TROUBLESHOOTING

If there is no sound from any
of the speakers:
• Check that the receiver/
amplifier is on and a source
is playing.
• Review proper operation of
your receiver/amplifier.
If there is no sound
coming from one speaker:
• Check the 'Balance' control
on your receiver/amplifier.
• Check all wires and connec-
tions between receiver/
amplifier and speakers.

SPECIFICATIONS

Drivers Bass/midrange (video shielded)
Drivers Tweeter (video shielded)
Frequency Response
Power Handling (Peak/Continuous)
Maximum Recommended Amplifier Power*
Sensitivity
Nominal Impedance
Dimensions (H x W x D)
Weight (each)
*The maximum recommended amplifier power
rating will ensure proper system headroom to
allow for occasional peaks. We do not recomm
end sustained operation at these maximum power
levels.
Descriptions and specifications subject to change
without notice.
Notice to Purchaser: JBL assumes no responsibility
or liability for injuries or property damage – direct,
indirect or consequential – resulting from the
improper installations of Control ONE loudspeakers.
• Make sure all wires are con-
nected. Make sure none of
the speaker wires are frayed,
cut or punctured.
If the system plays at low vol-
umes but shuts off as volume
is increased:
• Check all wires and connec-
tions between receiver/
amplifier and speakers.
• Make sure all wires are con-
nected. Make sure none of
the speaker wires are frayed,
cut or punctured.
100mm
12mm Titanium Laminate
80Hz – 20kHz
200W/50W
100W RMS
89dB/2.83V/1m
8 Ohms
228 x 155 x 139mm
2.4kg
• If more than one pair of
speakers is being used,
check the minimum
impedance requirements of
your receiver/amplifier.
If there is no (or low) bass
output:
• Make sure the polarities
(+ and -) of the left and right
'Speaker Inputs' are
connected properly.
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château-du-Loir
France
declare in own responsibility, that the
product described in this owner's manual is
in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Laurent Rault
Harman Consumer Group, Inc.
Chateau-du-Loir, France 08/07
