Summary of Contents for Vivitek D7 Series
- Page 1 User Manual Manual del usuario Manuel de l'utilisateur Benutzerhandbuch Gebruikershandleiding Manuale d'uso Handbok Käyttöohje D7 Series...
- Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2011 Disclaimer The information in this document is subject to change without notice.
-
Page 3: Important Safety Information
DLP Projector – User’s Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. -
Page 4: Projector Installation Notice
Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically. Allow at least 50 cm clearance around the exhaust vent. - Page 5 DLP Projector – User’s Manual Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
- Page 6 Preface Main Features • Lightweight unit, easy to pack away and transport. • Compatible with all major video standards including NTSC, PAL, and SECAM. • A high brightness rating allows for presentations in daylight or in lit rooms. • Supports resolutions up to UXGA at 16.7 million colors to deliver crisp, clear images. •...
-
Page 7: Table Of Contents
DLP Projector – User’s Manual Table of Contents GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Rear view ..................................3 Bottom view..................................4 ..............................5 EMOTE ONTROL ARTS ..........................7 EMOTE ONTROL PERATING... - Page 8 Preface SPECIFICATIONS................................48 ................................. 48 PECIFICATIONS ........................49 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ..........................49 ................................ 50 IMING ABLE ) ............................52 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ............................. 53 FCC W .................................. 53 ARNING .................................... 53 ANADA ..............................
-
Page 9: Getting Started
DLP Projector – User’s Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR EMOTE CONTROL VGA CABLE OWER CORD (WITH TWO AAA BATTERIES) CD-ROM UICK TART UIDE ARRANTY ’ S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. -
Page 10: Views Of Projector Parts
DLP Projector – User’s Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE Lamp cover Removes cover to replace lamp Secure to permanent object with a Kensington® Kensington lock Lock system Security bar For security and authorized usage Lens Projection Lens Aspheric mirror... -
Page 11: Rear View
DLP Projector – User’s Manual Rear view 2 3 4 121110 ABEL ESCRIPTION EE PAGE Connect the RGB CABLE to a display VGA OUT (Loop Thru only for VGA IN-1) RS-232 Connect RS-232 serial port cable for remote control Connect the RGB CABLE from a computer and VGA –... -
Page 12: Bottom View
DLP Projector – User’s Manual Bottom view 228.00 126.00 70.00 110.00 20.00 56.00 146.00 100.0 240.0 236.00 ABEL ESCRIPTION EE PAGE Security bar Helps protect the projector from unauthorized use Tilt adjustors Rotate adjusters lever to adjust angle position Ceiling support holes Contact your dealer for information on mounting the projector on a ceiling Note: When installing, ensure that you use only UL Listed ceiling mounts. -
Page 13: Remote Control Parts
DLP Projector – User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 14 DLP Projector – User’s Manual ABEL ESCRIPTION EE PAGE IR transmitter Transmits signals to projector Status LED Lights when the remote control is used Laser Press to operate the on-screen pointer Up arrow when connected through USB to a PC Right Right arrow when connected through USB to a PC Down...
-
Page 15: Remote Control Operating Range
DLP Projector – User’s Manual Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level. -
Page 16: Setup And Operation
DLP Projector – User’s Manual ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. -
Page 17: Connecting Input Devices
DLP Projector – User’s Manual Connecting Input Devices A PC or notebook computer and video devices can be connected to the projector at the same time. Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras. Check the user manual of the connecting device to confirm it has the appropriate output connector. -
Page 18: Starting And Shutting Down The Projector
DLP Projector – User’s Manual Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. The POWER LED on the projector light. Turn on the connected devices. Ensure the POWER LED displays a solid orange. - Page 19 DLP Projector – User’s Manual When the “Power Off? /Press Power again” message appears, press the POWER button. The projector turns off. Caution: Do not unplug the power cord until the POWER LED change to orange–indicating the projector has cooled down. –...
-
Page 20: Setting An Access Password (Security Lock)
DLP Projector – User’s Manual Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the OSD on page 17 and Setting the OSD Language on page 18 for help on using OSD menus.) - Page 21 DLP Projector – User’s Manual You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.
-
Page 22: Adjusting The Projector Level
DLP Projector – User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. •... -
Page 23: Adjusting The Keystone
DLP Projector – User’s Manual Adjusting the Keystone Use the KEYSTONE buttons the remote control to correct image-trapezoid (wider top or bottom) effect. Volume The keystone control appears on the display. – 15 –... -
Page 24: Adjusting The Volume
DLP Projector – User’s Manual Adjusting the Volume Press the Volume +/- buttons on the remote control. The volume control appears on the display. Volume Press the MUTE button to turn off the volume – 16 –... -
Page 25: On-Screen Display (Osd) Menu Settings
DLP Projector – User’s Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD. -
Page 26: Setting The Osd Language
DLP Projector – User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Installation I. 2. Press the cursor ▲▼ button until Language is highlighted. 3. -
Page 27: Osd Menu Overview
DLP Projector – User’s Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 19 –... -
Page 28: Osd Sub-Menu Overview
DLP Projector – User’s Manual OSD Sub-Menu Overview – 20 –... -
Page 29: Image Menu
DLP Projector – User’s Manual Image Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to change values for settings. -
Page 30: Advanced Feature
DLP Projector – User’s Manual Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu. -
Page 31: Color Manager
DLP Projector – User’s Manual Color Manager Press (Enter) / ► to enter the Color Manager sub menu. ESCRIPTION Select to enter the Red Color Manager. Press the ◄► buttons to adjust the Hue, Saturation, and Gain. Select to enter the Green Color Manager. Green Press the ◄►... -
Page 32: Computer Menu
DLP Projector – User’s Manual Computer Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Com- puter menu. Press the cursor ▲▼ button to move up and down in the computer menu. Press ◄► to change values for settings. -
Page 33: Video/Audio Menu
DLP Projector – User’s Manual Video/Audio Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Video/Audio menu. Press the cursor ▲▼ button to move up and down in the Video/Audio menu. Press ◄►... -
Page 34: Audio
DLP Projector – User’s Manual Audio Press (Enter) / ► to enter the Audio sub menu. ESCRIPTION Volume Press the ◄► buttons to adjust the audio volume. Mute Press the ◄► buttons to turn on or off the speaker. Audio Input Press the cursor ◄►... -
Page 35: Installationi Menu
DLP Projector – User’s Manual Installation I Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion I menu. Press the cursor ▲▼ button to move up and down in the Installation I menu. Press ◄►... -
Page 36: Advanced Feature
DLP Projector – User’s Manual Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Installation I menu. Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced menu. -
Page 37: Installation Ii Menu
DLP Projector – User’s Manual Installation II Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion II menu. Press the cursor ▲▼ button to move up and down in the Installation II menu. ESCRIPTION Auto Source Press the cursor ◄►... -
Page 38: Advanced Feature
DLP Projector – User’s Manual Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Installation II menu. Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced menu. -
Page 39: Osd Menu Setting
DLP Projector – User’s Manual OSD Menu Setting ESCRIPTION Menu Position Press ◄► button to select different OSD location. Translucent Menu Press ◄► button to select OSD background translucent level. Menu Display Press ◄► button to select OSD timeout delay. Peripheral Test ESCRIPTION Remote Control Test... -
Page 40: Lamp Hour Reset
DLP Projector – User’s Manual Lamp Hour Reset Please refer to Lamp Hour Reset on page 41 to reset the lamp hour counter. ESCRIPTION Press ◄► to select Off, DLP-Link or IR. 3D Sync Invert Press ◄► to turn 3D Sync Invert On or Off. –... - Page 41 DLP Projector – User’s Manual Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields. IP Address Enter a valid IP address if DHCP is turned off.
- Page 42 DLP Projector – User’s Manual For simplicity and ease of operation, the projector provides diverse networking and remote management features. The LAN/RJ45 function of the projector through a network, such as remotely manage: Power On/Off, Brightness and Contrast settings. Also, projector status information, such as: Video-Source, Sound-Mute, etc .
- Page 43 DLP Projector – User’s Manual 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. –...
- Page 44 DLP Projector – User’s Manual 7. Press the Menu button on the projector. Select Installation II → Advanced→ Network. After getting into Network, input the following: DHCP: Off IP Address: 10.10.10.10 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS Server: 0.0.0.0 10. Press (Enter) / ►...
- Page 45 DLP Projector – User’s Manual ATEGORY NPUT ENGTH IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A)
-
Page 46: Factory Reset
DLP Projector – User’s Manual Factory Reset Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the Factory Reset sub menu and press (Enter) / ► to reset all the menu items to the factory default values (expect Language and Security Lock). -
Page 47: Maintenance And Security
DLP Projector – User’s Manual AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. - Page 48 DLP Projector – User’s Manual Remove the lamp compart- ment cover. Remove the two screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. Reverse steps 1 to 5 to install the new lamp module.
-
Page 49: Resetting The Lamp
DLP Projector – User’s Manual Resetting the Lamp After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installation II menu. -
Page 50: Cleaning The Projector
DLP Projector – User’s Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn. -
Page 51: Using The Physical Lock
DLP Projector – User’s Manual Using the Physical Lock ® Using the Kensington Lock If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System. -
Page 52: Troubleshooting
DLP Projector – User’s Manual ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection. -
Page 53: Led Error Messages
DLP Projector – User’s Manual LED Error Messages ARNING OWER RROR ESSAGES LINK LINK Power On Blue Power Off Orange Cooling Flashing Over Temperature Thermal Break Sensor error Burner Fan error Lamp Fan error Lamp Door Open DMD error In the event of an error, please disconnect the AC power cord and wait for one (1) minute before re- starting the projector. -
Page 54: Lamp Problems
DLP Projector – User’s Manual Lamp Problems Problem: There is no light from the projector 1. Check that the power cable is securely connected. 2. Ensure the power source is good by testing with another electrical device. 3. Restart the projector in the correct order and check that the Power LED is green. 4. -
Page 55: Hdmi Tmq & A
DLP Projector – User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High-Speed cables. ․Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 56: Specifications
DLP Projector – User’s Manual PECIFICATIONS Specifications For questions regarding product specifications, please contact your local distributor. Note: Model name D795WT D791ST Display type TI DMD 0.65" WXGA TI DMD 0.55" XGA Resolution WXGA 1280 x 800 Native XGA 1024 x 768 Native Projection distance 22.4 mm ~ 62.3 mm(+/-10mm) Projection screen size... -
Page 57: Projection Distance Vs. Projection Size
DLP Projector – User’s Manual Projection Distance vs. Projection Size Image Width Image Height Projection Distance and Size Table D795WT D791ST WXGA 16:10 16:9 Distance (D) 62.3+/-10mm 22.4+/-10mm 62.3+/-10mm 22.4+/-10mm Diagonal 97" 87" 82” 73” Image Width (W) 2089mm 1868mm 1671mm 1494mm Image height (L) -
Page 58: Timing Mode Table
DLP Projector – User’s Manual Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. DVI/ OMPOSITE HDMI IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL — NTSC —... - Page 59 DLP Projector – User’s Manual DVI/ OMPOSITE HDMI IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL 720p 37.5 50.0 — — 720p 45.0 60.0 — — 1080i 33.8 60.0 — — 1080i 28.1 50.0 — — HDTV 1080p — — 1080p —...
-
Page 60: Projector Dimensions (Mm)
DLP Projector – User’s Manual Projector Dimensions (mm) 354.00 – 52 –... -
Page 61: Regulatory Compliance
DLP Projector – User’s Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 62: Rs-232C Protocol
DLP Projector – User’s Manual PPENDIX RS-232C Protocol Note: Not all functions are available for all models due to different series. RS232 Setting Baud rate: 9600 Parity None check: Data bit: Stop bit: Flow Con- None trol Minimum delay for next command: 1ms Control Command Structure The command is structured by the Header code, command code, data code and end code. - Page 63 DLP Projector – User’s Manual Remote Command The remote commands simulate the code send from IR remote handset. Button’s name ASCII UP arrow ~ r U CR 7Eh 72h 55h 0Dh DOWN arrow ~ r D CR 7Eh 72h 44h 0Dh LEFT arrow ~ r L CR 7Eh 72h 4Ch 0Dh...
- Page 64 DLP Projector – User’s Manual Query Command ITEM ASCII Software Version ~ q V CR 7Eh 71h 56h 0Dh Power State ~ q P CR 7Eh 71h 50h 0Dh Input Select ~ q S CR 7Eh 71h 53h 0Dh Lamp Hours ~ q L CR 7Eh 71h 4Ch 0Dh Brightness...
- Page 65 2010 Vivitek Corporation. All rights reserved. All trademarks are the property of their respective owners. All specifications are subject to change without prior notice. 201009...
