HandKey II Installation and Operation Manual

Set Serial

Set the serial port (RS-485/RS-422 and RS-232) baud rates to match the rates of the
other Hand Readers, the host computer, and serial printer. 9600 baud is suitable for
most applications and is set as the default value.
1. When you enter the Set Serial command the display appears as follows.
2. Press
– or –
3. Press
command.
– or –
4. Press
5. Press
– or –
6. Press
the display.
7. Press
appears on the display, then press
the start of the RS-485/RS-422 option.
Page 110
SET SERIAL
*NO YES#
5
to exit the command menu.
*
to keep the current serial port baud rates and skip to the Set Duress Code
#
to Set a Serial Port. The RS-485/RS-422 option appears on the display.
SET RS-485/422?
*NO YES#
*
to skip to the RS-232 option.
#
to select the RS-485/RS-422 baud rate. The Baud Rate option appears on
9600 BAUD
*NO YES#
*
to step through the list of available baud rates until the desired baud rate
SET RS-485/422?
*NO YES#
#
to select the baud rate. The display returns to
Revision 2.0
