- Page 1 User Manual www.epos-acoustics.com...
- Page 2 This booklet contains information on the Epos Mi series loudspeaker range, with the exception of the M sub-woofer which has its own manual. POWER REQUIREMENTS Amplifiers with power outputs between those noted in the loudspeaker specifications will generally be adequate, although more powerful amplifiers could be used if care is taken to avoid over-driving the loudspeakers.
- Page 3 Bi-wiring involves the use of two pairs of speaker cables between your loudspeakers and amplifier. Tri-wiring requires three pairs of speaker cables. If you wish to bi-wire your M5i, M8i or M12i speakers, or tri-wire your M16i or M22i speakers it is essential that you first unscrew all the binding posts and remove the metal links that join them together.
-
Page 4: Cable Termination
Then make a connection to the plug and screw the shroud fully over the plug until no bare plug is evident. Once again, if you are in doubt consult your Epos dealer. Residents of the European Union may wish to use bare wires into the terminal posts, as 4mm plugs have been outlawed. -
Page 5: Specifications
Epos 25mm aluminium dome with high-temperature voice coil, ferrofluid cooling and ferrite magnet system. Magnetically shielded Bass/Midrange Driver Epos mid bass 165mm with polymer cone,32mm high-temperature voice coil and die- cast aluminium chassis. Magnetically shielded Crossover Mid Bass driver crossover is by mechanical design and without electrical network. - Page 6 If close to the floor, angle the speaker up a little to aim at listener’s face Tweeter Epos 25mm aluminium dome with high-temperature voice coil, ferrofluid cooling and ferrite magnet system. Magnetically shielded Bass/Midrange Driver Epos 140m nominal, with 25mm high-temperature voice coil and injection-moulded PP cone mounted on an inert die-cast aluminium chassis.
-
Page 7: Warranty
WARRANTY WITHIN U.K. Your Epos Mi series loudspeakers have been built to very high standards and should give many years of trouble free service. If, within five years of purchase, they prove to be defective for any reason other than accident, misuse, neglect, unauthorized modification or fair wear and tear, we will repair the defect or, at our option, replace the faulty speakers without charge for parts, labour or return carriage. - Page 8 These pleasing variations are your guarantee of the unique and warm charm of your Epos speaker system. Each Epos cabinet is finished in a special lacquer, which ensures a maintenance free life. EPOS LIMITED...
