JBL SCS135 Owner's Manual

Surround cinema speakers
Hide thumbs Also See for SCS135:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
S P E C I F I C A T I O N S
SCS135 System
Frequency Response
35Hz – 20kHz (–6dB)
Satellites
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
86dB @ 1 watt/1 meter
Tweeter
One 1/2" titanium-laminate
dome, video-shielded
Midrange
One 3" driver, video-shielded
Dimensions (H x W x D)
4-3/8" x 3-3/16" x 3-3/4"
111mm x 81mm x 95mm
Weight
1.1 lb/0.5kg
All features and specifications are subject to change without notice.
* Dolby and Pro Logic are trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
O W N E R ' S G U I D E
P R O D U C T L I N E :
Surround Cinema Speakers
M O D E L
SCS135
N U M B E R :
D E S I G N G O A L : Bring the thrill of live performance and movie sound to
the home environment by calling on JBL's professional engineering leadership.
S A T E L L I T E T Y P E : Titanium-laminate-dome tweeter, sealed enclosure
S U B W O O F E R T Y P E : Bass-reflex enclosure
P O R T D E S I G N : FreeFlow™ flared
P R O F E S S I O N A L R E F E R E N C E : Cinema Loudspeaker Series
Center
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
86dB @ 1 watt/1 meter
Tweeter
One 1/2" titanium-laminate
dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
3-1/4" x 7-5/8" x 3-3/4"
83mm x 194mm x 95mm
Weight
1.89 lb/0.86kg
Subwoofer
Amplifier
100 watts RMS
Bass
8" woofer, bass-reflex
enclosure
Dimensions (H x W x D)
15" x 13" x 14"
381mm x 330mm x 356mm
Weight
30 lb/13.6kg
P R O S O U N D
C O M E S H O M E
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No. ai5146
™

Advertisement

Table of Contents
loading

Related Manuals for JBL SCS135

Summary of Contents for JBL SCS135

  • Page 1 D E S I G N G O A L : Bring the thrill of live performance and movie sound to www.jbl.com the home environment by calling on JBL’s professional engineering leadership. S A T E L L I T E T Y P E : Titanium-laminate-dome tweeter, sealed enclosure ©2001 JBL, Incorporated.
  • Page 2 D E S I G N G O A L : Bring the thrill of live performance and movie sound to the home environment by calling on JBL’s professional engineering leadership. S A T E L L I T E T Y P E : Titanium-laminate-dome tweeter, sealed enclosure S U B W O O F E R T Y P E : Bass-reflex enclosure P O R T D E S I G N : FreeFlow™...

  • Page 3: R E A D T H I S

    R E A D T H I S ! I m p o r t a n t S a f e t y P r e c a u t i o n s ! ventilation is provided or the extreme care should be taken to keep from CAUTION manufacturer’s instructions have been...
  • Page 4 T H A N K Y O U F O R C H O O S I N G J B L For more than 50 years, JBL every note of enjoyment that us to keep you posted has been involved in every you expected –...

  • Page 5: Speaker Placement

    S P E A K E R P L A C E M E N T Center-Channel Front Speakers Speaker Subwoofer Surround Speakers The front speakers should be by screwing the leg in to The low-frequency material placed the same distance angle the speaker up, or reproduced by the from each other as they are...

  • Page 6: Mounting Options

    M O U N T I N G O P T I O N S Satellites and Surrounds On the wall. Wall brackets On shelves. On optional stands (FS300). are included. Wall-Mounting Attach plate to wall. The Slide speaker onto support. Place speaker and brackets should be placed, support on wall plate.

  • Page 7: Speaker Connections

    Most manu- stereo image. facturers of speakers and With the advent of electronics, including JBL, multichannel surround- use red to denote the (+) sound systems, connecting terminal and black for the all of the speakers in your (–) terminal.

  • Page 8: Dolby Pro Logic

    Dolby Pro Logic (Non-Digital) – Speaker Level Use this installation method for Dolby Pro Logic appli- – – – cations (not Dolby Digital, ® or other digital processing), where the receiver/processor does not have a subwoofer output, or Subwoofer a volume-controlled preamp (line-) level output: HIGH LEVEL Connect your receiver or...

  • Page 9: Dolby Pro Logic (Non-Digital) - Line Level

    Dolby Pro Logic (Non-Digital) – Line Level Use this installation method Use RCA-type patch cords Pro Logic processors. Note: If for Dolby Pro Logic appli- to connect the line-level your receiver or amplifier only cations (not Dolby Digital, DTS subwoofer outputs on your has one subwoofer output or other digital processing), receiver or amplifier to the...

  • Page 10: Operation

    • to the “ ” (On) position to use the subwoofer will be in position, the subwoofer will the subwoofer. The SCS135 standby mode. When the sub- remain on, whether or not subwoofer will automatically woofer senses an audio signal, program material is playing.

  • Page 11: Troubleshooting

    T R O U B L E S H O O T I N G If there is no sound from any • If your receiver/processor is If there is no sound from of the speakers: set in Dolby Pro Logic mode, the surround speakers: •...
  • Page 12 Staple sales invoice here.
