Quick Manual Configuration

Plug ERB9260 into power outlet.

Disable or turn off any wireless connections present on the

computer being used to configure the Range Extender before

setting up ERB9260.

Connect one end of the supplied Ethernet cable to the

Ethernet/RJ45 connector on the top of the Range Extender

and the other end to Ethernet port on your PC/ laptop.

Open a web browser and enter the default IP Address of the Range Extender

http://192.168.1.2

Click Scan Now and you will see all of the wireless networks in the range of the ERB9260.

Select the target router and click Connect

Quick Install Guide

Thank you for choosing EnGenius.

Page 1 Open a web browser and enter the default IP Address of the Range Extender http://192.168.1.2 Click Scan Now and you will see all of the wireless networks in the range of the ERB9260. Select the target router and click Connect...
Page 2 The connection is established successfully between your AP/Router and ERB9260. Now the ERB9260’s SSID is identical to with the router’s SSID. Note: Remove the Ethernet cable from ERB9260 and the computer and enable your wireless interface before using. Thank you for choosing EnGenius.
Page 3 Note: It takes up to 60 seconds for ERB9260 to clone your router. Once the WPS LED stops blinking and stays ON, the setup is complete. If the WPS LED does not stay ON, the configuration is not successful. In this case: ⇒...
Page 4: Troubleshooting
Cannot access the Internet after successfully setup ERB9260 with your router If you could not wirelessly connect to the Internet after you set up ERB9260 completely, you can: 1. Make sure you can access to the Internet over your AP/Router with ERB9260 turned off.
