Tripp Lite SU16000RT4U Owner's Manual

Smartonline hot-swappable modular uos systems
Hide thumbs Also See for SU16000RT4U:
Table of Contents

Advertisement

Quick Links

Owner's Manual
smartOnline
important safety Warnings
Features
Mounting
Connection
Optional Connection
Operation
Manual Bypass Procedure
storage/service
Warranty/Warranty registration
español
Français
™
Modular UPs systems
Models: sU16000rt4U and sU16000rt4UHW
Not suitable for mobile applications.
1111 W. 35th Street, Chicago, IL 60609 USA
(773) 869-1234
Copyright © 2008 Tripp Lite. All rights reserved. SmartOnline™ is a trademark of Tripp Lite.
Hot-swappable
2
3
7
8
9
10
15
17
17
18
35

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite SU16000RT4U

Summary of Contents for Tripp Lite SU16000RT4U

  • Page 1 Warnings Features Mounting Connection Optional Connection Operation Manual Bypass Procedure storage/service Warranty/Warranty registration español Français 1111 W. 35th Street, Chicago, IL 60609 USA (773) 869-1234 Copyright © 2008 Tripp Lite. All rights reserved. SmartOnline™ is a trademark of Tripp Lite.

  • Page 2: Important Safety Warnings

    • Do not operate the UPS without connecting the power module to an external battery module. • Connect only Tripp Lite battery packs to the battery connectors. Connect battery packs of the correct voltage and type. • The internal batteries in the battery pack are recyclable. Refer to local codes for disposal requirements, or in the USA call 800-SAV-LEAD (800-728-5323) or 800-8-BATTERY (800-822-8837), or go to www.rbrc.com for complete recycling information.

  • Page 3: Front Control Panel

    Features Front Control Panel BYPASS BATTERY AC/DC DC/AC MUTE SELECT SETUP LCD Display: This backlit dot matrix display indicates a wide range of UPS operating conditions and diagnostic data. It also displays UPS settings and options when the UPS is in setup mode. “ON/MUTE”...

  • Page 4: Power Module

    Serial and USB Ports: These serial (RS-232 DB9) and USB ports enable optional connection of the UPS to corresponding ports on a workstation or server. When the UPS system is connected to a computer via the included serial or USB cable, Tripp Lite's PowerAlert Software can be used to monitor and control the UPS system.
  • Page 5 BYPASS, but the equipment will not receive battery power in the event of a power failure. See the “Manual Bypass Procedure” section for detailed manual bypass instructions. An optional PDU with hardwire output is also available from Tripp Lite. Call (773) 869-1234 or go to www.tripplite.com for more information on available PDU options. Reverse View...
  • Page 6 External Battery Pack Connectors: Use these connectors to connect the battery pack to the power module and to daisy-chain additional Tripp Lite external battery packs with the main external battery pack for extended runtime. (Daisy-chaining additional battery packs is optional.) Remove the retention bracket(s) for access (the diagram shows the upper bracket removed). Check to ensure that the external battery pack you are connecting matches the voltage listed next to the battery connector.

  • Page 7: Mounting (Tower)

    Mounting Mounting (4-Post rackmount) The UPS includes rackmount shelf kits for 4-post rackmounting. The user must determine the fitness of hardware and procedures before mounting. If hardware and procedures are not suitable for your application, contact the manufacturer of your rack or rack enclosure. The procedures described in this manual are for common rack and rack enclosure types and may not be appropriate for all applications.

  • Page 8: Connection

    Input Maximum Rated Maximum Rated Typical Model Voltage Input Current Output Current Wire Size SU16000RT4U 100-140V (L1-N: L2-N) 4 AWG SU16000RT4UHW 100-140V (L1-N: L2-N) 4 AWG Contacts on Power Module and PDU Warning! High Voltage! risk of electrical shock! Do not let these contacts touch any surface! see "Manual Bypass Procedure"...

  • Page 9: Optional Connection

    Remove the slot's cover to install an optional internal SNMP/Web accessory card (Model: SNMPWEBCARD) to enable remote UPS monitoring and control via SNMP, Web or telnet. Contact Tripp Lite Customer Support at (773) 869-1234 for more information, including a list of available SNMP, network management and connectivity products.

  • Page 10: Operation

    If a problem is detected during the self-test, the LCD will display an error message. If your UPS displays any of the following messages in its LCD, call Tripp Lite Technical Support at (773) 869-1234 for service. LCD Screen Messages...

  • Page 11: Normal Operation

    Operation (continued) normal Operation During normal operation, the first line of your LCD Display shows which operating mode your UPS is in: “UPS MODE”, “ON BATTERY MODE”, “BYPASS MODE” or “STANDBY MODE”. “UPS MODE”: The UPS provides AC power while utility power is available and switches to ON BATTERY MODE instantly (zero transfer time) if AC power is interrupted.

  • Page 12: Configuration Menu

    Operation (continued) Configuration Menu The UPS output voltage is set at 208/120V~ when the UPS is shipped from the factory. In order to change the output voltage of the UPS, you first need to enter “ON BATTERY MODE” by cold-starting the UPS. (The battery must be at least partially charged for this operation to succeed.) If the UPS is on, press and hold the “OFF”...
  • Page 13 Operation (continued) Overload Messages When the UPS detects an output overload, its LCD will switch to the following display: OVERLOAD! LOAD1 = XXX% X.XKW OVERLOAD! LOAD2 = XXX% X.XKW The UPS will then begin a countdown. If the UPS is still overloaded at the end of the countdown, the UPS will automatically go to BYPASS MODE to protect its inverter.

  • Page 14: Shutdown Messages

    Operation (continued) shutdown Messages Your UPS will shut down and the LCD will display a message if it detects one of the following conditions. Note: During all these conditions, the “Input,” “Output” and “Bypass” LEDs will be illuminated. Shutdown Conditions LCD Screen Messages Shutdown Conditions LCD Screen Messages...

  • Page 15: Manual Bypass Procedure

    Note: An optional hardwire output detachable PDU is also available. Contact Tripp Lite for details. (Optional: During a hot-swap, the PDU can be housed in the back of the rack configuration using supplied PDU hanger brackets and hardware.
  • Page 16 Manual Bypass Procedure (continued) Warning! High Voltage! risk of electrical shock! see BeLOW. see warning statements below! step 6 step 7 step 7 High Voltage Warnings Contacts on Power Module Contacts on Detachable PDU Warning! Warning! High Voltage! High voltage! risk of electrical shock! risk of electrical shock! When the external battery pack is connected to the...

  • Page 17: Warranty Registration

    USA and Canada, 1 year) from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite; 1111 W.

This manual is also suitable for:

Su16000rt4uhw
