Installation and Operation Manual
XX221-00-02
ViconNet VN-NVR Shadow with
Internal RAID
Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788
Tel: 631-952-2288 Fax: 631-951-2288 Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
www.vicon-security.com
Document Number: 8009-8221-00-02
Issued: 512
Product specifications subject to change without notice.
Copyright © 2012 Vicon Industries Inc. All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vicon VN-NVR Shadow XX221-00-02
Summary of Contents for Vicon VN-NVR Shadow XX221-00-02
- Page 1 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 3: Table Of Contents
Technical Information Vicon Standard Equipment Warranty Vicon, ViconNet, and their logos are registered trademarks of Vicon Industries Inc. Windows is a registered trademark of Microsoft Corporation. Other company and brand products and service names are trademarks or registered trademarks of their respective holders... -
Page 4: General
ViconNet VN-NVR Shadow Installation and Configuration Guide General This manual provides information for installing and setting up the ViconNet® VN-NVR Shadow with internal RAIDs. The NVR Shadow is a high-capacity Network Video Recorder that can simultaneously capture, view and store high-quality, high-resolution voice, video and data. -
Page 5: Hardware Installation
ViconNet VN-NVR Shadow Installation and Configuration Guide Hardware Installation This unit should only be installed by a qualified technician using common hand tools and approved materials in accordance with the National Electrical Code ANSI/NFPA 70, state and local wiring codes. These units meet requirements for an FCC Class A computing device and CE. -
Page 6: Unpacking And Inspection
ViconNet VN-NVR Shadow Installation and Configuration Guide Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to provide suitable delivery. Inspect the cartons upon delivery and, if damage is present, make detailed notes on the carrier’s bill. -
Page 7: Unit Components
ViconNet VN-NVR Shadow Installation and Configuration Guide Unit Components This section describes the VN-NVR front and rear panels. Front Panel Controls and Connections • Network LED Indicators: Blue LED used to display the network connection status (ON means unit on and OFF means unit off). •... - Page 8 ViconNet VN-NVR Shadow Installation and Configuration Guide Rear Panel Controls and Connections • Speaker Output: Mini phono-type connector used for audio output. • Power Receptacle: Used to connect the provided power cable. • Keyboard Port: connector used to connect a standard PC keyboard (included).
-
Page 9: Mounting
ViconNet VN-NVR Shadow Installation and Configuration Guide Mounting Rack The NVR Shadow was designed to be mounted in a standard 19-inch (483 mm) wide vertical rack. A rail kit is installed onto the NVR to connect it to the rack. Hardware and installation instructions on how to use this kit are provided with the rail kit. -
Page 10: Installing The Vn-Nvr
ViconNet VN-NVR Shadow Installation and Configuration Guide Installing the VN-NVR After the unit is mounted permanently, follow the steps in this section to install the hardware. • Step 1: Installing the Drives • Step 2: Connecting the Hardware • Step 3: Connecting the Power Supply Important Notes Do not apply power or plug-in the unit to any outlet until instructed to do so. - Page 11 ViconNet VN-NVR Shadow Installation and Configuration Guide Step 2: Connecting the Hardware This procedure describes the various hardware connections that must be performed in order to operate the system. 1. Perform the following connections: (refer to Rear Panel diagram). 1.1 Locate the keyboard on a flat surface near the unit. Connect the keyboard by inserting its connector into the correct port.
- Page 12 ViconNet VN-NVR Shadow Installation and Configuration Guide Step 2: Connecting the Power Supply To ensure that the unit is protected during a power failure and that no important data is lost, it must be connected to an uninterruptible power source (UPS) before use. To connect the UPS: 1.
-
Page 13: Operation
ViconNet VN-NVR Shadow Installation and Configuration Guide Operation Powering On the Unit To power on the system: With the unit set up as shown in Installation, press the front panel pushbutton Power Switch. Important Do not press any keyboard buttons at this time. When the unit completes booting, the Main Screen is displayed. -
Page 14: Using Viconnet
ViconNet VN-NVR Shadow Installation and Configuration Guide Using ViconNet The NVR Shadow is delivered with the ViconNet application preloaded. Accessing the Configuration Functions The configuration functions are performed via the System Settings window applicable to a selected site. The Shadow must first be registered before the storage database drives can be configured. - Page 15 ViconNet VN-NVR Shadow Installation and Configuration Guide 2. Select the VN-NVR Shadow site to configure and click . The System Settings window is displayed. Note The System Settings window has the following options: When the function is not supported, the associated button is disabled (grayed out).
-
Page 16: Registering Your Unit
ViconNet VN-NVR Shadow Installation and Configuration Guide Registering Your Unit The full functionality of the VN-NVR is available only after it is registered. Before the registration procedure is performed, it will function with limited "Viewer" functionality only. To register your unit: 1. -
Page 17: Connecting To The Network
ViconNet VN-NVR Shadow Installation and Configuration Guide 5. Enter the six license numbers generated from the registration process into the six License Number fields of the Registration window, and click The application automatically restarts in order to implement the new registration and enable the functionality of your purchased application. Connecting to the Network Next the VN-NVR Shadow has to be added to the network. -
Page 18: Setting Up The Storage Database
ViconNet VN-NVR Shadow Installation and Configuration Guide 4. In the Nucleus Settings area, deselect the This Site is the Master Nucleus checkbox. 5. In the Nucleus Settings area, select the Nucleus IP radio button and enter the IP address. 6. Click . - Page 19 ViconNet VN-NVR Shadow Installation and Configuration Guide number displayed in the Maximum available size field. Click Apply. As a drive is configured, it is added to the list at top. Repeat until all the drives are configured. 4. Delete the storage drive listed as the “C” drive from the Video-Audio Storage list.
- Page 20 ViconNet VN-NVR Shadow Installation and Configuration Guide 6. After the storage database changes are saved, the system will reboot. The following message displays. 7. After reboot the following screen might display. This is normal and just let the restart continue. 8.
-
Page 21: Monitoring The Raid System
ViconNet VN-NVR Shadow Installation and Configuration Guide Monitoring the RAID System The hard drives are run by an internal RAID controller that handles the entire hot-swappable drives array. This controller can be monitored. 1. From the desktop, double click the icon. - Page 22 ViconNet VN-NVR Shadow Installation and Configuration Guide Click Connect. The Login screen will display. The default Login is User Name administrator with no password. From Login Mode, select Full Access or View Only. Note: The login name and password corresponds to the Windows® Login on the unit;...
-
Page 23: Replacing A Bad Database Drive
ViconNet VN-NVR Shadow Installation and Configuration Guide The list of drives is displayed on the left. There is no further need for any action at this time. A red mark ( ) next to any of the drives indicates that the drive has failed. - Page 24 ViconNet VN-NVR Shadow Installation and Configuration Guide 3. The failed drive will be indicated in the drive list by a red mark and have the indication (Foreign) next to the drive name. 4. The beep can be turned off by right clicking the Intel RAID Controller at the top left side of the screen and selecting Silence Alarm.
- Page 25 ViconNet VN-NVR Shadow Installation and Configuration Guide 6. Once the drive has been physically located, press the button to release the drive arm (handle) and remove it from the bay. Insert a new drive. 7. The “Rebuilding” process begins. The drive icon next the drive that is rebuilding will look different.
-
Page 26: Replacing The Os Hard Drive
ViconNet VN-NVR Shadow Installation and Configuration Guide Replacing the OS Hard Drive If there is a problem with the OS hard drive, contact Vicon Technical Support, 1-800-34-VICON (1-800-348-4266). After Vicon has verified that the OS hard drive needs to be replaced, a replacement drive and all necessary software will be sent. - Page 27 ViconNet VN-NVR Shadow Installation and Configuration Guide 7. Click Yes to restart the unit. 8. When the NVR restarts, from the desktop, double click the icon. The Intel RAID Web Console 2 will load. Click Connect. The Login screen will display. Login as described previously in this document.
- Page 28 ViconNet VN-NVR Shadow Installation and Configuration Guide 5. The Web Console screen will display. Verify that all the hard drives are displayed and there are no failures. Defining a Name 1. Right click on Start and choose the “Explore” option. 2.
- Page 29 ViconNet VN-NVR Shadow Installation and Configuration Guide 5. Make sure that the green shield with the check mark is selected On for the Windows Firewall. Click OK. 6. Left click the “General” tab. 7. Scroll down the menu and double click on “Internet Protocol (TCP/IP).” 8.
-
Page 30: Shipping Instructions
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. Vicon Industries Inc. 89 Arkay Drive Hauppauge, NY 11788 Phone: 631-952-2288; Toll-Free: 1-800-645-9116; Fax: 631-951-2288 For service or returns from countries in Europe, contact: Vicon Europe Ltd. -
Page 31: Technical Information
ViconNet VN-NVR Shadow Installation and Configuration Guide Technical Information Electrical Characteristics Input Voltage 105 - 240 VAC ±10%, 50/60 Hz nominal. NOTE: Vicon requires the use of uninterruptible power supply systems (UPS) to prevent voltage fluctuations that can affect operation and cause damage to the equipment. - Page 32 ViconNet VN-NVR Shadow Installation and Configuration Guide Mechanical Characteristics Application Indoor Mounting Standard 19 in. (483 mm) rack mount and stackable, 2 RU height Dimensions Height (H): 3.5 in. (89 mm) Width (W): 19.0 in. (483 mm) with racking ears; 17.5 in.
-
Page 33: Vicon Standard Equipment Warranty
Vicon Standard Equipment Warranty Vicon Industries Inc. (the “Company”) warrants your equipment to be free from defects in material and workmanship under Normal Use from the date of original retail purchase for a period of three years, with the following exceptions: VCRs, all models: Labor and video heads warranted for 120 days from date of original retail purchase. - Page 34 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-2288 800-645-9116 Fax: 631-951-2288 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Vicon Germany Kornstieg 3 D-24537 Neumuenster...
