1. Plug the supplied AC cord into the Corinex Intelligent
PowerNet Ethernet Adapter and after that, into an AC
outlet.
2. Plug the Ethernet cable into the Corinex Intelligent
PowerNet Ethernet Adapter and the Ethernet slot or card on
your PC.
As soon as the
Adapter is connected to an Ethernet slot or card using
a standard cable, the button on the front panel of the box
should be in the „OUT" (Normal) position. A cable modem or
DSL modem often requires a "cross cable". If this is the case,
the button should be in the „IN" (Uplink) position. When the
button is in the correct position, the green link LED at the
Ethernet connection will light up.
2.4

Installing the PowerNet Setup Tool

1. Insert the installation CD. The CD should automatically start
the installation process. If the installation program does not
start automatically, start the application by selecting „My
Computer", usually found on the desktop. Navigate to the
CD drive, and double click on the drive. The following screen
should be displayed:
Corinex Intelligent PowerNet Ethernet
6
