Tripp Lite SmartOnline SU1500XL Specifications

Model #: SU1500XL
SmartOnline 1.5kVA On-Line Double-Conversion UPS, Tower, 100/110/120V NEMA outlets
Description
Tripp Lite's SmartOnline SU1500XL on-line, double conversion UPS protects critical server, networking or telecommunications equipment from
blackouts, brownouts, voltage fluctuations and surges. Large-capacity 1.5kVA/1200W UPS continuously converts incoming AC to DC, then back to
perfect sine wave AC output at 120V AC (+/-2%). Removes harmonic distortion, fast electrical impulses, frequency fluctuations and other
hard-to-solve power problems not addressed by other UPS systems. True sine wave output and zero transfer time provides guaranteed compatibility
with all equipment types. Highly efficient operation in optional economy mode setting, saving BTU heat output and energy costs. Includes 6
UPS-supported outlets. 2 load banks, each with 3 outlets, can be independently controlled via a software interface to selectively reboot remote
equipment or automatically shed less critical loads to extend battery runtime for the most critical equipment. Battery backup time can be extended
with the addition of multiple external battery packs. Includes slot for internal SNMP/web card, plus DB9 enhanced serial monitoring port for
unattended shutdown, remote control and monitoring of UPS system and power data. HID-compliant USB interface enables integration with built-in
power management and auto shutdown features of Windows and Mac OS X. Includes Tripp Lite's PowerAlert UPS Power Management Software.
Compatible with Tripp Lite's Watchdog Service Monitoring/Rebooting Software. Attractive all-black upright tower format. $250,000
Insurance
Package Includes
SU1500XL UPS System
PowerAlert Software
USB, DB9 and EPO cabling
Owner's manual with warranty information
Features
True on-line, double conversion UPS provides constant, pure sine wave AC output
Zero transfer time, on-line, double-conversion and economy-mode operation supported
Maintains continuous operation through blackouts, brownouts, voltage fluctuations and surges with zero transfer time
Removes harmonic distortion, electrical impulses, frequency variations and other hard-to-solve power problems
Accepts input voltages between 80V and 150V (65V to 150V at loads under 70%), regulating output to 120V AC +/-2%
1500VA/1200W output capacity with 6 NEMA 5-15R outlets
Two built-in, individually switchable load banks, each with 3 outlets, can be controlled via software interface to selectively reboot remote
equipment or automatically shed less critical loads to extend battery runtime for the most critical equipment
Highlights
1500VA / 1.5kVA / 1200 watt on-line double-conversion tower UPS
110/120V +/-2% output at 50/60Hz, high efficiency economy mode option
Expandable runtime, Hot-swappable battery modules
USB, RS232 & EPO ports; support for SNMP/WEB card options
Front panel status LEDs with detailed load and battery metering
2 independently switchable output load banks
NEMA 5-15P input; 5-15R outlets
