Irritrol KwikDial Series Quick Reference Card

Quick Reference Card

To Change Time and/or Date:

1.Turn the control dial to Date/Time
2.Press the or button to adjust the hour.
3.Press the button to advance to the next field.
4.Repeat 2 and 3 to set current minutes, month, day and year.

To Set a Calendar Day Watering Schedule:

1.Turn the control dial to Water Days
2. Press the button to select the desired program.
3.Press the or button to select
4.Repeat 1–3 for the remaining days.

To Set an Odd or Even Day Watering Schedule:

1.Turn the control dial to Odd / Even
2. Press the button to select the desired program.
3.Press the or button to select Odd, Even.
Note: Select - - - (dashes) to remove an Odd or Even schedule.

To Set a Day Interval Watering Schedule:

1.Turn the control dial to Interval
2.Press the button to select the desired program.
3. Press the or button to select the desired Day Interval 01– 31).
Note: Select - - - (dashes) to remove a Day Interval.
4. Press the button to advance to the TODAY
5. Press the or button to set the current day of the interval.

To Set Program Start Times:

1.Turn the control dial to Start Times
2.Press the button to select the desired program.
3. Press the or button to display the desired start time.
4. Turn the control dial to Start Times
Note: Select - - - (dashes) to remove a Start Time.
To Set Station Run Time Duration (1– 240 minutes):
1.Turn the control dial to the desired Station number
2.Press the button to select the desired program.
3.Set the run time duration by pressing the
Note: Select - - - (dashes) to remove a Station Run Time.
4. Repeat steps 1–3 for all stations as needed.
.
- Sun .
(on) or (off).
.
.
field.
1.
2 and 3, repeat steps 2–3.
.
or button.
( )
OVER
