Summary of Contents for Snell B7
- Page 1 Owner’s Manual Tower Tower Tower CR70 Center Channel...
-
Page 2: Specifications
Natural cherry or Natural cherry or Black-painted walnut Black-painted walnut Shipping Weight 115 lbs (52.2 kg) / each 115 lbs (52.2 kg) / each B7 / C7 * Custom paint and grilles are available Port for an extra charge Rear Tweeter... - Page 3 CR70 38 Hz-20 kHz 62 Hz-22 kHz 50–250W 50–250W 4 ohms 4 ohms 90dB SPL 89dB SPL 1” SEAS silk dome, 1 inch SEAS silk dome, with 1 inch rear tweeter a 4-inch treated paper midrange Dual 6 -inch (165mm) SEAS Dual 6 -inch (165mm) SEAS treated paper cone,...
-
Page 4: Product Description
Front channel speakers of a surround system note: The four legs supplied with the B7, C7 and D7 must be attached to the base of the cabinet. This is necessary for stability as well as bass performannce. The legs and mounting hardware are in the accessory box shipped with each speaker. -
Page 5: Speaker Distance
how to plaCe YouR SpeakeR SYStemS front Speaker Separation The distance between the front speakers in a dedicated music system, or an A/V system, deter- mines the width of the stereo image. If the speakers are placed too close together, the image will be too narrow;... -
Page 6: Connecting The Speakers
However, if speakers are too close to the room boundaries, particularly corners, the bass output can be uneven. Furthermore, the B7, C7 and D7 should be placed at least 18-inches (0.5m) from the wall behind them so the bass port and rear tweeter will perform properly. - Page 7 Unscrew the of terminals and remove the Woofer jumper straps between the woofer and tweeter or, on the B7 and C7, between the woofer and midrange. When making connections, be sure to connect + to + (red) and - to - (black).
-
Page 8: Control Settings
Repeat steps 2 and 3 for the second amplifier tri-wiring and tri-amplifying The B7 and C7 have three sets of terminals—one each for the tweeter, midrange and woofer. You can tri-wire the speakers, although the performance improvement will be minor and it can be difficult to connect three wires to the ampifier terminals. -
Page 9: Listening Levels And Power Handling
Switch The B7, C7 and CR70 have a three position switch to adjust the output level of the tweeter. In most rooms, the “Flat” position will produce the best sound. In rooms that have plush carpet- ing, heavily upholstered furniture and other sound absorbing furnishings, try the switch in the “Boost”... -
Page 10: Limited Warranty
For five years from the date of purchase, Snell Acoustics will repair for the original owner any defect in materials or workmanship that occurs in normal use of the speaker system, without charge for parts and labor. Your responsibilities are to use the product according to the instructions supplied, to provide... - Page 12 300 Jubilee Drive, P.O. Box 3717 Peabody, MA 01961-3717 ©2009 Snell Acoustics. All Rights Reserved. phone: 978-538-6262 Specifications are subject to change without notice. fax: 978-538-6266 Covered by patents issued and/or pending. email: info@snellacoustics.com Part #542-1040 www.snellacoustics.com...
