GSW 520H Installation Manual And Owner's Manual

Direct vent indoor models on-demand condensing water heater
Table of Contents

Advertisement

Quick Links

520H Direct Vent Indoor Models
On-Demand Condensing Water Heater
Installation Manual and Owner's Guide
Gas Tankless Water Heater
520H Direct Vent Indoor Models
Suitable for potable water heating and space-heating*
* Please refer to local codes for space-heating compliance.
FEATURING
• ENDLESS HOT WATER
• ON-DEMAND USAGE
• COMPACT, SPACE SAVING
• ENERGY CONSERVATION
• COMPUTERIZED SAFETY
• NO PILOT LIGHT
• EASY-LINK SYSTEM
520H model
only
This product must be installed
and serviced by a licensed
plumber, a licensed gas fitter,
or a professional service tech-
nician. Improper installation
and/or operation, or installation
WARNING
by an unqualified person, will
void the warranty
- Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch, do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
• If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
If the information in these
instructions is not followed
exactly, a fire or explosion may
result causing property dam-
age, personal injury or death.
WARNING
If you have any questions,
please call or write to:
GSW Water Heating
599 Hill Street West
Fergus, ON Canada N1M 2X1
Toll Free: 1-888-479-8324
320577-000
REV. 00 (10-12)
