5646 CL3-0137 10 12/5/07 11:13 AM Page 1
Our unique, high-velocity air beam technology
How To Use
is designed to be used in many and specific ways:
Direct Cooling
Use the Vornado
293HD Shop Fan with the air
®
beam pointed directly at you or your workspace.
This product has the unique ability to project the
beam of air a long distance. Moving air can
make you feel up to 5 degrees cooler.
Fresh Air Exchange
Use the Vornado 293HD Shop Fan in a
doorway to draw-in fresh air to a workspace.
Place the fan in the area that you want to draw
air from, the fan will then project this air far into
the room. If you only have one door or window
into the room keep the air beam low in the
opening to allow air to escape out the top of
the opening. If you have more than one door
or window open, use the fan in conjunction with
prevailing winds to assist in fresh air exchange.
Air Exhaust
Use the Vornado 293HD Shop Fan in a
doorway or near a window to exhaust air,
odors, or airborne particles. If you have more
than one door or window open, use the fan in
conjunction with prevailing winds, to assist in
exhausting air. If you only have one door or
window into the room keep the air beam low
in the opening to allow fresh air to come in the
opening at the top. Do not use this or any
portable fan to exhaust flammable vapors.
Power Drying
Use the Vornado 293HD Shop Fan for power
drying projects. The head of the Vornado 293HD
Shop Fan can be tilted downward to dry floors
or pointed up at walls or ceiling to dry paint or
sheetrock. It can also be used to dry finishes on
projects, with just the right amount of airflow.
Do not set fan on wet surfaces.
Winter Energy Saving with
Destratification
Use the Vornado 293HD Shop Fan for
destratisfying winter air. Point the Vornado
293HD Shop Fan straight up to pump the cool
air up off the floor and to bring the warm air
down from the ceiling making all the air in the
room a consistent temperature. Even in just an
8-foot tall room the temperature can vary 10
Degrees F from top to bottom, variation is even
greater in taller rooms. Vornado effectively
brings this warm air from the ceiling down to the
floor where people are; this may allow you to
adjust your thermostat and save on heating bills.
Summer Energy Savings with Air
Conditioning
Use the Vornado 293HD Shop Fan to assist
your air conditioning in several ways. Use it to
push air-conditioned air further into the room.
Even with air conditioning, direct air blowing on
you makes you feel up to 5 degrees cooler; this
may allow you to set your thermostat higher and
save on cooling bills.
Air Pump
Use the Vornado 293HD Shop Fan as an
air pump. Help move air from one area to
another horizontally or vertically. Place the unit
in the area you want to pump the air from and
point it to the area you would like to send it to.
Use it to pump air from one room to another, up
a flight of stairs, down a hallway, or to keep
cool air directed to a warm spot or machine.
Linear Cooling
Use the Vornado 293HD Shop Fan to create a
long-range beam of cooling for multiple-person
cooling effect. The long-range beam of air will
push air up to 100 feet, keeping multiple persons
more comfortable.
Whole Room Circulation
Using the Vornado 293HD Shop Fan in a
closed room environment will create whole room
circulation. The closed room allows the Vornado
to create a beam of air that can shoot across a
room and then circulate back around the
perimeter creating whole room circulation with
air moving everywhere in the room. Remember
circulating air makes you feel cool and can
allow you to lower your cooling bills.
POWER PERFORMANCE
Performance Over Size - Vornado
®
is Better
V OR NAD O H E AV Y- D U T Y S H OP FAN
T Y P I CAL B OX FAN
This product has a unique "beam-of-air" approach to air movement
that allows it to be used effectively in the above ways; inversely
however it does not have a broad width of air movement and may not
be appropriate for that type of application.
Vornado Air LLC
5-Year Limited Warranty
Vornado Air LLC ("Vornado") warrants to the original consumer or purchaser this
Model 293 HD ("Product") is free from defects in material or workmanship
for a period of five (5) years from the date of purchase. If any such defect is discovered
within the warranty period, Vornado, at its discretion, will repair or replace the Product at
no cost if the Product is returned to Vornado postage-paid. Repairs not covered by the
warranty or outside the warranty period will require a fee to cover the cost of materials,
labor, handling and shipping.
This warranty does not apply to defects resulting from abuse of the Product, modification,
alteration, repair or service of the Product by anyone other than Vornado, mishandling,
improper maintenance, commercial use of the Product, damages which occur in shipment
or are attributed to acts of God.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY
OF THE CONSUMER. VORNADO SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS
LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
or allow limitations on how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights, and you may
have other rights that vary from state to state.
For warranty or repair service, call 1-800-234-0604 or email consumerservice@vornado.com
to obtain a Return Authorization ("RA") form. Please have or include your Product's model
number and serial number, as well as your name, address, city, state, zip code and phone
number when contacting Vornado for warranty service. After receiving the RA form, ship
your Product postage-paid with a check or money order for $20.00 to cover return shipping
and handling along with a copy of the original dated receipt of purchase to:
Vornado Air LLC
Attn: Warranty & Repair
415 East 13th Street
Andover, KS 67002
For your convenience, please have your model number and serial number when contacting
Vornado with service inquiries.
To assure proper handling, packages must be clearly marked with the RA number.
Packages not clearly marked with the RA number may be refused at the receiving dock.
Please allow 1-2 weeks for repair and return of your Product after the Product is received.
For your records: Staple or attach your original sales receipt to this Owner's Guide. Please
also write your products's serial number below (located on product specs decal).
Serial No. ______________________________________
Product registration available online at www.vornado.com
© 2007 Vornado Air LLC Andover, KS 67002
US Patent: Re-34,551. Specifications subject to change without notice.
Vornado
, Leaders In Airflow Technology™, and AirTensity
are trademarks owned by
®
®
Vornado Air LLC.
W www.vornado.com P 1-800-234-0604 E consumerservice@vornado.com
CL3-0137 Rev-
OWNER'S GUIDE
READ AND SAVE THESE
IMPORTANT INSTRUCTIONS
Leaders In Airflow Technology™
For questions or more information
www.vornado.com
