EnGenius ERB9250 Specifications

ERB9250
> HARDWARE SPECIFICATIONS
MCU
Memory
Flash
PCB dimension
Physical Interface
LEDs Status
Power Requirements
ERB9250 Datasheet Version 19062009
*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g, n chipset used. Actual throughput may vary.Network conditions and environmental
factors lower actual throughput rate.
** All specifications are subject to change without notice
PRODUCT DESCRIPTION
ERB9250 is a 2.4GHz 802.11b/g/n 300Mbps Repeater & Client Bridge
(Range Booster / Extender). Range Extender solves the signal attenuation
(limited coverage) problem by literally repeating / extending AP radio
signal to dead-spots. While repeater clones AP and serves as a
subsidiary entity to its clients, client bride offers an extension of wired
network to the AP.
PACKAGE CONTENT
 1* 802.11n SOHO Router (ESR-9250)
 1* 12V/1A Power Adapter
 1*QIG
 1*CD (User's Manual)
TECHNICAL SPECIFICATION
RT3052, 384MHz embedded RF/MAC/BBP
32MB SDRAM
4MB
100mm * 90mm
Ethernet: One 10/100 Fast Ethernet RJ-45
Rest button
Power Jack
Power Status
LAN (Internet connection)
WLAN(Wireless connection)
Power Supply: 200 to 240 VDC ± 10％ (ETSI) 100 to 120 VDC ± 10％ (FCC)
Device: 12V/1A
Learn more about EnGenius Solutions at www.engeniustech.com.sg
802.11b/g/n Range Extender
• 2.4 GHz
• 300Mbps
• 11N Repeater/
client bridge
HOME AND HOME OFFICE
ERB9250
