Summary of Contents for Snell CR7

  • Page 1 Owner’s Manual...

  • Page 2: Specifications

    The CR7 is a high-performance extruded aluminum D’Appolito Array for use wherever space is limited and in a wide variety of applications. The CR7 is a two-way design with a complex crossover for best sound quality. This two-way monitor uses a 1-inch soft dome tweeter and dual 4-inch bass units.

  • Page 3: Stereo Image

    We advise using a tape measure to equalize these two distances to the primary the cR7 was designed to have the optimum listening position. The payoff will be well worth balance when close to one boundary surface. the time and effort.

  • Page 4: Bracket Mounting

    3. Line-up bracket to speaker back groove so that the two brackets interlock. The bracket slots into the back of the CR7 to preserve its appearance. note: Use the four toggle bolts supplied for mounting to plaster board. Any smaller inserts will not be sufficient to hold its weight.
  • Page 5 HoW to MoUnt YoUR cR7 (continued) Bracket Mounting Horizontal Mounting to Wall (as an center channel): 1. Remove factory mounted bracket off from back of speaker, 2. Block the cabinet two holes with the bracket screws. 3. Attach & level both brackets to wall using appropriate hardware supplied. 4. Attach speaker wires to speaker terminals in the back of the speaker.

  • Page 6: Connecting The Speakers

    connectinG tHe SpeaKeRS connecting to a choosing cable We recommend 16-gauge cable or thicker for Surround processor runs up to 25 feet (8m) and 12-gauge wire or thicker for longer runs. When using a powered subwoofer: Select the SMALL or NORMAL setting on your connecting with bare wire: receiver or processor for your main and center Insert bare wire into holes and tighten. channels. This routes all bass information (typically below 120Hz) to your subwoofer. connecting with banana plugs, spade lugs, or pins: When not using a powered subwoofer: The binding posts accept standard banana Select the LARGE setting on your receiver or plugs and pins, and can accommodate spade processor for your main speakers. This routes lugs up to ¼ inch. all bass information (typically below 120Hz) to your main speakers.

  • Page 7: Listening Levels And Power Handling

    Your responsibilities are to use the product according to the instructions supplied, to provide safe and secure transportation to an authorized Snell Acoustics service representative, and to present proof of purchase from an authorized Snell dealer in the form of your sales slip when requesting service.
  • Page 8 300 Jubilee Drive Peabody, MA 01960 phone: 978-538-6262 ©2007 Snell Acoustics. All Rights Reserved. Specifications fax: 978-538-6266 are subject to change without notice. Covered by patents email: info@snellacoustics.com issued and/or pending. www.snellacoustics.com Part #542-1032...
