (the last day of the interval). when watering a new lawn. The KwikDial provides three independent start times per day for each program. Refer 1. Turn the control dial to the Interval position. -
Page 15: Setting Station Run Time Duration
Setting Station Run Time Duration Controller Operation The station run time duration is the amount of time a The KwikDial controller has five modes of operation: station will operate once it has been started. A station is Automatic, Manual Station(s), Manual Programs, Test assigned to a program when it is given a designated run and Off. -
Page 16: True Manual Operation
6. After all desired stations for timed manual operation True Manual Operation have been selected, turn control dial to the Auto True manual operation allows a single station to be position. selected and run without regard to run time duration. Once •... -
Page 17: Test Mode
1–3 to display OFF. 2. Press the button to change the run time Turning Off the KwikDial from 1 to 9 minutes if desired. Note: The run time used in the test program is When the control dial is turned to the Off... -
Page 18: Special Functions
As a reminder of Water Budget setting (other than 100%), Special Functions the % symbol will be displayed with the current time. See “Important” on page 8 for additional information. The Special Functions dial position provides access to various control features and optional display formats. Station Run Time Duration Format Option The special functions are: Water Budget, Station Run The station run time duration can be displayed in either... -
Page 19: Clock Time Format Option
Clock Time Format Option Enable / Disable Expansion Port Time of day can be displayed in either 12-hour AM/PM Your KwikDial controller is capable of remote control or 24-hour format. operation when used in conjunction with the KwikStart remote system. The expansion port provided for the 1. -
Page 20: Troubleshooting
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Europe - (39) 0765 40191 International: This is a CISPR 22 Class B product. Australia - 1300 130 898 © 2005 Irritrol Form Number 373-0239 Rev. C...
Need help?
Do you have a question about the KwikDial and is the answer not in the manual?
Questions and answers
why is the controller flashing message" sensor"
The Irritrol KwikDial controller flashes the message "SEN" (sensor) when the connected rain sensor has absorbed rainwater and signals the controller to suspend all watering operations. This display continues until the sensor dries out and resets the controller for automatic operation.
This answer is automatically generated
After going through 3 stages on automatic setting my KwikDial starts the cycle all over again. How do I stop the second phase?
To stop the second phase of the Irritrol KwikDial automatic cycle, turn the control dial to the Off position. The display will show OFF and flash for three seconds. Once the flashing stops, any watering operation currently in progress will be turned off, and programmed automatic operation will stop.
This answer is automatically generated
I didn't schedule program C but it still comes on. How can I delete a program
Int displays and I cannot remove
sensor went off and light returned to green. thanks anyway
