SPEAKER SPECIFICATIONS

Speaker Type:
Woofers:
Tweeter:
Impedance:
Sensitivity:
Contour Switches:
Frequency Response:
Power Handling:
Dimensions (H x W x D):
Wall Cut Out (H x W):
Features and specifications are subject to change without notice.
LIMITED TEN-YEAR WARRANTY
Proficient Audio Systems warrants to the original retail purchaser
only that this product will be free from defects in materials and
workmanship for a period of ten years, provided the speaker was
purchased from a Proficient Audio Systems Authorized Dealer.
Defective products must be shipped, prepaid and insured, together
with proof of purchase, to the Proficient Audio Systems Authorized
Dealer from whom they were purchased, or to Proficient Audio
Systems at the address listed on this installation instruction manual.
Freight collect shipments will be refused. It is preferable to ship this
product in the original shipping container to lessen the chance of
transit damage. In any case, the risk of loss or damage in transit is to
be borne by the purchaser.
If, upon examination at the Factory or Proficient Audio Systems
Authorized Dealer, it is determined that the unit was defective in
materials or workmanship at any time during this warranty period,
Proficient Audio Systems or the Proficient Audio Systems Authorized
Dealer will, at its option, repair or replace this product at no additional
charge, except as set forth below. If this model is no longer available
and can not be repaired effectively, Proficient Audio Systems, at its
sole option, may replace the unit with a current model of equal or
greater value. In some cases where a new model is substituted, a
modification to the mounting surface may be required. If mounting
surface modification is required, Proficient Audio Systems assumes no
responsibility or liability for such modification. All replaced parts and
product become the property of Proficient Audio Systems. Products
replaced or repaired under this Warranty will be returned to the origi-
nal retail purchaser, within a reasonable time, freight prepaid.
For technical inquiries please call 800.448.0976 or email us at techsupport@proficientaudio.com. We are available to assist you
every weekday, except holidays, between the hours of 7:00 a.m. and 5:00 p.m. PST.
IW525
2-Way In-Wall LCR
Two 5¼" Graphite Cones
with Butyl Rubber Surrounds
Pivoting 1" Aluminum Dome
8 Ω
88dB 1W/1m
Front-Mounted 3-Position
±3dB Bass & Treble Switches
45Hz - 20kHz
100 watts
8" x 1515⁄16" x 37 ⁄ 16"
63⁄16" x 14½"
Audio Systems
940 Columbia Avenue, Riverside, CA 92507
800.448.0976 • Fax 951.787.8747 • proficientaudio.com
IW550
2-Way In-Wall LCR
Two 5¼" Kevlar
®
with Butyl Rubber Surrounds
Pivoting 1" Aluminum Dome
8 Ω
88dB 1W/1m
Front-Mounted 3-Position
±3dB Bass & Treble Switches
40Hz - 20kHz
125 watts
8" x 1515⁄16" x 37 ⁄ 16"
63⁄16" x 14½"
This Warranty does not include service or parts to repair damage
caused by accident, disaster, misuse, abuse, negligence, inadequate
packing or shipping procedures, commercial use, voltage inputs in
excess of the rated maximum of the unit, or service, repair or modi-
fication of the product which has not been authorized or approved
by Proficient Audio Systems. This Warranty also excludes normal
cosmetic deterioration caused by environmental conditions. This
warranty will be void if the Serial Number on the product has been
removed, tampered with or defaced.
This Warranty is in lieu of all other expressed warranties. If the prod-
uct is defective in materials or workmanship as warranted above, the
purchaser's sole remedy shall be repair or replacement as provided
above. In no event will Proficient Audio Systems be liable for any inci-
dental or consequential damages arising out of the use or inability
to use the product, even if Proficient Audio Systems. or a Proficient
Audio Systems Authorized Dealer has been advised of the possibility
of such damages, or for any claim by any other party. Some states do
not allow the exclusion or limitation of consequential damages, so
the above limitation and exclusion may not apply.
All implied warranties on the product are limited to the duration of
this expressed Warranty. Some states do not allow limitation on the
length of an implied warranty. If the original retail purchaser resides in
such a state, this limitation does not apply.
Cones
1301-22000 (rev1)
