- Page 1 Bluetooth Wireless Desktop ™ Enjoy the freedom and convenience of wireless computing User Manual F8T042-B...
-
Page 2: Table Of Contents
Table of Contents 1 Introduction............. . . 1 2 Overview Product Features . -
Page 3: Introduction
Please be sure to review this User Manual carefully, to ensure that you take advantage of all the features and capabilities of your new Bluetooth Wireless Desktop. PLEASE NOTE: References made to the Bluetooth USB Adapter are to equipment included with your Bluetooth Wireless Desktop, part number F8T042-B. -
Page 4: Overview
Overview Product Features The Bluetooth Desktop is compliant with Bluetooth Standard version 1.1 and: • Offers the convenience of the wireless Bluetooth interface • Features comfortable, ergonomic design • Works at distances of up to 10 meters (33 ft.) • Installs and operates easily •... - Page 5 Overview The USB Adapter is compliant with Bluetooth Standard Version 1.1 and provides: • Compliance with Bluetooth specification v1.1 devices • USB bus powering; no external power supply necessary • Support for Microsoft Windows Me, 2000, XP, Server 2003, and ®...
-
Page 6: System Requirements
Overview System Requirements • PC-compatible computer, CPU speed 200MHz or above • Memory: 64MB or above, 128MB recommended • One available USB port, USB 1.1 standard • Windows Me, 2000, XP, Server 2003, or Mac OS X v10.2.6 and higher ®... -
Page 7: Package Contents
Overview Package Contents • Bluetooth Wireless Keyboard • Bluetooth Wireless Optical Mouse • Bluetooth USB Adapter • USB base with 6 ft. extension • CD-ROM (installation and user manual) • Quick Installation Guide • 4 AA Batteries... -
Page 8: Specifications
Overview Wireless Specifications Bluetooth Compliance Version 1.2 Compatible to Bluetooth HID profile 0.95c Operating Frequency 2.402 to 2.480GHz Output Power Class II (<4 dBm) RF output power Operation Range 10-meter (33 ft.) radius indoors Antenna Integrated Mouse Specifications Pointing Device Optical, 800dpi Buttons 3+ scroll-wheel... -
Page 9: Keyboard Specifications
Overview Keyboard Specifications Buttons/Keys 107+ 15 Multimedia/Internet buttons Batteries Required 2 AA (included) Battery Life 25 days under normal usage; 100 days standby USB Backup USB “B”-Type Connector Specifications Dimensions Mouse 74 (W) x 130 (L) x 45mm (H) Keyboard 495 (W) x 196.9 (L) x 25.4mm (H) Weight Mouse... -
Page 10: Supported Profiles
Overview Audio Gateway Supported Profiles Profile The services supported by your USB Adapter are defined as “Profiles”. Available profiles include: Personal Area Serial Port Object Exchange Network Human Interface LAN Access File Transfer Device* Audio Gateway Dial-Up Hardcopy Cable Audio Gateway Profile Profile Networking... - Page 11 Overview Your USB Adapter gives you the ability to do the following—without cables: • Transfer files • Access dial-up networks • Connect to local area networks • Perform an ActiveSync® session • Connect to serial ports • Print • Exchange PIM data •...
-
Page 12: Software Setup
Software Setup Installing the USB Adapter Software Setup for Windows Me, 2000, and XP To install the software for the USB Adapter, follow the instructions below: The installation process for Windows XP may look slightly different from Windows Me and 2000. NOTE: Do not insert the USB Adapter into the USB port prior to installation. - Page 13 Choose “I accept the terms in the license agreement” to accept the license agreement. Click on “Next” to continue. Specify the location where the software files will be installed on your hard drive. It is recommended that you install the software in the default directory “C:\Program Files\Belkin\Bluetooth\Software\”. Click on “Next” to continue.
- Page 14 Software Setup Confirm that the device software is ready to be installed and click on “Install”. The InstallShield Wizard will begin to install the Bluetooth software. This may take several minutes. NOTE: If at any time during the installation process you receive a “Driver Signature Notice”, click “OK”...
- Page 15 Software Setup During the installation process, you will be prompted to insert your Bluetooth USB Adapter. If your Adapter is not plugged into your computer at this time, you may insert it into an available USB 1.1-compliant port on your desktop or notebook, then click “OK”...
- Page 16 Software Setup Confirm the completion of the software installation; click “Finish” and restart the system if prompted to do so.
-
Page 17: Hardware Setup
Hardware Setup USB Adapter Bluetooth You must connect the USB Adapter to an available Universal Serial Bus (USB) port on your computer. NOTE: Your USB Adapter is sensitive to static electricity, which can damage its delicate electrical components. Electrostatic charges can be acquired simply by dry weather conditions or they can occur when you walk across carpeted floors. - Page 18 Hardware Setup Hardware Setup for Windows Me, 2000, and XP Once you have connected the USB Adapter, your system will display a “New USB device found”. Follow the prompts to install drivers for your Adapter. Choose “Install from a list or Specific location”; then click “Next”.
- Page 19 Hardware Setup Bluetooth Browse for the location of the device driver “C:\Program Files\Belkin\ Software\bin\” then click “Next”. If you receive the following “Hardware installation notice”, click on “Continue Anyway” to continue with the installation process.
- Page 20 Hardware Setup A window will appear that confirms the completion of the hardware installation; click on “Finish” to complete the installation process.
-
Page 21: Initial Configuration Wizard
Initial Configuration Wizard Configuring your Computer for Windows Me, 2000, and XP Bluetooth Once the installation process is complete, double click the icon in the Bluetooth lower left corner of your desktop to begin the “Initial Configuration Wizard”. Follow the prompts as the Wizard guides you through the initial setup of your Bluetooth device. - Page 22 Initial Configuration Wizard Choose the type of computer you have installed the Bluetooth USB Adapter to in the drop-down menu and click “Next”. Continue to use the Wizard to configure the Bluetooth services that this computer will allow other Bluetooth devices to access. Click “Next”.
- Page 23 Initial Configuration Wizard Bluetooth Choose the services your computer will offer. The most common service for your computer type will be checked by default. Bluetooth Congratulations! Your computer is ready to connect to your keyboard. Bluetooth Click “Skip”, then “Finish” and proceed to the “Connecting the Desktop”...
-
Page 24: Connecting The Bluetooth Desktop
Bluetooth Bluetooth Connecting the Connecting the Connecting the Desktop Desktop Desktop The following steps will allow you to establish the initial connection between your Wireless Desktop and computer. Once a connection is established, your computer will automatically connect every time to boot your computer. If for any reason the Desktop does not reconnect at boot-up, follow the pairing and connection procedures on page 24. -
Page 25: Inserting The Batteries
Bluetooth Bluetooth Connecting the Connecting the Connecting the Desktop Desktop Desktop Inserting the Batteries The Keyboard requires four AA batteries and the Mouse requires two AA batteries to run (included). When it becomes necessary to replace them, be sure to use new batteries only;... -
Page 26: Connecting The Bluetooth Keyboard
Bluetooth Bluetooth Connecting the Connecting the Connecting the Keyboard Keyboard Keyboard Preparing the Keyboard Turn the Keyboard upside down, and press and hold the “Connect” button for five seconds.The Keyboard is now in pairing mode and is ready to connect to your computer. - Page 27 Bluetooth Bluetooth Connecting the Connecting the Connecting the Keyboard Keyboard Keyboard On your computer, open “My Bluetooth Places” by double-clicking on the Bluetooth icon. Bluetooth From the menu bar, select “ ” then “Bluetooth Setup Wizard”. Bluetooth Select “I know the service I want to use and I want to find a device that provides that service.”...
- Page 28 Bluetooth Connecting the Keyboard From the menu, scroll down to select “Human Interface Device” then click on “Next”. Please verify that the LED continues to flash rapidly. The Bluetooth Keyboard will be discovered. Click on the Bluetooth Keyboard icon then click “Next”.
- Page 29 Bluetooth Connecting the Keyboard The “Pairing Procedure” window will appear. Click on the “Initiate Pairing” button on the screen. On your Bluetooth Keyboard, type the unique pin-code digits and press the “Enter” key. Type the name you would like your Keyboard to appear as and click “Finish”.
-
Page 30: Connecting The Bluetooth Mouse
Bluetooth Bluetooth Connecting the Connecting the Connecting the Mouse Mouse Mouse The following steps will allow you to establish the initial connection between your Mouse and computer. Once a connection is established, your computer will automatically connect to your Mouse every time you reboot. If the Mouse does not reconnect at boot-up, follow the pairing and connection procedures on page 24. - Page 31 Bluetooth Bluetooth Connecting the Connecting the Connecting the Mouse Mouse Mouse From the menu bar select “Bluetooth” then “Bluetooth Setup Wizard”. Select “I want to find a specific Bluetooth device and configure how this computer will use its services”. Then click “Next”.
- Page 32 Bluetooth Connecting the Mouse From the drop-down menu, select “Show mice, keyboards and joysticks” then click on the “Search Again” button. The Belkin Mouse will be discovered. Click on the Belkin Mouse icon then click “Next”.
- Page 33 Bluetooth Connecting the Mouse The services that are available from the device will be listed. Select “Bluetooth Mouse” and click “Finish”. Wait while the Mouse is installed. This may take several seconds. Your Mouse is now connected. Move your Mouse to verify the connection.
-
Page 34: Uninstalling The Software
Uninstalling the Software Uninstalling the Software for Windows Me, 2000, and XP Follow these instructions to uninstall your Bluetooth USB Adapter. Insert the CD-ROM included with your USB Adapter. The “InstallShield Wizard” should automatically load. If it does not load, explore the CD and run the “Setup.exe”... -
Page 35: Faqs
DUN, Generic Object Exchange, Business Card, Push, Pull & Exchange, Fax, Synchronization, PAN, HCRP, Audio Gateway, Headset, and Human Interface Device. Which Bluetooth Profiles does the Bluetooth Wireless Desktop (the Desktop) Support? The Desktop supports the Human Interface Device profile. - Page 36 FAQs Will my Bluetooth Keyboard work prior to Windows loading? At this time, the Bluetooth Keyboard will only operate inside the Windows environment. You must use a keyboard that is connected directly to your computer to access your system BIOS. Future firmware upgrades for the Bluetooth USB Adapter that is included with this product will allow your Bluetooth Keyboard to function prior to Windows booting.
- Page 37 HID Profiles. For WIDCOMM software users, you must have BTW version 1.4 or higher. Can my Microsoft Bluetooth Keyboard and Mouse connect to my Belkin Bluetooth USB Adapter included with this package? Yes, it can. Follow the Keyboard and Mouse connection procedure as described above in this User Manual.
-
Page 38: Battery And Safety Information
Battery and Safety Information General Precautions Keep batteries out of reach of children. Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries). Always remove old, weak, or worn-out batteries promptly and recycle or dispose of them in accordance with local and national disposal regulations. -
Page 39: Special Precautions
Battery and Safety Information Special Precautions The precautions below are to prevent the sudden release of electrolytes, which these prohibited actions can cause: Do not open, puncture, or mutilate the batteries. Do not heat batteries. Do not use a fire to dispose of batteries. Released battery electrolyte is corrosive, can cause damage to the eyes and skin, and may be toxic if swallowed. -
Page 40: Information
Information DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the products, F8T040, F8T043, F8T003 to which this declaration relates, comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 41 Modifications The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by Belkin Corporation may void the users authority to operate the equipment. Canada-Industry Canada (IC) The wireless radio of this device complies with RSS 139 & RSS 210 Industry Canada. This Class B digital complies with Canadian ICES-003.
- Page 42 • EN 300 328 Technical requirement for radio equipment • ETS 300 826 General EMC requirements for radio equipment. To determine the type of transmitter, check the identification label on your Belkin product. Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (72/23/EEC) issued by the Commission of the European Community.
- Page 43 Belkin Corporation warrants this product against defects in materials and workmanship for its warranty period. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
- Page 44 Tel: +44 (0) 1933 35 2000 Fax: +44 (0) 1933 31 2000 © 2004 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. The Bluetooth name and the Bluetooth trademarks are owned by Bluetooth SIG, Inc., and are used by Belkin Corporation under license.
