Parts and Functions

Operation

CLOCK
Used to set correct time.
TIMER
Used to select
TIMER ON,
TIMER OFF,
TIMER ON/OFF.
TIME
Used to set clock and
timer setting.
Power ON/OFF
Used for unit start and
stop.
Cautions:
On cooling only unit, heating
mode is not available.
Buttons and display of the wire controller.
Note:
The above information is the explanation of
the displayed information therefore varies
with those displayed in actual operation.
7
MODE
Used to select AUTO
RUN, COOL, DRY,
HEAT and FAN
operation.

FAN SPEED

Used to select fan
speed: LO, MID, HI,
AUTO
TEMP
Used to select your
desired temp.
SET
Used to confirm Timer
and Clock settings.
SLEEP
Used to select sleep
mode.
