(0) H T V
OP ABLE ERSION
Entry 0 allows the user to choose the portion of the band in which the transceiver will operate.
Selection Name
0 902 – 928 MHz
1 915 – 928 MHz
2 902 – 928 Mhz, 16 fewer
freqs
3 916 – 920 MHz
4 921 – 928 MHz
5 902 – 911 & 919 – 928
MHz
6 902 – 915 MHz
Note: Do not use FreqKey 14 (E) with the Australia (915-928 MHz), Taiwan (916-920 MHz), and New
Zealand (921-928) hop tables.
(1) H T S
OP ABLE IZE
The Hop Table Size defines how many separate channels will be used by a given network. For 900MHz
networks, the Hop Table Size may be set from 50 to 112.
(2) H F O
OP REQ FFSET
The Hop Freq Offset option is not functional in the 900 MHz spread spectrum transceiver.
Note: Regardless of the FreqKey used, all transceivers in either Point-to-Point or Point-to-MultiPoint
networks must be set to identical Hop Table Version, Hop Table Size and Hop Freq Offset.
LUM0002AF Rev G
Spread Spectrum Wireless Data Transceiver User Manual
Available options
Band
Full 902-928 MHz
915-928 MHz
902-928 MHz, 16 fewer frequencies than full U.S. set
916-920 MHz
921-928 MHz
Uses 902-928 MHz with center frequencies of 911-
919 MHz notched out
902-915 MHz
