  • Page 1 10 to 13 SEER 1.5 to 5 Tons Models: HC18-60A1VAR/S HC18-60C1VAR HC18-60D1VAR No.0010572324 The information contained in this booklet is subject to change without notice.
  • Page 2 (other than those authorized by the manufacturer) into, onto, or in conjunction with the air conditioner. You should be aware that the use of unauthorized components, accessories or devices may adversely affect the operation of the air conditioner and may also endanger life and property.
  • Page 3: Table Of Contents

    9.3.Wiring diagram ----------------------------------------------------------------------------- 1.INTRODUCTION This manual contains the installation and operating instructions for your new air conditioner. Improper installation can result in unsatisfactory operation or dangerous conditions. Carefully read this manual and any instructions packaged with separate equipment required to make up the system prior to installation.
  • Page 4: Specification

    3.SPECIFICATION The dimensions for the condensing unit are illustrated in Figure 1. Physical and electrical specifications are provided in Table 1 for 10 SEER systems respectively. Table 1: Model:HC18-60A1VAR/S...
  • Page 5 Table 2:System Cooling Capacity Outdoor Unit With This Indoor Air handler Air Handler Model Number HC18A1VAR HB2400VA1M20 HC24A1VAR HB2400VA1M20 HC30A1VAR HB3000VA1M20 HC36A1VAS HB3600VA1M20 HC42A1VAR HB4200VA1M25 HC48A1VAR HB4800VA1M25 HC60A1VAR HB6000VA1M25 The dimensions for the condensing unit are illustrated in Figure 1. Physical and electrical specifications are provided in Table 3 for 12 SEER systems respectively.
  • Page 6 Table 4:System Cooling Capacity Outdoor Unit Model Number Air Handler HC18C1VAR HB2400VC1M20 HC24C1VAR HB2400VC1M20 HC30C1VAR HB3600VA1M20 HC36C1VAR HB3600VC1M25 HC42C1VAR HB4800VA1M25 HC48C1VAR HB4800VA1M25 HC60C1VAR HB6000VC1M25 The dimensions for the condensing unit are illustrated in Figure 1. Physical and electrical specifications are provided in Table 5 for 13 SEER systems respectively. Table 5: Model:HC18-60D1VAR MODEL:...
  • Page 7: Unit Inspection

    4.UNIT INSPECTION This product has been inspected at the factory and released to the transportation agency without known damage. Inspect exterior of carton for evidence of rough handling in shipment. Unpack carefully. If damage is found, report immediately to the transportation agency. 5.EQUIPMENT PROTECTION FROM ENVIRONMENT The metal parts of the unit may be subject to rust or corrosion in adverse environmental conditions.
  • Page 8: Unit Clearances

    Provide a level concrete slab. To prevent transmission of noise or vibration, slab should not be connected to building structure. Some sort of sound-absorbing material should be placed between the condenser and the slab. A good material to use is rubber and cork pad. For rooftop application, make sure the building construction can support the weight and that proper consideration is given to the weather-tight integrity of the roof.
  • Page 9: Line Insulation

    PITCH SUCTION LINE TOWARD OUTDOOR UNIT 1/2" FRO EVERY 10' OF LINE OUTDOOR UNIT LIQUID LINE INVERTED LOOP LIQUID LINE INDOOR UNIT OUTDOOR UNIT SUCTION LINE Only refrigeration-grade copper piping (dehydrated and sealed) should be used. Take extreme care to keep the refrigerant tubing clean and dry prior to and during installation.
  • Page 10 Refrigerant Line Sizing Check the following table (Table 7) for correct suction and liquid line sizes for any combination of the unit size and the maximum refrigerant line length. Unit Size 0 - 24 (Ton) Suction The factory charge is sufficient for 25 feet of standard liquid line. For longer or shorter liquid line lengths, adjust the charge as follows: 1/4"...
  • Page 11 1.Tubing should be cut square. Make sure it is round and free of burrs at the connecting ends. Clean the tubing to prevent contamination from entering the system. 2.Make sure that both refrigerant stop valves at the outdoor unit are closed. 3.Push the tubing into the fitting until it stops.
  • Page 12: Electrical Wiring

    1.Fully open both shutoff valves. 2.Connect service gage manifold to the valve service ports, being sure to evacuate lines. 3.Startup the system (Refer to the Section 7 - "System Startup"). Run system at least 10 minutes to allo pressure to stabilize. 4.Temporarily install thermometer on suction (large) line near condensing unit.
  • Page 13: System Startup

    The condensing unit rating plate and the tables of "Physical and Electrical Specifications / Outdoor Units" (Table 1 and 2) provide pertinent data necessary for the selection of proper size electrical service and over-current protection devices. Table 9 provides data on the minimum copper wire size as a function of supply wire length and circuit ampacity.
  • Page 14: Operation

    8.OPERATION Most single phase units are operated without start relay or start capacitor. Such systems should be off for a minimum of 5 minutes before restarting to allow equalization of pressures. The thermostat should not be moved to cycle unit without waiting 5 minutes. To do so may cause the compressor to stop on an automatic open overload device or blow a fuse.
  • Page 15 Symptom Possible Cause Power off or loose electrical connection Incorrect thermostat setting No cooling Defective contactor Open circuit breaker of blown fuses Defective transformer Interconnecting low voltage wiring damage Replace thermostat wiring Dirty filters Indoor air blockage Blocked outdoor coil Improperly sized unit Insufficient Cooling Improper airflow Incorrect refrigerant charge...
  • Page 16 HC18-60A1VAR/S HC18-60C1VAR HC18-60D1VAR Air Conditioner Wi ri ng Diagram 208/230V 60Hz 1PH Compress or Prot ect 3 Min. Time Delay Opt ion al Low & High Pressur e Switches COMPRESSOR 24VAC COMMON 1) Confi rm sy stem selec tion. Opti onal com ponents m ay be field or factory installed.
