Conditional Indicators
Condition
Alarm
Autolist™ Program
mode
Freeze
Macro Record mode
Motion Detection
Videoloss
Zoom
Status Display Box
A Status Display Box can be viewed by pressing the Camera Number button twice. Status Indicators
include:
On Live Fullscreen:
Archive Status: Not Connected, Not Ready, Ready, Ejecting, Play, and timeleft. Timeleft
indicates the amount of time before the archive medium is full (Only available if the unit has
Background Archiving turned On).
Network: Displays all current Network connections. Normal connection is displayed as ip.ip or ---
if there is no connection. Live connections are displayed as E1: ip.ip, E2: ip.ip, etc. (where ip.ip
represents the last 2 bytes of the IP Address). POTS connection is displayed as IP 1.1.
On Playback Fullscreen:
All the above, including Image Quality Setting: High, Medium, Standard.
ATM/POS Text Display
Pressing the Camera Number a third time displays an ATM/POS text display. This feature can be
used during live viewing mode to verify that the DVMRe Simplex is receiving ATM/POS text, or in
Playback mode to review recorded text and video.

2.10 The Print Image Feature

Pressing the Function and Zoom button will print the currently displayed
image. If any multiscreen is the display mode, the Simplex will switch to a
single image display of the last selected fullscreen camera, freeze the image,
and send to the default printer.
Printer Setup
The following equipment and conditions are required for the operation of the Print Image feature.
Equipment
HP DeskJet 3820
Hawking Print Server PN7127P
Conditions
The Printer and Print Server must be connected to the same local network as the Simplex.
0150-0239D
Full Screen Indicator
ALM
PGM
FRZ
F followed by macro number
M
VDL
ZOOM
25
Multiscreen Indicator
A in cameo of camera in alarm
PGM
(Asterisk) in frozen cameo
*
F followed by macro number
M in cameo w/ motion detection
V in cameo with videoloss
ZOOM
Zoom and Function
GE Security DVMRe Simplex
{F}
Button
