- Page 1 PIEGA 2008...
- Page 3 PIEGA 2008...
- Page 5 PIEGA The Company Even after more than twenty years since the founding of our company PIEGA, we have still kept our passion for building loudspeakers for discerning audiophiles. We have held true to our core expertise and our specialties, the LDR (Linear Drive Ribbon) tweeter, the coaxial ribbon system and the seamless aluminum cabinet have now become synonymous amongst specialists with audio excellence.
- Page 7 When it comes to quality, we leave nothing to chance. New ways were also developed for the design of loudspeaker cabinets. The extrud- ed aluminum cabinets are PIEGA innovations, finished to perfection with optimum damping without any intrinsic sound.
- Page 9 All employ- ees at PIEGA are aware of their responsibility to maintain the exclusivity of this loudspeaker and focus all their abilities in ensuring that the CL 120 X reaches the new owner in perfect condition.
- Page 11 TC 30 X is equipped with the coaxial ribbon system which means that the acoustic center of midrange and tweeter excludes any disturbing interference. Precise sound reproduction and pure musical enjoyment – hand made by PIEGA in Horgen.
- Page 13 ® bass performance. These are combined with the stunning musicality and dynamics of the PIEGA LDR ribbon tweeter for a clean and unerring musical integrity. Top class slim-line column loudpeaker with ribbon tweeter TP 5 S (Small)
- Page 15 PIEGA TS Series Slimline column loudspeaker in the upper medium quality range TS 5 The slim-line column loudspeaker with its double-bass components with MDS ® technology, precise aluminum housing, neodymium dome and precision-designed frequency crossover. For a loudspeaker with such a filigree appearance, the TS 5 offers an astonishingly solid sound which was simply unachievable before.
- Page 17 Furthermore, the AP 3 even uses a genuine PIEGA LDR ribbon tweeter inside. The loudspeakers can be mounted both vertically and horizontally without any loss in quality.
- Page 19 The center speaker for the TP and TC Series with ribbon tweeter TC 40 C The PIEGA TC 40 C model stands out with its sound quality and optimum spatial imaging. Featuring the unique PIEGA LDR ribbon tweeter and the MDS® basses, this 2 1/2-way system offers brilliant sound reproduction with an unembellished directness and clarity that is only achievable with PIEGA technology.
- Page 21 PIEGA SUB Series The uncompromising subwoofer PS 2 A PS subwoofer is essential for hearing the really deep groove and fully appreciat- ing the entire bass range. It offers tremendous performance both in home cinemas and in stereo systems. The newly developed PS 2 offers superb bass range performance for your favorite music or cinema experience.
- Page 22 The ideal connection to the CL 120 X, CL 90 X and PIEGA‘s other top class loud- speakers with a coaxial ribbon system. The OPUS 3 cable is also an alternative.
-
Page 23: Technical Data
Technical Data The loudspeakers of all series are Model available on request in a range of Design principle different finishes and with different loudspeaker coverings. Recommended amplifier output Sensitivity Impedance Frequency range Equipment Connection Dimensions (HxWxD) Weight Finish CL 120 X CL 90 X 3-way system floor-standing 3-way system floor-standing... - Page 24 Model TC 70 X Design principle 3-way system floor-standing loudspeaker Recommended 20 – 250 Watt amplifier output Sensitivity 92 db/W/m Impedance 4 Ohm Frequency range 26 Hz – 50 kHz Equipment 2 18 cm MOM 1 C2 coaxial ribbon system Connection Bi-Wiring / WBT Dimensions (HxWxD)
- Page 25 Model TP 7 Design principle 3-way system column loudspeaker Recommended 20 – 250 Watt amplifier output Sensitivity 91 db/W/m Impedance 4 Ohm Frequency range 30 Hz – 50 kHz Equipment 4 13 cm MDS 1 13 cm MDS 1 LDR tweeter Connection Dimensions (HxWxD) 161 x 19 x 21 cm...
- Page 26 Model Design principle Recommended amplifier output Sensitivity Impedance Frequency range Equipment Connection Dimensions (HxWxD) Weight Finish TS 5 1015 TS 3 TS 5 2 1/2-way system column loudspeaker 20 – 150 Watt 90 db/W/m 4 Ohm 45 Hz – 22 kHz 2 10 cm MDS 1 26 mm LDS dome Multi-Connectors...
- Page 27 Model Design principle Recommended amplifier output Sensitivity Impedance Frequency range Equipment Connection Dimensions (HxWxD) Weight Finish AP 3 AS 3 AP 3 AS 3 2-way system 2-way system 20 – 150 Watt 20 – 150 Watt 90 db/W/m 89 db/W/m 4 Ohm 4 Ohm 45 Hz –...
- Page 28 Model TC 40 CX Design principle 3-way system center loudspeaker Recommended 20 – 250 Watt amplifier output Sensitivity 91 db/W/m Impedance 4 Ohm Frequency range 35 Hz – 50 kHz Equipment 2 15 cm MOM 1 C2 coaxial ribbon system Connection Dimensions (HxWxD) 19 x 61 x 21 cm...
- Page 29 Model Design principle Recommended amplifier output Sensitivity Impedance Frequency range Equipment Connection Dimensions (HxWxD) Weight Finish PS 2 PS 1 PS 2 PS 1 active subwoofer active bassreflex subwoofer integrated integrated 500 Watt amplifier 250 Watt amplifier variable variable – –...
- Page 30 Service PIEGA offers first-class service and six years warranty on all loudspeakers, as well as three years on the electronics.
- Page 32 PIEGA SA Bahnhofstrasse 29 CH-8810 Horgen Telephone +41 44 725 90 42 Fax +41 44 725 91 92 mail@piega.ch www.piega.ch Information for Exports PIEGA SA Bahnhofstrasse 29 CH-8810 Horgen Telephone +41 44 725 90 02 Fax +41 44 725 91 92 mail@piega.ch...
