- Page 1 TRANSDUCTION USER’S MANUAL Version 1.2 07/30/08 TR-LCD1900-RM Rack Mount Monitor TR-LCD1900-PM Panel Mount Monitor 5155-23 Spectrum Way, Mississauga, ON, Canada L4W 5A1 TEL: 1-800-268-0427, 905-625-1907 FAX: 905-625-0531 Email: sales@transduction.com...
- Page 2 Products returned for repair must be accompanied by a Return Material Authorization (RMA) number, obtained from Transduction prior to return. Freight on all returned items must be prepaid by the customer. The customer is responsible for any loss or damage caused by the carrier in transit.
-
Page 3: Safety Precautions
Safety Precautions When not used for extended periods of time, set your PC to DPMS. If using a screen saver, set it to the active screen mode. Do not use a damaged or loose plug. This may cause an electric shock or fire. Do not pull the plug out by the wire or touch the plug with wet hands. - Page 4 Contents Your new TR-LCD1900 monitor box should contain the following: • TR-LCD1900 rack mount / panel mount monitor • Power Cord • Video Signal Cable • User’s Manual and Driver Installation CD *Remember to save your original box and packing material to transport or ship the monitor. Power Cord Video Signal Cable User’s Manual and Driver...
-
Page 5: Quick Start
Quick Start To attach the TR-LCD1900 monitor to your system, follow these instructions: 1. Turn off the power to your computer. 2. Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. -
Page 6: Control Panel Buttons
Control Panel Buttons The Control Panel Buttons give various and very easy graphic user interfaces. Users can easily access the function needed. Be sure that your system power and LED is turned on before operating the keyboard. Key Name and Function Key Name Description Power... - Page 7 Control Panel Buttons cont’d OSD Adjustment Menus Sub-menus Function Descriptions Adjustment (PC) Brightness Adjusts the brightness of video. Adjustment is used Contrast Adjusts the contrast of video. to fine tune and get Clock Removes the noises. When frequency value is wrong, the image the best image by has horizontal lines especially in 1 dot on and off.
- Page 8 Rear Panel Connectors and On/Off Switch (The configuration at the back of the monitor may vary from product to product.) Power port Connect the power cord for your monitor to the power port on the back of the monitor. DVI port Connect the DVI Cable to the DVI Port on the back of your Monitor.
-
Page 9: Troubleshooting Tips
Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, Troubleshooting Tips please contact Transduction. Symptom Check List Solutions No images on the screen. I Is the power cord connected Check the power cord connection and supply. -
Page 10: Frequently Asked Questions
Troubleshooting Tips - cont’d Check Before Using MagicTune 1. The MagicTune (display adjustment) feature is not available in Game mode or Full Screen video mode. 2. When activated in a mode in which the four edges of the display are black (Game or DOS mode), the “Auto”... -
Page 11: Self-Test Feature
Self-Test Feature The TR-LCD1900 has a Self-Test feature that allows you to check whether your monitor is functioning properly. Self-Test Feature Check 1. Turn off both your computer and the monitor. 2. Unplug the video cable from the back of the computer. 3. - Page 12 TR-LCD1900 Specifications TR-LCD1900 Monitor Notes LCD Module Active matrix, thin film transistor Size: 19.0 inch diagonal (TFT) liquid crystal display Display Area: 376.32 (H) x 301.056 (V) (LCD) Pixel Pitch: 0.294 (H) x 0.294 (V) Type: a-si TFT active matrix Viewing Angle: 80(H) / 75(V) Brightness:...
-
Page 13: Resolutions Supported
Resolutions Supported If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power is on. Refer to the video card manual and adjust the screen as follows. Preset Timing Modes Display Mode Horizontal... - Page 14 TRANSDUCTION 5155 Spectrum Way Bldg 23 Mississauga, ON L4W 5A1 Canada 905-625-1907 www.transduction.com TR-LCD1900...
