DB-9 Pin Configuration For Port 1
Pin Use
1 DCD
2 RX
3 TX
RS232 Port 2
For Event Generation and ASCII Text Insertion.
RJ-45 Pin Configuration For RS232 Port 2
Pin Use
1 Ground
2 Reserved
3 Not Connected
4 RXD

1.8 Power-Up

Use the diagram below to secure the power cord to the back panel.
It is important that the power-up procedures be followed carefully. The unit uses its auto-detect
feature to detect camera signals during power-up, and configure itself automatically.
0150-0239D
Pin Use
4 DTR
5 Ground
6 Not Connected
Pin
5
6
7
8
1 Slide approximately 6 inches of the power cord through the pre-installed
cable tie (approximately 1 inch after the ferrite core).
1
2
2
Tighten the cable tie until the cord is secure. Do not over tighten.
3
Loop the power cord end around and insert into the power receptacle on
the back panel.
3
15
Pin Use
7 RTS
8 CTS
9 Not Connected
Use
TXD
Not Connected
Ground
Reserved
GE Security DVMRe Simplex
1
6 9
DB-9 on back panel.
1 2 3 4 5 6 7 8
RJ-45 socket on
back panel.
5
