GS116E IG_20sept2012.fm Page 1 Thursday, September 20, 2012 9:59 AM
Installation Guide
ProSafe Plus 16-Port Gigabit Switch GS116E
Step 1. Connect equipment
Computer
Server
GS116E
Optional router
Step 2. Connect power
Internet
Optional
modem
Step 3. Check status
Power LED
Port LEDs
On
1000 Mbps link
(both LEDs)
Off
100 Mbps link
(left LED
10 Mbps link
(right LED
Activity (blinking)
No link (off)
Advertisement
Related Manuals for NETGEAR ProSafe Plus GS116E
Summary of Contents for NETGEAR ProSafe Plus GS116E
- Page 1 GS116E IG_20sept2012.fm Page 1 Thursday, September 20, 2012 9:59 AM Installation Guide ProSafe Plus 16-Port Gigabit Switch GS116E Step 1. Connect equipment Step 2. Connect power Step 3. Check status Internet Computer Server Power LED Port LEDs 1000 Mbps link (both LEDs) Optional 100 Mbps link...
-
Page 2: Specifications
NETGEAR reserves the right to make changes to the products described in this document without notice. their respective holders. © NETGEAR, Inc. All rights reserved. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit For indoor use only in all EU countries and Switzerland.
