  • Page 1 ® FreeWave Spread Spectrum Wireless Data Transceiver User Manual FreeWave Technologies, Inc. 1880 South Flatiron Court Boulder, CO 80301 (303) 444-3862 (303) 786-9948 www.freewave.com...
  • Page 3 Other product names mentioned in this manual may be copyrights, trademarks, or registered trademarks of their respective companies and are hereby acknowledged. The FreeWave Wireless Data Transceiver is made in the United States of America. Printed in the United States of America.
  • Page 4 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S...
  • Page 5 ♦ Consult the dealer or an experienced radio/TV technician for help. Note: Whenever any FreeWave Technologies module is placed inside an enclosure a label must be placed on the outside of that enclosure which includes the module's FCC ID.
  • Page 6 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S...
  • Page 7 This product is licensed by The United States. Diversion contrary to U.S. law is prohibited. Shipment or re-export of this product outside of The United States may require authorization by the U.S. Bureau of Export Administration. Please contact FreeWave Technologies for assistance and further information.
  • Page 8 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S...
  • Page 9 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Model# FGRO9CSU is suitable for use in Class 1, Division 2, Groups A, B, C, and D or non- hazardous locations only.
  • Page 10 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S viii...

  • Page 11: Table Of Contents

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Table of Contents QUICK START..................... 1 QUICK START ON A MULTIPOINT SYSTEM............ 2 TUNING TRANSCEIVER PERFORMANCE ............3 OPERATION MODE SELECTIONS ..............6 (0) P ................6...
  • Page 12 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S RADIO TRANSMISSION PARAMETERS ............29 (0) F ....................30 ................34 ACKET IZE AND ................. 34 ACKET (3) X ....................36 (4) RF D ..................36 (5) RF X ..................
  • Page 13 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S List of Tables Table 1 Setup Menu Terminal Settings .................. 3 Table 2: AT Script File Commands..................8 Table 3: Subnet ID Settings ....................19 Table 4: Data Word Length and Parity Selections..............22 Table 5: Data port protocol Selections..................
  • Page 14 V5.0S Table of Figures Figure 1: Initial Menu ......................4 Figure 2: FreeWave Operation Mode Menu ................5 Figure 3: Using Mode 6 to Call Through Repeaters ............... 9 Figure 4: Multipoint Parameters.................... 14 Figure 5: Multipoint Subnet Diagram ..................19 Figure 6: Baud Rate, and other items related to the Data port ..........

  • Page 15: Quick Start

    FreeWave will potentially operate in virtually any environment where RS232 data communications occur. The transceivers function as a 9 pin null modem cable. If FreeWave is to be used in an application where a null modem cable is used (such as communication between two computers), then FreeWave can be connected directly.

  • Page 16: Quick Start On A Multipoint System

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Quick Start on a Multipoint System 0) Set Operation Mode Program one of the units to be a multipoint Master (Operation Mode 2) Program the Multipoint Slaves (Operation Mode 3)

  • Page 17: Tuning Transceiver Performance

    900 MHz and 2.4 GHz V5.0S Tuning Transceiver Performance FreeWave allows you to tune several parameters to optimize its performance for your particular application. All adjustments are done through the FreeWave setup program, a user interface which eliminates the need for setup diskettes, DIP switch settings, or custom software.

  • Page 18: Figure 1: Initial Menu

    900 MHz and 2.4 GHz V5.0S When the setup program is invoked all three LEDs on the FreeWave front panel will turn green and will remain green for the entire time the Transceiver is in setup mode. The main menu screen for the setup program is shown in Figure 1:...

  • Page 19: Figure 2: Freewave Operation Mode Menu

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Figure 2: FreeWave Operation Mode Menu...

  • Page 20: Operation Mode Selections

    LEDs will be solid red. (1) Point-to-Point Slave When set up as a point to point slave a FreeWave Transceiver will communicate with any master in its call book, either directly or through up to four repeaters. When functioning as a slave, the Entry to Call feature in the Transceiver's call book (Figure 7) is not operational.

  • Page 21: Point-To-Point Repeater

    900 MHz and 2.4 GHz V5.0S (5) Point-to-Point Repeater FreeWave allows the use of up to four repeaters in a point to point communications link, significantly extending the operating range. When designated as a repeater a Transceiver behaves as a pass-through link.

  • Page 22: Table 2: At Script File Commands

    RF Data Rate ATXP_ RF Transmit Power ATDT_ Position in Call Book to Call ATD_ Allows specific FreeWave Serial Number to be entered to call ATXC_ Used in conjunction with the ATD command, instructs transceivers which repeater path to follow ATXS...

  • Page 23: Figure 3: Using Mode 6 To Call Through Repeaters

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Using Mode 6 to call a transceiver not listed in the Call Book Mode 6 will accept the command ATD####### where ####### is any arbitrary modem serial number such as 5551234.

  • Page 24: Point-To-Multipoint Repeater

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Issue the command ATXC# where # corresponds to the position in the Call Book where the repeater(s) is/are located 3. Issue the command ATD####### where ####### is the serial number of the transceiver with which you are attempting a link.

  • Page 25: Multipoint Operation

    Please contact FreeWave Technologies if you have any questions about the installation of multipoint systems.

  • Page 26: Overlapping Multipoint Systems

    900 MHz and 2.4 GHz V5.0S Overlapping Multipoint Systems Overlapping multipoint systems may be set up with FreeWave transceivers effectively if a couple of key parameters are set correctly. Overlapping multipoint systems are defined as systems using different masters which share or overlap in a specific geographic area. It may include colocation of units (generally repeaters) which are part of different systems.
  • Page 27 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S It is important to keep in mind that increasing the master packet repeat will not only increase the probability of a packet getting through, but will also increase latency in the system because each packet from the master or repeater is being sent more often.

  • Page 28: Master Packet Repeat In Multipoint Systems With Repeaters

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Master Packet Repeat in Multipoint Systems with Repeaters The Master Packet Repeat parameter must also be set in multipoint repeaters when they are used in a multipoint system. In a multipoint system a repeater looks like a master to a slave.

  • Page 29: Max Slave Retry

    The repeater may be programmed to either use the master's hopping pattern (selection 0) or its own (selection 1). Please refer to the Application Note on the wwww.freewave.com website.

  • Page 30: Network Id

    (8) MultiMaster Synch (8) MultiMaster Synch is reserved for applications (either point to point or multipoint) with concentrations of Master units where it is necessary to reduce interference between the Masters. Please contact FreeWave Technologies for more information. (9) 1 PPS Enable/Delay The 1 PPS Enable/Delay option allows the radio network to propagate a GPS 1PPS signal from the master transceiver to all slaves in a multipoint network.

  • Page 31: (A) Slave/Repeater

    A second computer to run the diagnostics software A diagnostics cable, available through FreeWave Technologies Diagnostics software, also available through FreeWave Technologies Please contact FreeWave if you are interested in using the diagnostics feature in your network. (C) Subnet ID...
  • Page 32 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Note: The Subnet ID works only in Multipoint Networks using NetworkID. Note: In typical Multipoint Networks the Freq Key must be at the same setting for all transceivers. If the SubnetID is used the sub network may be set to a different Freq Key.

  • Page 33: Figure 5: Multipoint Subnet Diagram

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S The drawing below depicts a Multipoint Network in which the Subnet ID is used to force communications along specific paths. In this example Repeater1 must talk directly to the Master, and Repeater2 must talk directly to Repeater1.

  • Page 34: (D) Radio Id

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S (D) Radio ID Option (D) allows a transceiver to be designated with an arbitrary, user selectable, 4 digit number which identifies the transceiver in the diagnostics mode.

  • Page 35: Baud Rate Selections

    Transceiver(s) in the communication loop. For example, FreeWave may be used in an application to send data from remote process instrumentation to an engineer's computer. In this application the baud rate for the Transceiver on the instrumentation might be set to 9600, and the Transceiver on the computer might be set to 57,600 or 115,200.

  • Page 36: Data Word Length And Parity

    (2) Data Word Length and Parity There are six data word length and parity configurations available to be used with FreeWave transceivers. The default setting is 0 (8,N,1) and is the most commonly used serial communications protocol. Data word length and parity selections available:...

  • Page 37: Setup Port

    The Diagnostics port is a 3-pin connector. In the FGR-115RC and the FGR-115RE (Ethernet modem) this is a small 3-pin connector on the rear panel. An adapter cable for this port ((ASC0409DC) is available from FreeWave. In the FGR09xx (board level modem), this is part of a 2-row, 2 mm PCB female strip connector.

  • Page 38: Flow Control

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Flow Control Use this menu to specify the hardware flow control for the Data port. Table 7: Flow control Selections Menu Setting Port Notes None Use software control (XON XOFF)

  • Page 39: Call Book Selections

    Call Book Selections (2) Edit Call Book The Call Book is an innovative feature in FreeWave which offers both security and flexibility in use. The Call Book accomplishes this by allowing the user to determine with which other FreeWave Transceivers a given Transceiver will communicate, based on the serial numbers for both the master and slave.

  • Page 40: Entering Or Modifying Numbers In The Call Book

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Figure 7: Call Book Menu Entering or Modifying numbers in the Call Book Entering or modifying serial numbers in the Call Book is a straightforward process. When in the Call Book menu enter the position number (0 - 9) you wish to edit.

  • Page 41: Programming The Call Book To Use 3 Or 4 Repeaters

    Programming the Call Book to Use 3 or 4 Repeaters In a point to point link FreeWave can utilize up to 4 repeaters. To use 3 or 4 repeaters program the Call Book with the slave being called, followed by the first 2 repeaters being used (from the master calling out to the slave).

  • Page 42: Programming The Call Book In Multipoint Systems

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Programming The Call Book in Multipoint Systems In a Multipoint system the slaves and repeaters are not listed in the master's Call Book. When establishing such a system, it is necessary only to have the master's...

  • Page 43: Radio Transmission Parameters

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Radio Transmission Parameters (3) Edit Radio Transmission Characteristics When item (3) is selected in the main menu the screen in figure 9 appears, which allows the user to modify the radio transmission characteristics of the Transceivers.

  • Page 44: Freqkey

    (0) FreqKey Selection (0) in the Radio Parameters menu allows the user to modify the hopping patterns of the Transceivers to minimize the interference with other FreeWave Transceivers in operation in the area. For instance, if there were 10 pairs of...

  • Page 45: Table 8: Frequency Bands, 900 Mhz

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S (0) Hop Table Version Entry 0 allows the user to choose the portion of the band in which the transceiver will operate. These choices are show in the table below:...
  • Page 46 V5.0S 2.4GHz The Frequency Key for the FreeWave Technologies 2.4GHz transceivers offers the ability to select more than just a different pseudo random hop table, but also the portion of the band which the transceiver will use. Because this feature offers...

  • Page 47: Figure 11: Frequency Key & Hop Table Options, 2.4 Ghz

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Figure 11: Frequency Key & Hop Table Options, 2.4 Ghz...

  • Page 48: Max Packet Size And

    Selections (1) and (2) allow the user to designate the size of the packets (in bytes) used by the transceiver in its communication link. This may be of particular value when using FreeWave with different communications software packages; you may find that throughput is optimized when packet sizes are restricted by the transceiver.

  • Page 49: Table 11: Max Packet Size Settings (Bytes) Rf Data Rate=2

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Table 11: Max Packet Size Settings (Bytes) RF Data Rate=2 Max Setting Setting Table 12: Max Packet Size Settings (Bytes) RF Data Rate=3 Max Setting Setting...

  • Page 50: Xmit Rate

    (4) RF Data Rate FreeWave has two settings for the RF Data Rate (not to be confused with the RS232 Baud Rate). Setting 2 should be used when the transceivers are close together and data throughput is to be optimized.

  • Page 51: Rf Xmit Power

    With option 6 the user may disable the transceiver’s security so it will accept a call from any other FreeWave unit. The default setting is 0 where security is enforced (the caller’s serial number must be in the slave’s Call Book), with a setting of 1 security is disabled.

  • Page 52: Retry Time Out

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S (8) Retry Time Out The Retry Time Out parameter allows the user to determine when a slave will drop a connection to a master or repeater in multipoint mode. The default setting is 255, meaning that if one packet in 255 from the master is sent successfully to the slave it will maintain a link.

  • Page 53: (A) High Noise

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S the table gives only qualitative indication of savings of supply current. Set this setting to empirically, considering that a low number reduces latency, and a high number reduces current consumption.

  • Page 54: Radio Statistics

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Radio Statistics Option (4) in the main menu allows the user to view data transmission statistics which have been gathered by the Transceiver during the most recent session.
  • Page 55 High noise levels can often be improved with bandpass filters, antenna placement or antenna polarization. Please contact FreeWave Technologies for more information. Average Signal Level The average signal level indicates the level of received signal at this modem and at each of the modems used as repeaters in the link.
  • Page 56 900 MHz and 2.4 GHz V5.0S Radio Temperature The radio temperature value is the current operating temperature of the radio in degrees C (Celsius.) For proper operation, FreeWave radio modems must be in ° ° the range of –40 to 75...

  • Page 57: Password

    Caution!!! If the password feature is enabled and you cannot remember the password the radio will need to be sent back to FreeWave to have the password disabled. Option (8) in the Main Menu allows the user to set a password which will prevent access to or changing of any of the radio’s parameters.

  • Page 58: Disabling A Password

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Disabling a Password The process to disable the password is similar to the process to change the password. However, when prompted to enter the new password the following procedure needs to be followed: 1.

  • Page 59: Transceiver Location

    V5.0S Transceiver Location Placement of your FreeWave unit is likely to have a significant impact on its performance. In general the rule of thumb with FreeWave is that the higher the placement of the antenna the better the communication link - height is everything! In practice you should also place the transceiver away from computers, telephones, answering machines, and other similar equipment.

  • Page 60: Front Panel Leds

    900 MHz and 2.4 GHz V5.0S Front Panel LEDs The LEDs on FreeWave's front panel provide important information on the operation of the transceiver. Compare the status of a Transceiver's LEDs with the table below to aid you in the troubleshooting process.

  • Page 61: Table 16: Led Status In Multipoint Mode

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Table 16: LED Status in Multipoint Mode MultiPoint Communications Master Slave Repeater Condition Powered, disconnected Repeater and slave connected to master, no data Repeater & slave connected to master,...

  • Page 62: Rs232 Pin Assignments

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S RS232 Pin Assignments Table 17: RS232 Pin Assignments Assignment Signal Carrier Detect Output Transmit Data Output Receive Data Input Input Ground Data Set Ready Output Input Clear to Send...
  • Page 63 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Pin 8: Clear to Send (CTS) This signal is used to tell the system device connected to the modem that the modem is ready to receive data. When asserted, the modem will accept data, when deasserted the modem will not accept data.

  • Page 64: Fgro Rf Board Only Pinout

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S FGRO RF Board only Pinout The FGRO Small Footprint Series transceivers are available in both TTL and RS232 versions. The TTL versions use reverse polarity from standard RS-232 at 0 to 5 Volt levels.

  • Page 65: Fgr-115Wc Waterproof Enclosure Pinout

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S FGR-115WC Waterproof Enclosure Pinout for Cable ASC0612WW Table 19: FGR-115WC Pinout Color Function Signal Brown Carrier Detect Output Transmit Data Output Orange Receive Data Input Yellow Input...

  • Page 66: Establishing Data Communication Links

    900 MHz and 2.4 GHz V5.0S Establishing Data Communication Links FreeWave's versatility allows data communication links to be established using a variety of different configurations. This, in turn, makes it possible to extend the range of FreeWave and get around obstacles.
  • Page 67 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Diagram (C) shows a link with two repeaters between the master and slave. With two repeaters there is clearly more flexibility in getting around obstacles and greater total range is possible. Once again, it would be desirable to use external omnidirectional antennas with the repeaters, and attaching a Yagi to the master and slave would increase the range of the link.
  • Page 68 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Example (E) depicts a standard point-to-multipoint system. In this example any data sent from the master is broadcast to all three slaves, one of which receives it through a multipoint repeater.
  • Page 69 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S In (F) a point-to-multipoint system is depicted which uses one of the slave sites as a repeater simultaneously, all through the same radio. This system works in a...

  • Page 70: Rs422 & Rs-485 Operation

    V5.0S RS422 & RS-485 Operation For both RS-422 and RS-485 the Freewave modem can drive 32 standard unit loads and loads the buss with only 1/8 unit load. This means the user can tie up to 256 devices on the buss if all of the line receivers have 1/8 unit load (different devices have different loads).

  • Page 71: Table 21: Rs 485 Half Duplex

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S RS-422 & RS-485 Full Duplex pin-outs Function Bare Board Pin Number DE-9 Pin Number Table 20: RS-422 & RS 485 full duplex RS-485 Half Duplex pin-outs Function...

  • Page 72: Other Settings

    V5.0S Other Settings A number of parameters other those shown in the setup menu may be set on FreeWave transceivers. The parameters below may be set with DOS based software available by contacting FreeWave Technologies. Baud Rate The transceiver's RS232 baud rate may be set to 300, 600, or 900 baud.

  • Page 73: Technical Specifications

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Technical Specifications Specification Frequency: 902 to 928 MHz Transmitter: 1 mW to 1 W (+30 dDm) Output Power Range* 60 miles Spread Spectrum GFSK, 120 kBs – 170 kBs...
  • Page 74 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S FGR09xx FGR-115RE FGR-115RC FGR-115WC Data port 10-pin PCB connector Ethernet RS232, DE9-F RS232, circular connector Enclosure Bare board Extruded Aluminum Extruded Aluminum Extruded Aluminum Waterproof Dimensions 16 mm H x 62 mm W x 128...
  • Page 75 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Specification Frequency: 2.400 to 2.4835 GHz Transmitter: Output Power 100 mW to 500 mW Range* 20 miles Modulation GFSK, 115.2 Kbps or 153.6 Kbps Occupied Bandwidth 230 kHz...
  • Page 76 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Board Level I-800X009 I-900X009 Data port 10-pin PCB connector RS232, DE9-F RS232, circular connector Enclosure Bare board Extruded Aluminum Extruded Aluminum Waterproof Dimensions 16 mm H x 62 mm W x 128...

  • Page 77: Troubleshooting

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Troubleshooting For up to date troubleshooting information check the FAQ page at www.freewave.com.
  • Page 78 FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S Notes:...

  • Page 79: Oem Board Level Mechanical Drawing

    FreeWave Technologies Spread Spectrum Transceiver User Manual 900 MHz and 2.4 GHz V5.0S OEM Board Level Mechanical Drawing...
