Irritrol KD2 Quick Reference Card

Set Time and/or Date

1. Turn the control dial to Date/Time
2. Press the or
3. Press the
4. Repeat steps 2 and 3 to set the current minutes, month, day and year.

Set Station Run Time Duration

1. Turn the control dial to Station Times
2. Press the button to select the desired program to edit.
3. Press the or
4. Press the
5. Repeat steps 3 and 4 to set all stations as needed in the program.
Note: Select - - - (dashes) to remove a station from the program.

Set Program Start Times

1. Turn the control dial to Start Times
2. Press the button to select the desired program to edit.
3. Press the or
4. Press the
5. Repeat steps 3 and 4 to set another start time. Each program can have up to 3 start times.

Set Calendar Day Watering Schedule

1. Turn the control dial to Water Days
2. Press the button to select the desired program to edit.
3. Press the or
4. Press the
5. Repeat steps 3 and 4 to set the remaining days of the week.

Set Interval Watering Schedule

1. Turn the control dial to Interval
2. Press the button to select the desired program to edit.
3. Press the or
Note: Select - - - (dashes) to deactivate Day Interval.
4. Press the
5. Press the or

Set Odd or Even Watering Schedule

1. Turn the control dial to
2. Press the button to select the desired program to edit.
3. Press the or

Special Functions

1. Turn the control dial to Special
2. Press the button to select the desired program to edit (if applicable).
3. Press the
4. Use the or
100% - Water Budget menu. Select between OFF and 200% in 10% increments.
HH:MM - Select the run time format between Hours:Minutes (HH:MM) or Minutes (MMM).
ENG - Select the desired display language.
12H - Select either 12-hour or 24-hour time format.
CLR - Select the program(s) to clear/erase. Press
XP Y - Enable (Y) or Disable (N) the Accessory Port.
RS Y - Enable (Y) or Disable (N) the SENSOR terminals.
VX.XX - Displays the controller's firmware version.
button to adjust the hour.
button to advance to the next field.
button to set the run time from 1–240 minutes.
button to select the next station.
button to set the desired start time. Select - - - (dashes) to remove.
button to select the next start time.
button to select
button to select the next day of the week.
button to select the desired day interval (01-31).
button to advance to TODAY field.
button to set the current day of the interval.
Odd/Even .
button to select ODD , EVEN or - - - (dashes) to deactivate schedule.
button to select the desired special function (see below).
button to modify the selection.
Quick Reference Card
.
.
.
.
( ON ) or ( OFF ).
.
Special Functions .
the
button twice to clear.
KD2
TM
