  • Page 1 300Mbps Wireless N Range Extender ERB9260 300Mbps Wireless N Range Extender V1.3...

  • Page 2: Table Of Contents

    Table of Contents Package Contents ................................4 Introduction ..................................4 Hardware Overview ................................5 Before you Begin ................................7 Considerations for Wireless Installation ..............................7 Computer Settings (Windows XP/Windows Vista/Windows 7) ...................... 8 Apple Mac X OS ......................................12 Hardware Installation ..............................13 Configuring Range Extender ............................
  • Page 3 Security (Repeater mode) ..................................45 Filter (Repeater mode) ....................................48 WPS ............................................ 50 Client List (Repeater mode) ..................................54 AP Profile .......................................... 55 Network ..................................57 10.1 Status ..........................................57 10.2 LAN ............................................. 58 10.3 WAN (Client Router mode) ..................................60 10.3.1 Static IP Address .......................................
  • Page 4 12.7 Quality of Service (QoS) ....................................78 12.8 Static Routing ......................................... 81 12.9 Dynamic Routing ......................................82 12.10 Routing Table ......................................83 Management ................................84 13.1 Admin ..........................................84 13.2 Firmware ........................................... 85 13.3 Configure ......................................... 88 13.4 Reset ..........................................89 Tools ....................................

  • Page 5: Package Contents

    It supports latest industrial standard security settings WEP, WPA & WPA2. ERB9260 offers an easy way to extend your wireless AP coverage without changing IP address settings. It is truly user friendly network gear for home users.

  • Page 6: Hardware Overview

    3 Hardware Overview RJ45 On/Off Switch This is RJ45 LAN port. You can manually turn on/off the device using this slide switch. LAN: Connect to a computer, switch or hub. O: Off I: ON...
  • Page 7 LED Lights icon Description Color – Blue Wireless LAN Lights when Wireless signal is activated. Blinks when Wireless data transfer. Color – Blue Blinks when WPS handshake is initialized. Color – Blue Lights when wired network device is connected to RJ45 port. Blinks when data transfer occurs on RJ45 port.

  • Page 8: Before You Begin

    Here are some key guidelines to ensure that you have the optimal wireless range. 1. Keep the number of walls and ceilings between the EnGenius access point and other network devices to a minimum. Each wall or ceiling can reduce the signal strength, the degradation depends on the building’s material.

  • Page 9: Computer Settings (Windows Xp/Windows Vista/Windows 7)

    Computer Settings (Windows XP/Windows Vista/Windows 7) This device can be configured as a Repeater, Client Bridge and Client Router. The default IP address of the device is 192.168.1.2 (In Repeater Mode as default). In order to log into this device, you must first configure the TCP/IP settings of your PC/Notebook.
  • Page 10  Windows XP, click [Network Connection]  Windows Vista, click [View Network Status and Tasks] then [Manage Network Connections]  Windows 7, click [View Network Status and Tasks] then [Change adapter settings]...
  • Page 11  Right click on [Local Area Connection] and select [Properties].  Check “Client for Microsoft Networks”, “File and Printer Sharing for Microsoft Networks”, and “Internet Protocol (TCP/IP)” is ticked. If not, please install them.
  • Page 12  Select “Internet Protocol (TCP/IP)” and click [Properties]  Select “Obtain an IP Address automatically” and “Obtain DNS server address automatically” then click [OK].

  • Page 13: Apple Mac X Os

    Apple Mac X OS  Go to System Preferences > Network  Under Network setting, select Using DHCP.  Click Apply when done.

  • Page 14: Hardware Installation

    5 Hardware Installation Power On: Use the AC Power cord to connect the device and outlet or any other power supplies to provide the electricity to the device. Make sure On/Off switch is on the right side where the symbol indicates “I”.
  • Page 15 Connect the network cable to the RJ45 port. Switch/Hub or PC/Laptop...

  • Page 16: Configuring Range Extender

    6 Configuring Range Extender This section will show you how to configure the device using the web-based configuration interface. Please use your wireless network adapter to connect the Range Extender. Default Settings IP Address 192.168.1.2 Username / Password admin / admin Wireless Mode Enable Wireless SSID...

  • Page 17: Quick Setup Range Extender

    Plug ERB9260 into power outlet. Disable or turn off any wireless connections present on the computer being used to configure the Range Extender before setting up ERB9260. Connect one end of the supplied Ethernet cable to the Ethernet/RJ45 connector on the top of the Range Extender and the other end to Ethernet port on your PC/ laptop.
  • Page 18 Click Scan Now and you will see all of the wireless networks in the range of the ERB9260. Select the target router and click Connect Enter the password if your target router is encrypted. Click Connect.
  • Page 19 The connection is established successfully between your AP/Router and ERB9260. Now the ERB9260’s SSID is identical to with the router’s SSID. Note: Remove the Ethernet cable from ERB9260 and the computer and enable your wireless interface before using.

  • Page 20: One-Touch Setup (Wps)

    One-Touch Setup (WPS) 1. Click [WPS] button on ERB9260...
  • Page 21 2. Click [WPS] button on the Access Point. Note: It may take up to 60 seconds for ERB9260 to clone the AP. Please wait until WPS led stops blinking and stay ON.  If the connection is successful. There will be TWO HomeAP in the environment.
  • Page 22 3. Please rescan the APs and reconnect to the HomeAP closest to you. Your wireless card should pick up the AP with strongest signal as you roam. Note: To re-configure the extender you can enter http://erb9260 to enter the WEB configurator or reset the extender to default by press the WPS button for 15 seconds.

  • Page 23: System

    Expert Mode 8 System Operation Mode Each of the operating modes offers different features. In order to switch the operating mode, select it from the System >> Operation Mode. There are three operation modes: Repeater, Client Bridge and Client Router. A dialog box will appear to notify you that the system will restart in order for the change to take effect.

  • Page 24: Status

    Status This page allows you to monitor the status of the device. System Operation Mode The device is currently in which mode. System Time The device’s system time. If this is incorrect, please set the time in the Tools / Time page. System Up Time The duration about the device has been operating without powering down or reboot.
  • Page 25 WLAN Repeater Information (Repeater mode) Connection Status The connection status: Successful or Fail. Channel The wireless channel in use. ESSID The SSID (Network Name) of the wireless network. Security Wireless encryption for this SSID. BSSID The MAC address of this SSID. Data Rate The Data Rate in use.
  • Page 26 WLAN Settings (Repeater mode) Channel The wireless channel in use. ESSID The SSID (Network Name) of the wireless network. Security Wireless encryption for this SSID. BSSID The MAC address of this SSID.
  • Page 27 WAN Settings (Client Router) Attain IP Protocol Method used to connect to the Internet. This is your WAN connection type. IP Address The WAN IP address of the Router. Subnet Mask The WAN subnet mask of the Router. Default Gateway The default gateway of the Router.
  • Page 28 WLAN Station Information (Client Bridge / Client Router mode) Connection Status The connection status: Successful or Fail. Channel The wireless channel in use. ESSID The SSID (Network Name) of the wireless network which ESR1221AN connected. Security The wireless encryption in use. BSSID The MAC address of this SSID which ESR1221AN connected.

  • Page 29: Dhcp (Client Router Mode)

    DHCP (Client Router mode) This page shows the status of the DHCP server and also allows you to control how the IP addresses are allocated.
  • Page 30 The DHCP Client Table shows the LAN clients that have been allocated an IP address from the DHCP Server. DHCP Client Table (Client Router mode) IP Address The LAN IP address of the client. MAC Address The MAC address of the client’s LAN interface. Expiration Time The time that the allocated IP address will expire.
  • Page 31 You can also manually specify the IP address that will be allocated to a LAN client by associating the IP address with its MAC address. Type the IP address you would like to manually assign to a specific MAC address and click Add to add the condition to the Static DHCP Table.

  • Page 32: Schedule (Client Router Mode)

    Schedule (Client Router mode) This page allows you to schedule times that the Firewall feature will be activated / deactivated. Click Add to create a Schedule entry.
  • Page 33 Schedule (Client Router mode) Schedule Description Assign a name to the schedule. Service Type of service Days Define the Days to activate or deactivate the scheduled service. Time of day Define the Time of day to activate or deactivate the scheduled service. Note: Use 24-hour clock format.

  • Page 34: Event Log

    Event Log This page displays the system log of the device. When powered down or rebooted, the log will be cleared. Save Save the log to a file. Clear Clears the log. Refresh Updates the log.

  • Page 35: Monitor

    Monitor This page shows a histogram of the Ethernet and Wireless LAN traffic. Click on [Detail] to get the detail information.

  • Page 36: Wireless

    9 Wireless Status This page shows the current status of the device’s Wireless settings. Repeater mode:...
  • Page 37 Client Bridge / Client Router mode:...

  • Page 38: Basic

    Basic This page shows the current status of the device’s Wireless settings. Repeater mode: Basic (Repeater mode) Radio Enable or Disable the device’s wireless signal. Band Select the types of wireless clients that the device will accept. eg: 2.4 Ghz (B+G) Only 802.11b and 11g clients will be allowed.
  • Page 39 Client Bridge / Client Router mode: Basic (Client Bridge / Client Router mode) Radio Enable or Disable the device’s wireless signal. Band Select the types of wireless clients that the device will accept. Site Survey Click on [Site Survey] to search the existing AP.
  • Page 40 Site Survey (Client Bridge / Client Router mode) AP list after site survey.
  • Page 41 Select an AP and click on [Add to AP Profile]. Enter the correct security setting.
  • Page 42 Add AP profile successfully, click on [Close] to close the browser. The AP profile is added in AP Profile Table.

  • Page 43: Advanced

    Advanced This page allows you to configure wireless advance settings. It is recommended the default settings are used unless the user has experience with these functions. Repeater mode:...
  • Page 44 Advanced (Repeater mode) Fragment Threshold Specifies the size of the packet per fragment. This function can reduce the chance of packet collision. However when this value is set too low, there will be increased overheads resulting in poor performance. RTS Threshold When the packet size is smaller than the RTS Threshold, then the packet will be sent without RTS/CTS handshake which may result in incorrect transmission.
  • Page 45 Client Bridge / Client Router mode: Advanced (Client Bridge / Client Router mode) Fragment Threshold Specifies the size of the packet per fragment. This function can reduce the chance of packet collision. However when this value is set too low, there will be increased overheads resulting in poor performance.

  • Page 46: Security (Repeater Mode)

    Security (Repeater mode) This page allows you to set the wireless security settings. Note: Only in Repeater mode. Security (Repeater mode) SSID Selection Select the SSID that the security settings will apply to. Broadcast SSID If Disabled, then the device will not be broadcasting the SSID. Therefore it will be invisible to wireless clients.
  • Page 47 WEP Encryption: WEP Encryption Authentication Type Please ensure that your wireless clients use the same authentication type. Key Length Select the desired option, and ensure the wireless clients use the same setting. 64 Bit - data is encrypted, using the default key, before being transmitted. You ...
  • Page 48 WPA Pre-Shared Key Encryption: WPA Pre-Shared Key Encryption WPA type Select the WPA encryption you would like. You can choose WPA(TKIP), WPA2(AES), WAP(AES) or WAP2(TKIP). Please ensure that your wireless clients use the same settings. Pre-shared Key Type Select whether you would like to enter the Key in HEX or Passphrase format. Pre-shared Key Wireless clients must use the same key to associate the device.

  • Page 49: Filter (Repeater Mode)

    Filter (Repeater mode) This page allows you to create filters to control which wireless clients can connect to this device by only allowing the MAC addresses entered into the Filtering Table. Note: Only in Repeater mode. Wireless Filter (Repeater mode) Enable Wireless MAC Tick the box to Enable Wireless Access Control.
  • Page 50 Reset Click this button if you have made a mistake and want to reset the MAC address and Description fields. MAC Address Filtering Table Only clients listed in this table will be allowed access to the wireless network. Delete Selected Delete the selected entries.

  • Page 51: Wps

    WPS feature is following the Wi-Fi Alliance WPS standard and it eases the set up of security-enabled Wi-Fi networks in the home and small office environment. It reduces the user steps required to configure a network and enable security. Wi-Fi Protected Setup (WPS) Tick to Enable the WPS feature.
  • Page 52 Step 1: Click [WPS] button on ERB9260.
  • Page 53 Step 2: Click [WPS] button on the Access Point Note: It may take up to 60 seconds for ERB9260 to clone the AP. Please wait until WPS led stops blinking and stay ON.  If the connection is successful, there will be TWO HomeAP in the environment.
  • Page 54 Step 3: Please rescan the APs and reconnect to the HomeAP closest to you. Your wireless card should pick up the AP with strongest signal as you roam.

  • Page 55: Client List (Repeater Mode)

    Client List (Repeater mode) This page shows the wireless clients that are connected to the device. Click on [Refresh] to get the latest user list and information update. Note: Only in Repeater mode.

  • Page 56: Ap Profile

    AP Profile This page allows you to configure the profile of the Client Bridge / Client Router including Security Setting exactly the same as the Access Point. You can save three AP profiles at most. Note: Only in Client Bridge and Client Router mode. AP Profile Table (Client Bridge / Client Router mode) Add / Edit Select a profile to add or edit.
  • Page 57 AP Profile Settings Network Name (SSID) Enter the SSID (Network Name) of the wireless network which ERB9260 want to connect. Encryption The encryption method to be applied. You can choose from Disable, WEP, WPA pre-shared key and RADIUS. Please select the correct security type.

  • Page 58: Network

    10 Network 10.1 Status This page shows the current status of the device’s LAN and WAN (Client Router mode) connection. Note: DHCP Server and WAN Settings are only in Client Router mode.

  • Page 59: Lan

    10.2 LAN This page allows you to modify the device’s LAN settings. The LAN setting in Client Router mode. There is additional setting Default Gateway in Repeater and Client Bridge mode. LAN IP Bridge Type Select Static IP or Dynamic IP from the drop-down list. If you select Static IP, you will be required to specify an IP address and subnet mask.
  • Page 60 DHCP Server feature is only in Client Router mode. DHCP Server (Client Router mode) DHCP Server Enable or disable DHCP feature. The DHCP Server automatically allocates IP addresses to your LAN device. Lease Time The duration of the DHCP server allocates each IP address to a LAN device. Start / End IP The range of IP addresses of the DHCP server will allocate to LAN device.

  • Page 61: Wan (Client Router Mode)

    10.3 WAN (Client Router mode) The WAN section allows you to manually set the WAN type connection and its related settings. Note: Only in Client Router mode. 10.3.1 Static IP Address If your ISP Provider has assigned you a fixed IP address, enter the assigned IP address, Subnet mask, Default Gateway IP address, and Primary DNS and Secondary DNS (if available) of your ISP provider.

  • Page 62: Dynamic Ip Address

    10.3.2 Dynamic IP Address The IP Address is allocated automatically. However some ISP’s will also recognize the MAC address and will reject connections if the MAC address does not match. If your ISP has recorded the MAC address of your computer’s Ethernet LAN card, please connect only the computer with the authorized MAC address, and click the Clone MAC button.

  • Page 63: Ppp Over Ethernet (Pppoe)

    10.3.3 PPP over Ethernet (PPPoE) This protocol is used by most DSL services worldwide. Select this option if you have a DSL connection. Enter the username and password provided by your ISP. PPP over Ethernet (PPPoE) Login Username assigned to you by the ISP Password Password for this username.

  • Page 64: Point-To-Point Tunneling Protocol (Pptp)

    10.3.4 Point-to-Point Tunneling Protocol (PPTP) PPTP is used by very few ISPs.
  • Page 65 Point-to-Point Tunneling Protocol (PPTP) WAN Interface Type Select whether the ISP is set to Static IP or will allocate Dynamic IP address. Hostname This is optional. Only required if specified by ISP MAC address The MAC Address that is used to connect to the ISP. Login Username assigned to you by the ISP Password...

  • Page 66: Firewall (Client Router Mode)

    11 Firewall (Client Router mode) The Firewall section allows you to set the access control and Firewall settings. Note: Only in Client Router mode. 11.1 Enable This page allows you to Enable / Disable the Firewall features. If enabled Firewall service, the Denial of Service (DoS) and SPI (Stateful Packet Inspection) features will also be enabled.

  • Page 67: Dmz

    11.2 DMZ If enabled this feature, allows the DMZ computer on your LAN to be exposed to all users on the Internet.  This allows almost any application to be used on the server.  The “DMZ PC” will receive all Unknown connections and data. ...

  • Page 68: Dos

    11.3 DoS Denial of Service (Denial of Service) is a type of Internet attack that sends a high amount of data to you with the intent to overload your Internet connection. Enable the DoS firewall feature to automatically detect and block these DoS attacks.

  • Page 69: Mac Filter

    11.4 MAC Filter You can choose whether to Deny or only Allow those computers listed in the MAC Filtering table to access the Internet. MAC Filter Enable MAC filtering Tick this box to Enable the MAC filtering feature. Deny all clients with MAC addresses When selected, the computers listed in the MAC Filtering table will be Denied listed below to access the network access to the Internet.

  • Page 70: Ip Filter

    11.5 IP Filter You can choose whether to Deny or only Allow, computer with those IP Addresses from accessing certain Ports. This can be used to control which Internet applications the computers can access. You may need to have certain knowledge of what Internet ports the applications use.
  • Page 71 IP Filter Enable IP filtering Tick this box to Enable the IP filtering feature. Deny all clients with IP addresses When selected, the computers with IP addresses specified will be Denied access to listed below to access the network the indicated Internet ports. Allow all clients with IP addresses When selected, the computers with IP addresses specified will be Allowed access listed below to access the network...

  • Page 72: Url Filter

    11.6 URL Filter You can deny access to certain websites by blocking keywords in the URL web address. For example, “gamer” has been added to the URL Blocking Table. Any web address that includes “gamer” will be blocked.

  • Page 73: Advanced (Client Router Mode)

    12 Advanced (Client Router mode) The Advanced section allows you to configure the Advanced settings of the router. Note: Only in Client Router mode. 12.1 Network Address Translation (NAT) This page allows you to Enable / Disable the Network Address Translation (NAT) feature. The NAT is required to share one Internet account with multiple LAN users.

  • Page 74: Port Mapping

    12.2 Port Mapping Port Mapping allows you to redirect a particular range of ports to a computer on your LAN network. This helps you host servers behind the NAT and Firewall. In the example below, there is a FTP Server that requires ports 21 to 22.

  • Page 75: Port Forwarding

    12.3 Port Forwarding Port Forwarding allows you to redirect a particular public port to a computer on your LAN network. This helps you host servers behind the NAT and Firewall. In the example below, there is a Web Server running on port 80 on the LAN.

  • Page 76: Port Triggering

    12.4 Port Triggering If you use Internet applications which use non-standard connections or port numbers, you may find that they do not function correctly because they are blocked by the Wireless Router's firewall. Port Triggering will be required for these applications to work. Port Triggering Enable Port Triggering Check this box to enable the Port Trigger feature.

  • Page 77: Application Layer Gateway (Alg)

    12.5 Application Layer Gateway (ALG) Certain applications may require the use of the ALG feature to function correctly. If you use any of the applications listed on the table below, select the feature and click Apply.

  • Page 78: Universal Plug And Play (Upnp)

    12.6 Universal Plug and Play (UPnP) The UPnP function allows automatic discovery and configuration of UPnP enabled devices on your network. It also provides automatic port forwarding for supported applications to seamlessly bypass the Firewall.

  • Page 79: Quality Of Service (Qos)

    12.7 Quality of Service (QoS) QoS allows you to control the priority that the data is transmitted over the Internet, or to reserve a specific amount of Internet bandwidth. This is to ensure that applications get enough Internet bandwidth for a good user experience. Priority Queue Sets the QoS method to Priority Queue.
  • Page 80 Priority Queue Method Bandwidth priority is set to either High or Low. The data transmissions in the High Priority queues will be processed first. Unlimited Priority Queue IP Address The computer with this IP Address will not be bound by the QoS rules. High / Low Priority Queue Protocol The type of network protocol.
  • Page 81 Bandwidth Allocation Method You can set the maximum amount of bandwidth a certain protocol will use at one time. Or you can set a minimum amount of bandwidth that will be guaranteed to a certain protocol. Bandwidth Allocation Type Set whether the QoS rules apply to transmission that are Download, Upload or Both directions. IP range Enter the IP address range of the computers that you would like the QoS rules to apply to.

  • Page 82: Static Routing

    12.8 Static Routing If your wireless router is connected to a network with different subnets, this feature will allow the different subnets to communicate with each other. Note: The NAT function needs to be disabled for the Routing feature to be enabled. Static Routing Enable Static Routing Check this box to enable the Static Router feature.

  • Page 83: Dynamic Routing

    12.9 Dynamic Routing Dynamic routing allows routing tables in routers to change as the possible routes change. This device use RIP to support dynamic routing.

  • Page 84: Routing Table

    12.10 Routing Table This page allows you to observe the current routing table.

  • Page 85: Management

    Enter your new password. Confirm Password Enter your new password again for verification. System Name The system name of this device. You can use this System Name to access your device. Ex. http://erb9260 Idle Timeout Enter Administration Page timeout time.

  • Page 86: Firmware

    13.2 Firmware This page allows you to upgrade the device's firmware. To perform the Firmware Upgrade: 1. Click the [Browse] button and navigate to the location of the upgrade file. 2. Select the upgrade file. Its name will appear in the Upgrade File field. 3.
  • Page 87 Emergency Upgrade If you upgrade fail, you may enter Emergency Upgrade WEB page. 1. Enter IP address: 192.168.1.2 and enter Emergency Upgrade WEB page. 2. Select [LOGIN] to enter firmware upgrade WEB page. 3. Click the [Browse] button and navigate to the location of the upgrade file and then click [UPLOAD].
  • Page 88 4. Wait for 100 seconds for firmware upgrade and reboot the device. 5. You can access the device again.

  • Page 89: Configure

    13.3 Configure This page allows you to save the current device configurations. When you save the configurations, you also can re-load the saved configurations into the device through the [Restore Settings]. If extreme problems occur you can use the [Restore to Factory Defaults] to set all configurations to its original default settings. Configure Restore to Factory Default Restores the device to factory default settings.

  • Page 90: Reset

    13.4 Reset In some circumstances it may be required to force the device to reboot. Click on [Apply] to reboot.

  • Page 91: Tools

    14 Tools 14.1 Time Setting This page allows you to set the system time. Time Time Setup Synchronize with the NTP Server or Synchronize with PC Time Zone Select the time zone for your current location. NTP Time Server Enter the address of the Network Time Protocol (NTP) Server to automatically synchronize with a server on the Internet.

  • Page 92: Dynamic Dns (Ddns) (Client Router Mode)

    14.2 Dynamic DNS (DDNS) (Client Router mode) This free service is very useful when combined with the Virtual Server (Port Forwarding) feature. It allows Internet users to connect to your Virtual Servers using a URL, rather than an IP Address. This also solves the problem of having a dynamic IP address.

  • Page 93: Diagnosis

    14.3 Diagnosis This page allows you to test your network. Type in the address for diagnosis. Diagnosis Address to Ping Enter the IP address you like to see if a successful connection can be made. Ping Frequency Select the frequency for Ping test. Ping Result The results of the Ping test.

  • Page 94: Wizard (Repeater Mode)

    15 Wizard (Repeater mode) This page allows you to go to Wizard Mode setting WEB page. Note: Only in Repeater mode. Wizard (Repeater mode) Reset the rang-extender to It will reset the device to factory default and go to Easy Setup WEB page again. factory default Keep the other advanced It allows you to go to Easy Setup WEB page again and keep the other settings.

  • Page 95: Logout

    16 Logout Click on [Logout] button to logout.

  • Page 96: Building A Wireless Network

    17 Building a Wireless Network With its ability to operate in various operating modes, your ERB9260 is the ideal device around which you can build your WLAN. This appendix describes how to build a WLAN around your ERB9260 using the device's operating modes.

  • Page 97: Client Bridge Mode

    In Client Bridge Mode, the ERB9260 behaves like a wireless client that connects to an Access Point wirelessly and allows users to surf the Internet whenever they want. In this mode, use the ERB9260 Site Survey to scan for Access Points within range.

  • Page 98: Client Router Mode

    17.3 Client Router Mode In Client Router Mode, the EBR9260’s internal DHCP server allows a number of LANs to automatically generate IP addresses to share the same Internet. In this mode, connect an AP/WISP wirelessly and connect to LANs via a wired connection.

  • Page 99: Appendix A - Fcc Interference Statement

    Appendix A – FCC Interference Statement Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 100: Appendix B - Industry Canada Statement

    Appendix B – Industry Canada statement Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 101 This radio transmitter (IC: 3616C-RB9260 / Model: ERB9260) has been approved by Industry Canada to operate with the antenna type, maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this user’s manual, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

  • Page 102: Appendix C - Product Specification

    Appendix C – Product Specification System Requirement System Windows Windows7, Vista, XP, 2000. 98, ME, NT or Mac OS Access method Web Based (HTTP 1.0 / 1.1) Browser Compatibility Microsoft IE 6.0 or above, Firefox 2.0 or above Status System Status System Information System Up Time, Device Name, Wireless MAC, LAN MAC, Country, Current Time, Firmware Version...
  • Page 103 Restore Saved Setting Reset to Factory Default Firmware Upgrade Firmware Upgrade Allow User to decide to Keep current setting or reset to default. Diagnosis Address to Ping : Hardware Specifications LAN: 1 x 10/100 Fast Ethernet RJ-45 WPS / Reset button Physical Interface Slide Switch Power Jack...
  • Page 104 Antenna 2dBi external Environment & Mechanical Temperature Range 0 to 45° C - Operating, -20 to 60 ° C - Storage Humidity (non- 90% or less – Operating, 90% or less - Storage condensing)
