- Page 1 SUBWOOFER OWNERS MANUAL 24 Brook Road, Rayleigh, Essex SS6 7XL. England. Tel: +44 (0) 1268 740580 Fax: +44 (0) 1268 740589 info@monitoraudio.co.uk www.monitoraudio.co.uk...
- Page 2 SUBWOOFER OWNERS MANUAL ASW100/FB110/FB210...
- Page 3 Monitor Audio Subwoofers Thank you for purchasing your Monitor Audio subwoofer, we trust it will enable you to have hours of continuous pleasure. All our speakers are hand crafted from top to bottom in our factories in England. Established in 1972, Monitor Audio has extensive experience in the use of traditional woodworking skills for our cabinets and state of the art technology for our drive units.
- Page 4 The equipment should be returned in its packing to the original supplier where possible, or to any other authorised Monitor Audio dealer. If it is not possible to return the equipment by hand, then it should be sent carriage prepaid via a reputable carrier.
-
Page 5: Table Of Contents
Satellite Speaker wiring option 1 Speaker level high pass filter Main/Satellite speaker wiring option 2 Wiring with a pre amp and separate power amp Plugging in the Subwoofer Fine tuning Trouble shooting Specifications Guarantee and Service Claims under Guarantee © Monitor Audio Ltd 2001... -
Page 6: Unpacking And Installation
Note: If the Subwoofer is not likely to be used for long periods, it is wise to switch off at the mains. This is a recommended safe practice in order to reduce the risk of electrical fire. © Monitor Audio Ltd 2001... - Page 7 Power Sources The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the product. © Monitor Audio Ltd 2001...
- Page 8 The appliance has been dropped or the enclosure damaged. Servicing The user should not attempt to service the appliance beyond that specified in the operating instructions. Qualified service personnel should carry out all other servicing requirement. © Monitor Audio Ltd 2001...
-
Page 9: Mains Connection
Position/Location Your Monitor Audio Subwoofer should perform well in just about any room location. In fact unless your ear is within a couple of feet of the subwoofer, the bass should seem to radiate from your main speakers. - Page 10 ASW 100 / FB110 FB 210 Power switch with auto off facility RCA Phono inputs Mode switch High level inputs Level/Gain control High level outputs Crossover/Frequency control Fuse Phase control Mains connection RCA Phono outputs Voltage Selector 115/230V © Monitor Audio Ltd 2001...
- Page 11 1. Power Switch with Auto Off facility: The power switch provided for ASW100/FB110 has two positions: Off - Auto On. In the Auto On position the sub- woofer unit will remain in stand by mode until the unit receives an input signal. If the subwoofer unit does not receive a signal for around 15-20 minutes, it will switch to stand by mode until it receives a further signal.
- Page 12 12. Mains Voltage Selector should be factory set to your countries mains voltage specification. Do not attempt to adjust this as this may lead to permanent damage to the product and even the risk of fire. © Monitor Audio Ltd 2001...
-
Page 13: Standard Amplifier - Speaker Cable Connection
Connect the amplifiers left channel Black (-) to the subwoofer left channel Black (-) ‘high level input’ terminals. Make a corresponding match connection to the right channel. See fig. 1 (showing ASW100/FB110) (If using two subwoofers connect one to each channel) Fig. 1... -
Page 14: Satellite Speaker Wiring Option 1
Connect the subwoofer Black (-) ‘high level output’ terminal to the Black (-) terminal on the back of the main / satellite speaker. Make a matching connection to the right channel main/satellite. Fig. 2 AMPLIFIER SPEAKERS MONITOR AUDIO MONITOR AUDIO LEFT RIGHT SPEAKER SPEAKER © Monitor Audio Ltd 2001... -
Page 15: Speaker Level High Pass Filter
Speaker-level high pass filter Monitor Audio’s subwoofers have a high pass filter. When your main/satellite speakers are connected to the ‘speaker output’ terminals on the subwoofer, the low bass frequencies below 100Hz are filtered from your main / satellite speakers. -
Page 16: Main/Satellite Speaker Wiring Option 2
/ satellite speakers to your amplifier using the same high level output terminals as the subwoofer. Do not connect the main / satellite speakers to the subwoofer. Fig. 3 SPEAKERS AMPLIFIER MONITOR AUDIO MONITOR AUDIO LEFT RIGHT SPEAKER SPEAKER © Monitor Audio Ltd 2001... - Page 17 (left and right) on the subwoofer rear panel. See Fig. 4 if you are using two subwoofers, simply connect one subwoofer per channel. Fig. 4 PREAMP MAIN MAIN OUT 1 OUT 2 POWER AMP SPEAKERS MAIN INPUT MONITOR AUDIO MONITOR AUDIO LEFT RIGHT SPEAKER SPEAKER © Monitor Audio Ltd 2001...
-
Page 18: Plugging In The Subwoofer
Note: If the Subwoofer is not likely to be used for long periods, it is wise to switch off at the mains. This is a recommended safe practice in order to reduce the risk of electrical fire. © Monitor Audio Ltd 2001... -
Page 19: Trouble Shooting
Check that this is not caused by items located on top of or close to the subwoofer which may vibrate when subject to deep bass sounds If problems persist contact your dealer immediately for assistance. © Monitor Audio Ltd 2001... -
Page 20: Specifications
” x 14 ” Weight 12Kg / 26lb 15Kg / 33lb 24Kg / 53lb Input Voltage (Mains) 90 - 125V 90 - 125V 90 - 125V 115V 220 - 250V 220 - 250V 220 - 250V 230V © Monitor Audio Ltd 2001...
