INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. The highest working pressure for spray is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure reducer is
needed. The highest water and environment temperature is 60°C. Please keep handspray, showerhead and the
shower arm away from heater, or it may become damaged and cause injury to the user.
STANDARD APPLICABLE
Special model meets or exceeds the following at date of manufacture: TIS
ROUGH-IN DIMENSIONS
50.7
15344T-E2
1234021-2A-A
15344T-E2
Multi-Function Handspray
45973T-E2
Handshower-Traditional
Ø122
G1/2˝
Ø122
G1/2˝
45973T-E2
RAIN DUET
79
1
Advertisement
Related Manuals for Kohler 15344T-E2
Summary of Contents for Kohler 15344T-E2
- Page 1 Handshower-Traditional BEFORE YOU BEGIN All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. Please leave these instructions for the consumer. They contain important information.
- Page 2 Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which could adversely affect the finish and are not recommended for cleaning. Do not use abrasive cleaners or solvents on Kohler faucets and fittings. SERVICE PARTS 1088901...
