Allied Telesis SWITCHBLADE 4000 Quick Install Manual
Switchblade 4000 series power supply unit
Hide thumbs
Also See for SWITCHBLADE 4000:
- Datasheet (9 pages) ,
- How to configure (9 pages) ,
- Supplementary manual (6 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allied Telesis SWITCHBLADE 4000
Summary of Contents for Allied Telesis SWITCHBLADE 4000
- Page 1 SWITCHBLADE POWER SUPPLY UNIT QUICK INSTALL GUIDE...
- Page 2 SwitchBlade Power Supply Unit Quick Install Guide Document Number C613-04028-01 REV B. Copyright © 2002 Allied Telesyn International, Corp. North Creek Parkway, Suite 200, Bothell, WA 98011, USA. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn.
-
Page 3: Package Contents
Quick Install Guide Documentation Roadmap SwitchBlade Safety and Statutory Information Booklet Hardware Reference Software Reference General Customer Support Chassis & Fan Tray Quick Install Guide Visit www.alliedtelesyn.co.nz for the latest documentation, FAQs, Power Supply Unit Quick Install Guide and support information. Switch Controller Quick Install Guide Line Card Quick Install Guide Bandwidth Expander Quick Install Guide... - Page 4 SwitchBlade Power Supply Unit Installing A Power Supply Unit (PSU) All AC and DC versions of this equipment must be earthed. PSUs can be hot swapped. When swapping PSUs, the SwitchBlade 8 (AT-SB4108) will continue to operate as long as two functional PSUs remain in place. The SwitchBlade 4 will continue to operate as long as one functional PSU remains in place.
- Page 5 Quick Install Guide Remove the PSU bay faceplate or existing PSU To remove a blank faceplate: Loosen the faceplate’s four Phillips mounting screws until they disengage from the chassis, then remove the faceplate. Keep the faceplate for future use. If you remove a PSU, replace the faceplate to prevent dust and debris from entering the chassis and to maintain proper airflow.
- Page 6 Also plug the power cord into an outlet that can supply a voltage of 90- 264V AC. Make sure the Standby switch is in the Run position. Figure 3: AC power connectors. SwitchBlade 4000 STANDBY RESET AC INPUT AC INPUT...
- Page 7 Connect the supply-cable wires to the circuit breaker h) Energise the circuit breaker Make sure the Standby switch (on the chassis’s rear panel) is in the Run position. Figure 4: DC power terminals. SwitchBlade 4000 STANDBY RESET FOR CENTRALIZED DC FOR CENTRALIZED DC...
- Page 8 SwitchBlade Power Supply Unit How Many PSUs Do You Need? The number of PSUs required depends on how many bays are in use. If any five bays are in use (one switch controller bay and four line card bays, or two switch controller bays and three line card bays), one PSU is sufficient.
