Summary of Contents for Kodak i700 Series

  • Page 2 Simply put, there’s nothing but performance and precision under the hood of the i700 Series Scanners. • Kodak i730 Scanner is a desktop duplex color scanner with an automatic document feeder that runs at 90 pages per minute which includes an enhanced printer. •...
  • Page 3 Outstanding document feeding — Kodak’s renowned feeder technology is designed into the scanner. • Exclusive SurePath paper handling — the i700 Series Scanners are virtually jam-free and damage-free because it’s designed for smooth paper transport from input to output. •...
  • Page 4 What’s in the box? • Kodak i700 Series Scanner • Output tray • Short document tray • Ink cartridge and blotter strips • Tires and Pre-separation pads • Cleaning supplies • FireWire (IEEE-1394) package (card and cable) • Calibration targets •...
  • Page 5 Physical dimensions Height: 40.6 cm / 16 in. Width: 60.9 cm / 24 in. Length: 76.2 cm / 30 in. Weight: 38.6 kg / 85 lbs Environmental conditions Operating Temperature: 10°C to 35°C (50° to 95°F) Humidity: 10 to 85% Environmental Factors: Energy Star qualified scanners Heat Load:...
  • Page 6 Scanner components Front view Elevator tray extender — opens the elevator tray extender to accommodate long documents. Feed module — provides smooth document feeding of various sizes, thicknesses and textures. Elevator tray side guides — slide the guides independently in or out to accommodate the document size you want to scan.
  • Page 7 Stop/Pause and Start/Resume buttons: • Stop/Pause button: (white with red triangle) press to temporarily stop scanning. • Start/Resume button: (green) press to start scanning. POD release latch — push up the POD release latch when you need to access the inside of the scanner.
  • Page 8 Inside view Sensors — the scanner has 3 (ultrasonic) multi-feed detection sensors, 1 (optical) paper path sensor and 1 (optical) paper present sensor. These sensors detect the presence of documents in the elevator tray and documents in the paper path during feeding and imaging. Pre-separation pad —...
  • Page 9 130,000 pages per day. SCANNER FEATURES Easy to use, meets ergonomic design standards We’ve made the i700 Series Scanners easy to operate and tough to beat: • 500-sheet elevator tray for easy paper feeding which can be pre-set to accommodate different batch sizes (settings include: 500, 250, 100 and 25 or less).
  • Page 10 Paper handling and feeding The input tray and automatic document feeder of the i700 Series Scanners are designed to stack and feed up to 500 sheets of 75 g/m (20 lb.) bond paper reliably across the specified range of document sizes.
  • Page 11 Response Center at Kodak for further analysis. Optics The design heritage of the M-type Kodak lens used in the i700 Series Scanners comes from a high-resolution production scanner developed for complex character scanning. The lens also incorporates an infrared filter with its lead-free multiple elements. This reduces light loss and eliminates alignment of the infrared filter to the lens.
  • Page 12 Enhanced Printer The Enhanced Printer provides a vertical print capability and supports alphanumeric characters, date, time, sequential document number and custom messages. The Enhanced Printer is unique in that the document print string can be configured to include both static information (i.e., information that stays the same for each document, such as scan station or operator) and dynamic information (i.e., information that may change for each page scanned, such as time or sequential document number).
  • Page 13 The Kodak Feeder Consumables Kit has an estimated life of 1,750,000 pages of non-abrasive, A4 or letter-sized, 75 g/m or 20 lb. bond paper. For more information regarding consumables and supplies, refer to the Supplies and Consumables catalog, A-61403.
  • Page 14 • No volume-based click charges or other costly add-ons Integration For the most up-to-date listing of completed integrations, go to the Kodak web site at www.kodak.com/go/ScannerISVs. IEEE-1394 (FireWire) Interface Reduce setup and installation time with plug-and-play simplicity. The IEEE-1394 (FireWire) card and cable are shipped with the scanner.

  • Page 15: Table Of Contents

    Advanced image processing capabilities have long been the hallmark of Kodak’s document image scanners. The i700 Series Scanners advance image processing to a new level, taking all the best and adding more. Full-speed image processing in color, grayscale and black and white arenas in a scanner of this capability offers an unparalleled opportunity for today’s demanding...

  • Page 16: Auto Color Detection

    Auto Color Detection Based on the color content of a document, this new feature will make it easier for customers to capture color/grayscale only when they require it, reducing document prep time, storage requirements and eliminating the need for patch sheets. If you choose to use this option, the scanner will be automatically triggered to change from the current image stream (black and white) to the alternative image stream (color/grayscale) based on the values set in Color Content, Color Amount and Color Threshold.

  • Page 17: Cropping Options

    The i700 Series Scanners can pick up the area with the bar code as a black and white image and deliver the rest of the image in full color (high or low resolution depending upon the needs of the application).

  • Page 18: Deskew

    (through OCR or ICR technology) read pertinent data without interference from the lines and boxes of the form. The i700 Series Scanners can drop out either red, green or blue. The dropout color selection (R, G, B) is changeable at the host. The scanner does more than just drop out the color.

  • Page 19: Noise Filter

    Noise in the scanned image appears as random specks. These specks may be caused by actual noise in the original (i.e., dirt, toner specs on photo copies or mottled colors). The i700 Series Scanners give you the option to keep intermittent pixels or remove them. Turning on Noise Filter results in cleaner images and images that are compressed better.

  • Page 20: Polarity

    Simultaneous Output of Color/Grayscale and Black and White Images The i700 Series Scanners can output color, grayscale, or black and white images; grayscale and black and white images; or color and black and white images without further processing required by the host (some color scanners create this type of output by having the color image converted at the host).
  • Page 21 The Kodak i700 Series Scanners are targeted at departments or organizations that need to automatically extract data from a wide variety of structured and unstructured forms. Structured Forms: • New customer applications • Customer orders and billing • Customer update or response forms •...
  • Page 22 • Robust paper handling and flexible misfeed management: designed with busy production operations in mind, the i700 Series Scanners are designed to meet real world needs, including mixed batches, imperfect document prep and heavy workloads. •...
  • Page 23 (through OCR or ICR technology) read pertinent data without interference from the lines and boxes of the form. The i700 Series Scanners can drop out either red, green or blue. The dropout color selection (R, G, B) is changeable at the host.
  • Page 24 From the industry leader in digital innovation and the world leader in imaging, the i700 Series Scanners truly redefine the “mid-volume production” document scanner category. Competitive offerings are hard pressed to beat Kodak’s winning combination of price, features, and performance offered with the i700 Series Scanners.
  • Page 25 This section compares the Kodak i700 Series Scanners with the major competition in the mid- volume production scanner segment. We hope you find the comparisons useful. The information that follows was gathered through sell sheet materials supplied (physically or via the Internet) by the manufacturer.
  • Page 26 Paper Types: Bond, Laser, Inkjet, Offset Paper Weights: The elevator tray handles a broad range of paper weights from 45 to 200 g/m (12 to 110 lb.). The Kodak Feeder Kit for Ultra Lightweight Paper can handle paper weights from 25 to 75 g/m (7 to 20 lb.).
  • Page 27 Kodak i700 Series Scanners vs. BB&H Spectrum Scanners • The list price of the Kodak i780 Scanner is 15% less than that of BB&H’s top Spectrum model. • The Kodak i780 Scanner offers superb image processing utilizing Kodak’s proprietary Perfect Page image quality algorithm, providing an array of image quality capabilities including: −...
  • Page 28 The Kodak i700 series scanners are more productive when real world, challenge document sets are required for scanning. In side by side testing, the Kodak i780 outperformed the DR X10C in both Multifeed Productivity testing and Challenge Document productivity testing, by as much as 50% in PPM ratings.
  • Page 29 • The Kodak i780 Scanner can scan longer documents (up to 34 inches / 864 mm) at rated speed. The Fujitsu scanner cannot handle longer documents, supporting only documents up to 17 inches / 432 mm.
  • Page 30 Color: demonstrates a 55% reduction in speed for simplex, and a 66% reduction in speed for duplex. • The Kodak i700 Series Scanners can scan longer documents (up to 34 inches / 864 mm) at rated speed. The Panasonic scanner does not offer this capability. •...
  • Page 31 Scanners are designed to meet real-world needs with speed, flexibility and reliability. • The speed of the Kodak i700 Series Scanners will not slow down when key features are enabled. For example, the product provides auto orientation/auto rotation and dual stream output at rated speed, a broad array of critical image quality capabilities including deskew and color dropout, and even manages mixed batch documents, all at rated speed.
  • Page 32 This shows up in the productivity and reliability of the customers’ equipment, as well as in the quality of the results produced. Kodak Service & Support is committed to increasing the customers’ total satisfaction with the performance of Kodak equipment.
  • Page 33 1-800-525-6325, prompt 2. Installation Services Installation of an i700 Series Scanner is not included in the price of the equipment. The reseller or the end user can accomplish installation by following the installation instructions in the User’s Guide.
  • Page 34 Kodak Extra-Extra-Large Feeder Consumables Kit for i600/i700/i1800 Series Scanners 134 3680 Kodak Imaging Guide Set for i600/i700/i1800 Series Scanners 197 6703 Kodak Printer Ink Blotters, Front Side for i600/i700 Series Scanners 840 5425 Kodak Enhanced Printer Ink Cartridge Carrier 113 3842...
  • Page 35 The long-life xenon lamps were designed to last the life of the scanner. If the lamps need to be replaced, a Kodak Field Engineer will replace them at no extra cost (per the Kodak Service Agreement). What is the warm-up time for an i700 Series Scanner when it is in standby mode with lamps off? •...
  • Page 36 Imaging guides Can I add Kodak PerformancePlus to the an i700 Series Scanner? Service for the i700 Series Scanners is covered by the Kodak PerformancePlus program. It will allow customers to upgrade their cover at highly competitive pricesNo. PerformancePlus is not available in selected markets only.
  • Page 37 What host adapter does Kodak ship with the scanner? Koutech 1582T. Do I need to purchase a FireWire card and cable? No. Kodak supplies both a FireWire card and cable in the box with the scanner (see the “What’s in the Box” section). Why would someone buy FireWire? It is a proven, reliable standard for data-intensive, high-speed transmission and it is one of the fastest peripheral standards ever developed, at a price that’s affordable to consumers.
  • Page 38 10 Mbps 80 Mbps 12 Mbps 480 Mbps (50 Mbps) (Practical: 2.5) (Practical: 5) (Practical: 20) (1.5 Mbps) (60 Mbps) (Practical: 25) (Practical: unknown) Kodak Scanner i200/i700 55XX/75XX/95XX i50/i60 i800 Series Scanners Scanners 1500/2500 Compatibility Kodak 35XX/4500 Professional 7520/9520 Digital...
  • Page 39 Product Comparison – Kodak i700 Series Scanners with the Competition Kodak i700 Series Kodak i600 Series Kodak i1800 Series Böwe Bell & Howell Canon Canon Fujitsu InoTec Panasonic Panasonic Scanner Scanner Scanner Spectrum XF Series: imageFORMULA imageFORMULA fi-5900C KV-S4085 KV-S3105C...
