  • Page 1 CHP-671R/L Water Filtration Device • This product can not be used if the voltage is different from that mentioned in the rating plate. • For your safety and proper use of the product, please read this User’s Manual before use.
  • Page 2 FEATURES Cold and hot water stage indicator Front draining system It is convenient as it can drain the cold water / room water / hot water from the front side without moving the product when you open the front draining door. Fine carbon particle reduce At the last stage of the filtration, Plus Inno-sense filter is applied to reduce carbon particles that sometimes come from...

  • Page 3: Table Of Contents

    DEAR CUSTOMERS Coway Water Filtration Device Thank you for using Please read this Users’ Manual to use and maintain the product correctly. If you encounter a problem while using the product, you may solve the problem referring to the User’s Manual. As this manual contains the product warranty card, please keep it in a safe place.

  • Page 4: Safety Information

    • In the case the power cord is damaged, do not replace the cord yourself. Call Coway Service Center to have it replaced. • Do not install near a heating device. • When the water is coming inside of the product or there is a puddle on the product, call Service Center after closing the supplying valve and unplugging.
  • Page 5 • If our product produces a strange noise or odd smell, immediately unplug from the electrical outlet and call our Service Center. • Do not put the candle, a light for cigarette on the products. • Do not place any containers with water, medicine, food, small metallic objects, or any flammable material on the top of the product.

  • Page 6: Warning

    SAFETY INFORMATION Warning : If not observed, serious injury or property damage could occur. • If the electric outlet is wet, carefully unplug the unit and let the electric outlet completely dry before subsequent use. • Unplug the product before repair, inspection, or parts replacement.
  • Page 7 Caution : If not observed, minor physical injury or property damage may occur as a result . • The filtration device installation shall comply with applicable state and local regulations. • Use after closing the water tank cover completely inside of the product.

  • Page 8: Parts Name

    PARTS NAME Front Indicators Cold / Room water Changeover Faucet Hot water Faucet Cup-touch Lever Gutter Front Draining Door Front Cover...
  • Page 9 Rear Top Cover Rear Cover Power Cord Inlet(Orange) Outlet (Blue, CHP-671R/L)

  • Page 10: Water Filtration Process

    If you don’t use qualifying filter or if you use an old filter that has expired, the system performance may degrade. The 5-step water filtering system (CHP-671R/L) Step 1: PLUS-SEDIMENT FILTER This plus sediment filter has the functions to remove infusible particles from feed water and to protect membrane and pre-carbon filter from being plugged.
  • Page 11 INSTALLATION PRECAUTIONS The summary for the proper installation of the water filtration device 1. Close main water supply valve to separate the faucet. 2. Apply the teflon tape on the adaptor and fit it to the pipe. Do not turn the water pipe. 3.
  • Page 12 INSTALLATION PRECAUTIONS Please check before use! Only connect the power cord to the voltage rating that matches it on the rating plate. • After installing the product Get rid of the saved water above the full water in the inner water tank 2 times or more to use. •...
  • Page 13 INDICATION / OPERATION PART Indication part / Operation part 1 Hot water 2 Cold water temperature temperature indicator indicator 3 Hot water mode 4 Cold water indicator mode indicator Hot water mode Cold water selection button mode selection button 5 Water level indicator Hot water temperature indicator Cold water temperature indicator The indicator is turned on...
  • Page 14 INDICATION / OPERATION PART ■ T o use cold water mode Press the cold water mode selection button and check if the cold water mode indicator is turned on. If you want to turn off cold water mode, press the selection button for about 2 seconds.
  • Page 15 HOW TO USE To drink the cold water You can drink the cold water when you turn the jog shuttle to the right in cold water/room water changeover faucet and pushing the cup-touch lever. ▶ If the cold water doesn’t come from the water filtration device, check if the cold water mode indicator is turned on (See P.12).
  • Page 16 HOW TO USE To drink the room water You can drink the room water when you turn the jog shuttle to the left in cold water/room water changeover faucet and push the cup-touch lever. ▶...

  • Page 17: Installation

    INSTALLATION Follow the instruction for installation Main water supply valve voltage rating that matches it on the rating plate. Connect the orange color inlet tubing to the tap water supplying pipe. Connect the outlet tubing Inlet tubing (Orange) Outlet tubing(Blue)
  • Page 18 When the position is moved, connect the power cord when 30 minutes passes after installing. To maintain optimal product performance, consult a Coway engineer for the detailed installation methods. There may be some water remaining inside of the filter which was used to test the product during inspection process at the factory.

  • Page 19: Cleaning Method

    CLEANING METHOD Storage tank 1. Turn off by pressing cold water / hot water mode selection button in the front of the product for 3 seconds or more and unplug. Please lock the main water supply valve. 2. Please empty the water tank completely using the draining hose after pressing and letting down the front draining door.
  • Page 20 CLEANING METHOD 4. Wipe the surface of the storage tank with soft clothes. 5. Use the storage tank after cleaning it with the drained water, and empty the water tank using the draining hose. After cleaning, please close both tank and top cover, then empty the water tank ▶...

  • Page 21: Gutter

    Gutter 1. Gutter separation method After leaning the gutter forward and taking in from the product, Separate the gutter cover. 2. Gutter assembling method After assembling the gutter and the gutter cover, insert the assembled gutter into below the product. ▶...

  • Page 22: Filter Replacement

    Please replace filters at a specified replacement cycle. For replacement filters, please contact Coway authorized dealers and distributors.  Filter replacement cycle If the filter is not regularly replaced, it may degrade the water quality from the product.

  • Page 23: Filter Replacement Method

    FILTER REPLACEMENT METHOD 1. Close the main water supply valve after unplugging the power cord, and drain the water inside of the water filtration device (See P.18). ▶ 2. After separating the fitting connected to the filter to replace, please replace the filter.
  • Page 24 TROUBLESHOOTING The water filtration device may operate abnormally due to minor causes not because of the product malfunction but because of the fact that the user is not familiar with the product use. In such a case, problems can be solved easily even without the help from the Service Center by checking the following items.
  • Page 25 SPECIFICATION Product Water Filtration Device Model CHP-671R CHP-671L Filtration Method RO(Reverse Osmosis) Power Supply Refer to the rating plate. Room Water 11.5 L Cold Water Tank Capacity Hot Water 3.6 L Total 21.1 L Dimension 370 mm(W) × 490 mm(D) × 1 257 mm(H) Working Temperature 5 °C - 35 °C (41 °F - 95 °F)
  • Page 26 WATER FLOW DIAGRAM CHP-671R Feed-NOS Valve Booster Pump Over Heating Check Valve Check Valve Storage tank Hand Valve Cooling tank Feed Water Cool/Room Water Water Heating tank Reject Water supply Valve Reject Water Hot Water Cool/Room Drain Drain CHP-671L FEED-NOS...
  • Page 27 MEMO...
  • Page 28 MEMO...
  • Page 29 MEMO...
  • Page 30 INCLUDING ITS REPRESENTATIVES, TO MAKE ANY only to Product used for an application specified REPRESENTATION OR TO OFFER ANY WARRANTY, by COWAY for the Product and applied in strict CONDITION OR GUARANTY IN RESPECT OF THE accordance with COWAY published specifications PRODUCT OTHER THAN THIS WARRANTY.
  • Page 31 If the Product fails to operate for its accident, alteration, improper installation or intended purpose, then notify Coway or its other acts that are not the fault of Coway or Representative Agency within 48 hours or the manufacturer of the product or that are within the next business day after discovery not covered by the manufacturer’s warranty;...
  • Page 32 1224107 www.coway.com...
