GE PGP976 Installation Instructions Manual

36" sealed gas cooktop
Hide thumbs Also See for PGP976:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

I stallatio
I structio s
36" Sealed Gas Cooktop
PGP976, PGP986, CGP650
Questions? Call 800.GE.CARES (800.432.2737
or Visit our Website at: ge.com
In Canada, call 1.800.561.3344
or Visit our Website at: www.geappliances.ca
i
IN THE COMMONWEALTH
OF
MASSACH USETTS:
. This product
must be installed by a licensed
plumber
or gas fitter.
, When using ball-type gas shut-off
valves, they
shall be the T-handle type.
, A flexible gas connector,
when used, must not
exceed 3 feet.
BEFORE YOU BEGIN
Read these instructions
completely
and carefully.
.IMPORTANT
- Save these
instructions
for local inspector's
use.
, IMPORTANT - Observe all
g overning
codes and ordinances.
, Note to Installer-
Be sure to leave these
instructions
with the Consumer.
, Note to Consumer
- Keep these instructions
for
future reference.
, Product failure due to improper
installation
is not
covered under the Warranty.
AWARNING
- Thisappliancemust be
properly grounded.
.
IMPORTANT
- Leak testing of the
applianceshall be conducted accordingto the
manufacturer's
instructions.
, Proper installation
is the responsibility
of the
installer and product failure due to improper
installation
is NOT covered under warranty.
WARN ING - Disconnect
all electrical
power at the main circuit breaker
or fuse box before installing.
FOR YOUR SAFETY:
AWARNING
- Iftheinformation inthis
manual
is not followed
exactly,
a fire, explosion
or gas leak may result causing
property
damage,
personal
injury
or death.
Do not store or use gasoline
or other flammable
vapors and liquids
in the vicinity
of this or any
other appliance!
WHAT
TO DO IFYOU SMELL
GAS:
Do not try to light any appliance.
Do not touch
any electrical
switch;
do not use any phone in
your building.
Immediately
call your gas supplier
from a
neighbor's
phone. Follow the gas supplier's
instructions.
, If you cannot
reach your gas supplier,
call the
fire department.
Installation
and service must be performed
by
a qualified
installer,
service agency or the gas
supplier.
This cooktop
has been certified
by UL. You'll find
safety precautions
in your Owner's Manual. Read
them carefully.
Installation
of this cooktop
must conform
with
local codes or in the absence of local codes with
the National Fuel Gas Code, ANSI Z223.1/NFPA
54-Latest
edition.
Be sure your cooktop
is installed properly by a
qualified
installer or service technician.
To eliminate
reaching over surface burners,
cabinet storage above burner should be avoided.
Do not install the unit near an outside door or
where a draft may affect its use.
31-i0808-i
(08-11GE)
1

Advertisement

Table of Contents
loading

Summary of Contents for GE PGP976

  • Page 1 I stallatio 36" Sealed Gas Cooktop I structio s PGP976, PGP986, CGP650 Questions? Call 800.GE.CARES (800.432.2737 or Visit our Website at: ge.com In Canada, call 1.800.561.3344 or Visit our Website at: www.geappliances.ca IN THE COMMONWEALTH FOR YOUR SAFETY: MASSACH USETTS:...
  • Page 2: Installation

    Installation Instructions IMPORTANT SAFETY INSTRUCTIONS PARTS INCLUDED ELECTRICAL REQUIREMENTS This appliance must be supplied with the proper voltage and frequency and connected to an individual, properly grounded branch circuit, protected by a circuit breaker or fuse having 2 Screws Regulator amperage as noted on the rating plate.
  • Page 3: Pre-Installation

    Installation Instructions PRE-INSTALLATION CHECKLIST Remove Installation Instructions from When preparing cooktop opening, make sure the inside of the cabinet and the literature pack and read them carefully cooktop do not interfere with each other. before you begin. (See section on preparing the opening.) Be sure to place all literature (Owners Manual,...
  • Page 4: Preparing The Opening
