WIRING TABLE

Keypad Control Panel
G Data In
v
− − Aux Pwr (GND)
+ + Aux Pwr
Y Data Out
w
Note: NO (normally Open) and C (common) are the
connections for the relay output

APPLICATION GUIDELINES

Use the following guidelines when planning an installation:
• Local wireless keys (wireless keys programmed directly into the FA270RF) may be used regardless of whether the
RF receiver in the FA270RF is enabled or disabled.
• If using bi-directional devices, be sure to enable the transmitter module in the FA270RF.
• If transmitters are programmed into the control panel, be sure to enable the receiver. (Make sure you do not
exceed the number of receivers supported by the control panel.)
• If a local wireless key is programmed to arm/disarm or to trigger a relay on the control panel, a user code must be
entered into the FA270RF. This user code must also be programmed into the control panel.
• You must set the House ID in the FA270RF (If the House ID source is "System", the FA270RF uses the House ID
programmed in the Control Panel.) only if you are using RF keypads and/or bi-directional devices; AND the House
ID Source is the FA270RF (Local).
FA270RF Application Guide
The following guide outlines how to program the wireless keys, RF receiver, and the House ID in the FA270RF for
your installation.
System Control Panel
FA110C, FA120C
FA142C, FA148C, FA148CP
FA162C, FA168C, FA168CPS
FA1220CV, FA1340C
* Two FA270RFs are needed for this application: one assigned to partition 1 and one assigned to partition 2.
** If using an RF keypad on only one partition, the FA270RF's partition assignment in panel programming must match the partition.
*** If set for Local on a partition control, the FA270RF's partition assignment must match the one programmed in the BD device.
Wire Color
Green
Black
Red
Yellow
Are you using
RF keys RF receivers
beyond beyond
system's system's
capacity? capacity?
N/A N/A
NO NO
YES NO
YES YES
NO NO
YES NO
YES YES
NO YES
YES YES
NO NO
YES NO
YES YES
NO YES
YES YES
Figure 2 - FA270RF Wiring Connections
Program
RF keypads and/or
Wireless Keys
Bi-directional
Into
devices on more
than 1 partition?
N/A FA270RF
N/A System
N/A FA270RF
N/A FA270RF
NO System
NO FA270RF
NO FA270RF
YES* System
YES* FA270RF
NO** System
NO** FA270RF
NO** FA270RF
YES System
YES FA270RF
- 2 -
Y G NO C
FA270RF-005-V0
FA270RF Programming Options
Receiver
House ID
Source***
Enable
OFF Local [0]
ON [1] System [1]
ON [1] System [1]
OFF [0] Local [0]
ON [1] System [1]
ON [1] System [1]
OFF [0] Local [0]
OFF [0] Local [0]
OFF [0] Local [0]
ON [1] System [1]
ON [1] System [1]
OFF [0] Local [0]
OFF [0] Local [0]
OFF [0] Local [0]
