By purchasing a loudspeaker from PIEGA you have expressed your trust in our company, for which we thank you very much. At the same time we assure you that you have purchased a product that is based on twenty years of R &...
Contents This user manual describes how to optimally install and connect the PIEGA loudspeakers for a wide range of uses and contains some useful information on operating, caring for and maintaining your loudspeakers. It also contains instructions for unpacking and setting up the loudspeakers.
Ensure without fail that your new PIEGA loudspeak- ers are mounted, positioned and connected exactly according to these instructions. PIEGA loudspeakers were only designed for use in dry residential environments within a temperature range of 10...40°C. The high quality loudspeaker chassis of PIEGA loud- speakers contain exceptionally strong magnets with magnetic fields that may impair the operation of...
Unpacking the Loudspeakers Special care was taken in the packaging of your new PIEGA quality products in order to ensure that your loudspeakers reach your living room safely and undamaged. In order to avoid any damage when unpacking the loudspeakers, follow closely the instructions below without fail.
The PIEGA Loudspeaker Series comprises floor-standing, satellite and center loudspeakers. Some series include all three loudspeaker types. All loudspeakers of the same series are based on the same technology, either dome tweeter or PIEGA ribbon tweeter. All loudspeakers of the same technology can always be com- bined and arranged into a cohesive home cinema system and also ideal for stereo systems, sound systems in bars and restaurants, fitness centers etc.
Positioning Perfect sound quality depends on the correct positioning and alignment of the loudspeakers. For stereo operation, the best results are achieved using the stereo triangle layout. In multi-channel systems, the front, center and rear speakers should be positioned as equidistantly as possible and aligned to the point of listening and time delay should be adjusted in the setup of the AV-receiver.
On-Wall Installation You can use the wall bracket (available as an accessory) to mount the satellite loudspeakers either on the wall or ceiling and thus use it as a rear or side speaker for both diffused and direct sound. The brackets are also used when installing the loudspeakers for a room sound system.
The terminal for single wiring applications is provided at the back of the loudspeaker. This is used for connect- ing standard loudspeaker cables with banana plugs or with a lead. Ideally, PIEGA loudspeakers should be con- nected with the CableONE or CableTHREE loudspeaker cable which is available as an accessory.
As a loudspeaker is basically a mechanical transducer consisting of several different components, the individ- ual elements must be run in during the initial weeks. This will ensure that the sound quality potential of your loudspeakers is fully utilized. You will definitely notice the resulting improvement in sound. Recommendations: In the first days and weeks listen only at normal...
From development to production, right down to quality testing, PIEGA only uses materials and components of the highest quality. Your new PIEGA loudspeakers are provided with a polished aluminum surface. Al- though this material is not very sensitive, it should be treated with due care.
Piega. 5. If it is necessary for a device or part of it to be sent to Piega or an approved Piega workshop, the sender is responsible for paying all transport costs in advance. The original packaging must be used for sending the complete device.
