Water Filtration Device
• This product can not be used if the voltage is different from that
mentioned in the rating plate.
• For your safety and proper use of the product, please read this
User's Manual before use.
• Warranty card is included in this User's Manual.
Available From:
freshwatersystems
serving you since 1989
CLICK HERE
®
CP-07BLO
.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Coway CP-07BLO
Summary of Contents for Coway CP-07BLO
- Page 1 CP-07BLO Water Filtration Device • This product can not be used if the voltage is different from that mentioned in the rating plate. • For your safety and proper use of the product, please read this User’s Manual before use. • Warranty card is included in this User’s Manual. Available From: freshwatersystems .com serving you since 1989 CLICK HERE ®...
- Page 2 FEATURES 1. Power saving mode using the light sensor If you press the “SAVE” button, as it decreases the driving times of the motor at night automatically, the amount of the power consumption is decreased. 2. Faucet pollution prevention It protects the cold water/the room water faucet from the external pollution using the faucet cover. Faucet pollution Faucet pollution prevention prevention 3. Prevention function Overcooling Overcooling It prevents the damages occurred due to the overcooling as it prevents the working of the motor when the cold water temperature lowers to excess. 4. Attachable gutter It can take a lot of water at a time using the big vessel by applying the attachable gutter. Attachable gutter...
-
Page 3: Table Of Contents
DEAR CUSTOMERS Coway Water Filtration Device Thank you for using our Please read this Users’ Manual to use and maintain the product correctly. If you encounter a problem while using the product, you may solve the problem referring to the User’s Manual. As this manual contains the product warranty card, please keep it in a safe place. This system conforms to NSF/ANSI 42 for aesthetic chlorine and NSF/ANSI 53 for VOC as verified and substantiated by test data. This system conforms to NSF/ANSI 58 for the reduction of Pentavalent Arsenic, Barium, Cadmium, Selenium, Radium 226/228, Trivalent chromium, Hexavalent chromium, Lead, Nitrate/Nitrite as verified and substantiated by test data. See performance data sheet for individual contaminants and reduction performance. This system is acceptable for treatment for influent concentrations of no more than 27 mg/L nitrate and 3 mg/L nitrite in combination measured as N and is certified for nitrate/nitrite reduction only for water supplies with a pressure of 280 kPa(40 psi) or greater. CONTENTS FOR INFORMATION hOW TO USE SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . 3 INSTALLATION PRECAUTIONS . -
Page 4: Safety Information
SAFETY INFORMATION Be careful to keep this safety information. Please read this information to prevent property loss and ensure your safety. If not observed, If not observed, If not observed, slight serious injury or serious injury or injury or property even death could property damage damage could occur. Danger Warning Caution occur. could occur. Electricity safety Do not use a damaged Do not pull the power cord . power cord or plug, and Otherwise, electric shock or loose outlet . -
Page 5: Installation Safety
Otherwise, electric shock or fire may occur as a result. fire may occur as a result. In the case the power cord is damaged, do not replace the cord yourself . Call Coway Service Center to have it replaced . Otherwise, electric shock or fire may occur as a result. Installation safety Do not install near a heating Avoid installing the device . -
Page 6: Operation Safety
SAFETY INFORMATION If not observed, If not observed, If not observed, slight serious injury or serious injury or injury or property even death could property damage damage could occur. Danger Warning Caution occur. could occur. Operation safety When the water is If our product produces a coming inside of the strange noise or odd smell, product or there is a immediately unplug from puddle on the product, the electrical outlet and... -
Page 7: Others
Danger Warning Caution Others Clean after unplugging . Do not clean by spraying the water directly or don’t Otherwise, electric shock or fire may occur as a result. wipe the product using the benzene and thinner . Otherwise, electric shock or fire may occur as a result. Do not repair, disassemble, Do not use filtered water or modify . -
Page 8: Parts Name
PARTS NAME Front Indication part/ Operation part Room water extraction faucet Cold water extraction faucet Cup-touch lever Gutte Rear Cooling Stopper Radiator Power cord Outlet(Blue) Inlet(Orange) -
Page 9: Water Filtration Process
WATER FILTRATION PROCESS The filter is the core technology of the filtration system. If you don’t use qualifying filter or if you use an old filter that has expired, the system performance may degrade. The 5-step water filtering system (CP-07BLO) STEP 1, 2 : NEO-SENSE FILTER This neo-sense filter has the function to reduce aesthetic chlorine, odor, volatile organic compounds(VOC’s). STEP 3 : RO MEMbRANE FILTER RO membrane filter has the function to reduce water contaminants such as pentavalent arsenic, barium, cadmium, selenium, radium 226/228, trivalent chromium, hexavalent chromium, lead, nitrate/nitrite. STEP 4 : INNO-SENSE FILTER This inno-sense filter has the functions to reduce smell induction material and to improve taste of water. It also has the function to reduce aesthetic chlorine, volatile organic compounds(VOC’s). STEP 5 : CERAMIC FILTER... -
Page 10: Installation Precautions
INSTALLATION PRECAUTIONS The summary for the proper installation of the water filtration device 1 . Close main water supply valve to separate the faucet . 2 . Wind the teflon tape on the adaptor and fit it to the pipe . Do not turn the water pipe . - Page 11 Please check before use! This product is for 120 V 60 Hz only . Please connect the power plug to a dedicated grounded electrical outlet for 120 V 60 Hz. The water filtration device works normally only when the electricity is connected. • Open the main water supply valve. The main water must be supplied to operate the water filtration device normally. • After installing the product Get rid of the saved water above the full water in the inner water tank 2 times or more to use. • When the indicator in the indication part is turned off When the indicator in the indication part is turned off, check if the power supply was stopped due to the power failure or other cause. • Regularly filter replacement It is important to replace the filter regularly to drink the pure water. If the filter is overused beyond its service life, the performance of the water filtration device deteriorate, Do not miss the filter replacement cycle. • When you didn’t use for a long time If you saved the water for a long time or you didn’t use, drain the water inside of the water filtration device completely and remove the newly filtered water one time to use. • When you don’t want to use for a long time Close the main water supply valve and unplug. When you don’t use for a long time, close the main water supply valve and unplug.
-
Page 12: Operation / Indication Part
OPERATION / INDICATION PART Indication part/Operation part Indication part Operation part Cold water mode indicator Power indicator L ight sensor Power saving Cold water mode indicator mode selection button Power saving Cold water mode selection temperature button indicator Water level Room water indicator mode indicator Cold water mode Cold water indicator temperature indicator When you select cold water The indicator is turned on mode, the indicator is turned on. according to the cold water temperature. As many Room water mode... - Page 13 Operation part Cold water mode Power saving selection button mode selection button When you want to select / deselect cold When you want to water mode, use it. select / deselect power saving mode, use it. To use the cold water mode Press the “COLD” in the right of the control button and check if the cold water mode indicator in the indication part is turned on.
-
Page 14: How To Use
hOW TO USE To drink the cold water Please push the cup-touch lever in the cold water faucet. If the cold water doesn’t come from the water filtration device, check if the cold water mode indicator in the indication part is turned on (See P.12). Tips To drink the room water Please push the cup-touch lever in the room water faucet. -
Page 15: Installation
INSTALLATION Follow the instruction for installation Main water 1 cooling stopper supply valve 120 V 60 Hz Only Connect the orange color inlet tubing to the tap water supplying pipe. Connecting the outlet tubing Inlet tubing(Orange) ▶ Outlet tubing(Blue) ▶... - Page 16 Water filtration device installation place 2 Please install at the place where it is 10 cm or more off from the wall and the bottom is flat and firm. After installing the water filtration system Get rid of the filtered water above the fulled water 2 times or more necessarily after installing. Cold water plumbing Please connect to the cold water pipe necessarily. (If you connect to the warm water pipe, the filter can be damaged.) Movement and installation When the position is moved, connect the power cord when 30 minutes passes after installing. To maintain optimal product performance, consult a Coway engineer for the detailed installation methods. Tips There may be some water remaining inside of the filter which was used to test the product during inspection process at the factory. Please feel at easy and use as it isn’t the used product. Don’t reuse the main water supply valve and hose that was previously used when you install the product.
-
Page 17: Cleaning Method
CLEANING METhOD Storage tank 1 . Unplug the power cord . Close the main water supply valve . 2 . Please drain and take the water inside of the water filtration device completely using the draining hose . P lease drain both the cold water and the room water using the same method. 3 . - Page 18 CLEANING METhOD 5 . Please wipe the surface of the storage tank with soft clothes . 6 . Use the storage tank after cleaning it with the taken water, draining completely using the draining hose, and emptying the newly room water one time or more .
-
Page 19: Gutter
Close the storage tank cover completely. A worm or a foreign body can be entered. Tips When you clean the storage tank, don’t use the medicine or the detergent. If you don’t clean the medicine or the detergent cleanly, it can be harmful to the body. - Keep the surroundings cleanly and clean the storage tank once per two months. Gutter 1 . Gutter separation method The gutter can be separated easily with lifting up the front part of the gutter and taking out. 2 . Gutter assembling method You just push the hook of the gutter slightly after sticking to the product. Available From: freshwatersystems .com serving you since 1989 CLICK HERE ®... -
Page 20: Filter Replacement
FILTER REPLACEMENT Filter The life of the water filtration system is the filter. It it isn’t the legitimated filter or you use too long even if it is the legitimated filter, the filter performance can be lowered. Please change to the legitimated filter according to the replacement cycle. Filter replacement cycle If the filter is not regularly replaced, it may degrade the water quality from the product. The filter replacement cycle depending on the main water quality can be shortened rater than the expected replacement cycle. The period for the filter exchange is made based on 10 L use in a day for house use(4 people based) and 20 L use for business. CP-07bLO Part No. Names of Filter Usable Period WJNF8-S Neo-sense filter 6 months WJMF8-20-S Ro membrane filter 20 months WJIF8 –S Inno-sense filter 18 months WJCC-02 Ceramic filter 12 months About filter replacement cycle... -
Page 21: Filter Replacement Method
FILTER REPLACEMENT METhOD 1 . Close the main water supply valve after unplugging the power cord, and drain the water inside of the water filtration device (See P .16) . 2 . Open the upper cover and separate the gutter in the front side . 3 . - Page 22 FILTER REPLACEMENT METhOD 4 . After releasing 2 fixed screw in the upper side of the product using the driver, pulling forward with grasping the upper side of the front cover . 5 . After separating the fitting connected to the filter trying to replace, please replace the filter .
-
Page 23: Troubleshooting
TROUBLEShOOTING The water filtration device may operate abnormally due to minor causes not because of the product malfunction but because of the fact that the user is not familiar with the product use. In such a case, problems can be solved easily even without the help from the Service Center by checking the following items. If you can’t solve the problem after checking the following items, please call the Service Center. Symptom Check Measures to take • Did you clean the storage tank? Clean the storage tank. The water tastes • You didn’t use the water filtration device Get rid of the saved water and clean the weird. for a long time. storage tank. • Isn’t it about time to change the filter? Request the filter replacement. • Is the water supply cut or isn’t the water Open the main water supply valve. The water doesn’t supply valve closed? come. • Did you miss the filter replacement times? Request the filter replacement. • Isn’t it about time to change the filter? Request the filter replacement. Check if the power cord plug in 120 V~ 60 • Is the power connected? Hz outlet. The water is • Didn’t you close the main water supply flowing slower. -
Page 24: Specification
SPECIFICATION Product Water Filtration Device CP-07BLO Model Filtration Method RO(Reverse Osmosis) Power Supply 120 V~ 60 Hz 5.3 L Room Water Tank 3.0 L Cold Water Capacity 8.3 L Total Dimension 320 mm(W) × 560 mm(D) × 500 mm(H) Working Temperature 5 °C - 35 °C Production Rate 76 L/d (25 °C, 138 kPa) Working Pressure 138 kPa – 827 kPa Net Weight 17.4 kg • The water amount can be differentiated according to the water pressure and the water temperature. • The water tank capacity is the amount by the size and can be different from the extraction capacity. • Without any prior notice, all or parts of the product are subject to change for the purpose of improving the performance of the product. • Refer to Performance data sheet for individual contaminants, reduction performance and... -
Page 25: Water Flow Diagram
WATER FLOW DIAGRAM CP-07bLO Available From: freshwatersystems .com serving you since 1989 CLICK HERE ®... -
Page 26: Performance Data Sheet
Water Filtration System Performance Data Sheet brand: Lyon II Model: CP-07bLO This system has been tested and certified by the Water Quality Association according to NSF/ANSI 42, 53, and 58 for the reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42, 53, and 58. Max. Allowable Average Average Minimum Average Substance Concentration Influent Effluent Percent Percent (mg/L) (mg/L) (mg/L) Reduction (%) Reduction (%) Arsenic (Pentavalant) 0.010 0.05 0.006 79.1 87.7 Barium 83.5 86.6... - Page 27 • For parts and service availability, please contact your local dealer or Coway. • This system is acceptable for treatment of influent concentrations of no more than 27 mg/L nitrate and 3 mg/L nitrite in combination measured as N and is certified for nitrate/nitrite reduction only for water supplies with a pressure of 2.8 kgf/cm (40 psi) or greater. • A nitrate/nitrite sampling kit should be used to monitor the nitrate/nitrite levels in your product drinking water at least every six months. Kits maybe purchased from your local dealer or Coway. • This system has been tested for the treatment of water containing pentavalent arsenic (also know as As(V), As(+5), or arsenate) at concentrations of 0.050 mg/L or less. This system reduces pentavalent arsenic, but may not remove other forms of arsenic. This system is to be used on water supplies containing a detectable free chlorine residual at the system inlet or on water supplies that have been demonstrated to contain only pentavalent arsenic. Treatment with chloramines (combined chlorine) is not sufficient to ensure complete conversion of trivalent arsenic to pentavalent arsenic. Please see the Arsenic Facts section of this Performance Data Sheet for further information. • Efficiency rating means the percentage of the influent water to the system that is available to the user as reverse osmosis treated water under operating conditions that approximate typical daily usage. • The product water should be tested every 6 months to ensure that the contaminants are being reduced effectively. Please contact your local dealer or Coway to initiate this service. • This reverse osmosis system contains a replaceable treatment components, critical for the effective reduction of total dissolved solids and that product water shall be tested periodically to verify that the system is performing properly. Replacement of reverse osmosis component should be with one of identical specifications, as defined by the manufacturer, to assure the same efficiency and contaminant reduction performance. • The estimated replacement time of filter, which is a consumable part, is not an indication of quality guarantee period, but it means the ideal time of filter replacement. Accordingly, the estimated time of filter replacement may be shortened in case it is used in an area of poor water quality. Model of Filter Type Usable period (months) COST US $ WJNF8-S NEO-SENSE FILTER 7.84...
- Page 28 1,1,2-trichloroethane 0.005 0.150 > 99 0.0005 trichloroethylene 0.005 0.180 > 99 0.0010 trihalomethanes (includes): chloroform (surrogate chemical) bromoform bromodichloromethane 0.015 0.080 0.300 chlorodibromomethane xylenes (total) 0.070 > 99 0.001 1. T hese harmonized values were agreed upon by representatives of USEPA and Health Canada for the purpose of evaluating products to the requirements of this Standard. 2. Influent challenge levels are average influent concentrations determined in surrogate qualification testing. 3. Maximum product water level was not observed but was set at the detection limit of the analysis. 4. Maximum product water level is set at a value determined in surrogate qualification testing. 5. C hemical reduction percent and maximum product water level calculated at chloroform 95% breakthrough point as determined in surrogate qualification testing. 6. T he surrogate test results for heptachlor epoxide demonstrated a 98% reduction. These data were used to calculate an upper occurrence concentration which would produce a maximum product water level at the MCL. Woongjin Coway.,Ltd. 658, Yugu-Ri, Yugu Eub, Gongju-Si, Choongchungnam-Do, Korea Tel.: 82-41-850-7879 Fax.: 82-41-841-7816...
- Page 29 State of California Department of Public Health Water Treatment Device Certificate Number 08 - 1934 Date Issued: September 11, 2008 Trademark/Model Designation Replacement Element(s) Woongjin Coway Co. LTD Lyon2 CP-07BL0 WJNF8-S WJMF8-20-S WJCC-02 WJIF8 anufacturer: Woongjin Coway Co LTD The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants: Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants None Arsenic Barium Cadmium Chromium (hexavalent) Chromium (trivalent) Lead Nitrate/Nitrite Radium 226/228 Selenium Organic Contaminants...
-
Page 30: Warranty Card
WARRANTY CARD OR WARRANTY LETTER ONE YEAR LIMITED WARRANTY WATER FIRTRATION DEVICE CP-07bLO (“PRODUCT”) Model: Serial Number: Customer Name: (“OWNER”) Date of Purchase: What This Warranty Covers: Limitations and Exclusions: Commencing with the date of purchase of the TO THE EXTENT PERMITTED BY APPLICABLE LAW, Product and continuing for a period of one year, COWAY DISCLAIMS ANY OTHER WARRANTY if manufacturing defects in the Product cause the EXPRESS OR IMPLIED, THAN THAT PROVIDED Product to not operate properly for its intended FOR HEREIN. THIS WARRANTY IS IN LIEU OF AND use, then subject to the exclusions, conditions, and EXCLUDES ALL OTHER WARRANTIES, GUARANTEES,... - Page 31 Warranty is conditioned upon the following : If the Product fails to operate for its intended purpose, then notify Coway or its a) The defect or damage is not caused Representative Agency within 48 hours or by or is the result of : abnormal use or within the next business day after discovery conditions; improper storage, unauthorized of any defect in the Product. The OWNER must modifications or repair; misuse, neglect, give written notice to COWAY no later than accident, alteration, improper installation or thirty (30) days after a defect is discovered or other acts that are not the fault of Coway or should by reasonable diligence have been the manufacturer of the product or that are discovered. Claims under this Warranty will not covered by the manufacturer’s warranty; require proof of purchase by the OWNER. b) The Product has not been altered, modified or repaired without prior written approval of COWAY; c) The OWNER has notified COWAY in writing of any failure of the Product covered by this Warranty within thirty (30) days following such failure; d) There has been no misuse, abuse or negligence with respect to the Product on the part of the OWNER. Add : WOONGJIN COWAY USA, INC. 695 SOUTH VERMONT, STE. 110(SOUTH TOWER) LOS ANGELES, CA 90005, USA Call center. : (213) 386-9900 / (213) 480-1600 Fax. : (213) 386-3990...
- Page 32 MADE IN KOREA Available From: freshwatersystems .com serving you since 1989 CLICK HERE ® 1208828...
