ENERGY TOP W 70 - W 80 - W 125
IT - ISTRUZIONE PER L'USO L'INSTALLAZIONE E LA MANUTENZIONE
ES - INSTRUCCIONES DE USO, INSTALACIÓN Y MANTENIMIENTO
TR - KULLANMA, KURULUM VE BAK M TALIMATLAR
EN - INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE
FR - INSTRUCTIONS D'UTILISATION, D'INSTALLATION ET D'ENTRETIEN
RO - INSTRUC IUNI DE UTILIZARE, INSTALARE I ÎNTRETINERE
RU -
,
UA -
,

Advertisement

loading

Related Manuals for Ferroli ENERGY TOP W 70

Summary of Contents for Ferroli ENERGY TOP W 70

  • Page 1 ENERGY TOP W 70 - W 80 - W 125 IT - ISTRUZIONE PER L’USO L'INSTALLAZIONE E LA MANUTENZIONE ES - INSTRUCCIONES DE USO, INSTALACIÓN Y MANTENIMIENTO TR - KULLANMA, KURULUM VE BAK M TALIMATLAR EN - INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE FR - INSTRUCTIONS D'UTILISATION, D'INSTALLATION ET D'ENTRETIEN RO - INSTRUC IUNI DE UTILIZARE, INSTALARE I ÎNTRETINERE...
  • Page 2 Exclude hot water storage tank (economy) speed fan and a modulating gas valve. ENERGY TOP W 70 - W 80 - W 125 is a heat generator arranged to operate alone or in cascade.
  • Page 3 ENERGY TOP W 70 - W 80 - W 125 Turning the boiler off Room temperature adjustment (with optional room thermostat) Press the button eco/comfort (detail 7 - fig. 1) for 5 seconds. Using the room thermostat, set the temperature required in the rooms.
  • Page 4 Water treatment is indispensable in the case ENERGY TOP W 70 - W 80 - W 125 is a heat generator arranged to operate alone or in of very large systems or with frequent replenishing of water in the system. If partial or cascade (bank).
  • Page 5 ENERGY TOP W 70 - W 80 - W 125 COCK Male/Female 1"1/2 One direct heating circuit In combination with the previous 3-way valve, it enables shutoff (for mainte- Check/Change parameter P02 of the "Transparent Parameters Menu" to 4. nance operations) in conformity with ISPESL requirements and can be used Change parameter P.02 of the "System Type Menu"...
  • Page 6 ENERGY TOP W 70 - W 80 - W 125 Two direct heating circuits 3.4 Gas connection Check/Change parameter P02 of the "Transparent Parameters Menu" to 4. Before carrying out the connection, make sure the unit is arranged for operation with the type of fuel available and carefully clean all the pipes of the gas system Change parameter P.01 of the "System Type Menu"...
  • Page 7 ENERGY TOP W 70 - W 80 - W 125 Accessing the electrical terminal block Carry out all the electrical connections (terminals 4 to 27) on module no. 1 On the remaining modules, only connect the power supply and possible contacts The electrical terminal block can be accessed after removing the front panel.
  • Page 8 Unscrew the gas valve ( e ) fixing ring fig. 29“A”fig. 30. Undo the two fixing screws “B” and remove the fan assembly as indicated in fig. 29 for the model ENERGY TOP W 70 - W 80 and in fig. 30 for the model ENERGY TOP W 125.
  • Page 9 ENERGY TOP W 70 - W 80 - W 125 Replace the gas nozzle “F” (see fig. 32 for the model ENERGY TOP W 70 - W 80 and fig. 33 the model ENERGY TOP W 125) with the one contained in the conver- sion kit, positioning it inside the seal “G”.
  • Page 10 ENERGY TOP W 70 - W 80 - W 125 4.2 Start-up Opening the casing Checks to be made at first lighting, and after all maintenance operations that To open the boiler casing (fig. 36): involved disconnection from the systems or an operation on safety devices or...
  • Page 11 ENERGY TOP W 70 - W 80 - W 125 Table of faults Fault Fault Possible cause Cure code Table. 5 - List of faults Heating sensor fault Sensor damaged Replace the sensor Sensor damaged Fault Cascade temperature sen- Fault...
  • Page 12 ENERGY TOP W 70 - W 80 - W 125 5.1 Dimensions and connections 5.2 General view and main components fig. 39 - General view ENERGY TOP W 70 - W 80 fig. 38 - Dimensions and connections ENERGY TOP W 70 - W 80 ENERGY TOP W 125 Heating system delivery - 1”...
  • Page 13 ENERGY TOP W 70 - W 80 - W 125 5.3 Water circuit 5.4 Technical data table Factory settings The unit is factory-set to 80% power. Technical data The column on the right gives the abbreviation used on the dataplate.
  • Page 14 ENERGY TOP W 70 - W 80 - W 125 5.5 Diagrams A = Pressure losses model ENERGY TOP W 70 - W 80 B = Pressure losses model ENERGY TOP W 125 Diagram of pressure losses, boiler shell only...
  • Page 15 ENERGY TOP W 70 - W 80 - W 125 5.6 Wiring diagram fig. 42 - Wiring diagram cod. 3540S807 - Rev. 00 - 12/2013...

  • Page 16: Dichiarazione Di Conformità

    Dichiarazione di conformità Cav. del Lavoro Dante Ferroli Declaración de conformidad Presidente y representante legal Caballero del Trabajo Dante Ferroli Uygunluk beyani . Dep. Dante Ferroli Declaration of conformity Cav. del Lavoro Dante Ferroli...

  • Page 17: Déclaration De Conformité

    Déclaration de conformité Declara ie de conformitate Dante Ferroli...
  • Page 20 FERROLI S.p.A. Via Ritonda 78/a 37047 San Bonifacio - Verona - ITALY www.ferroli.it...
