1.

NOTES ON THIS MANUAL

1.1 SCOPE OF VALIDATION

This User Manual discribes instructions and detailed procedures for installing,
operating, maintaining, and troubleshooting of the following SAJ grid-tie
inverters:
Sununo– TL1.5K, Sununo– TL2K,
Sununo– TL3KA, Sununo– TL4KA,
SU3KMTLI, SU4KMTLI,
Please keep this manual all time available in case of emergency.

1.2 SYMBOLS USED

DANGER
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, can result in death or serious injury or moderate
injury.
CAUTION
CAUTION indicates a hazardous condition which, if not
avoided, can result in minor or moderate injury.
NOTICE
NOTICE indicates a situation that can result in potential
damage, if not avoided.
User Manual
Sununo– TL3KB, Sununo– TL4KB,
Sununo– TL5K
SU5KMTLI
1

1.3 TARGET GROUP

Only qualified electricians who have read and fully understood all safety
regulation contained in this manual can install, maintain and repair the
inverter. Operators must be aware of the high-voltage device.
2.

PREPARATION

2.1 SYSTEM DEMONSTRATION

Solar energy generation systems, based on photovoltaic modules, nowadays
represent the most suitable solution to reduce the energy consumption
produced by oil and gas.
The solar inverter is a key device in a solar energy system. It performs the
conversion of the variable DC output of the PV modules into a clean sinusoidal
50Hz/60Hz AC current that is then directly applied to the commercial
electrical grid or to a local grid electrical network.
Typically, solar inverter includes communication function to monitor
operating condition, firmware to update and control the grid connection.
Depending on the grid infrastructure, cabled (RS-485, CAN, Power Line
Communication, Ethernet) or cableless (Bluetooth, ZigBee/IEEE802.15.4)
networking options can be used.
Solar
inverter
Solar
Panels
Grid
Figure 2.1
User Manual
Sell
Purchase
