• Built-In Direct Vent Fireplace
• Natural Gas or Propane
• Residential or Mobile Home
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency, or the gas supplier.
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
-
Installation must be performed by a qualified installer, service agency or the gas supplier
IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
36 DV XL Owner's Manual
Installer: After installation give this manual to the home-
owner and explain operation of this fireplace.
$10.00
Copyright 2003, T.I.
Part # 93508128
4030228
Featuring the
Burner
Tested and Listed by
Omni-Test Laboratories, Inc.
Beaverton, Oregon
Report # 028-S-20b-1
ANSI Z21.88, CSA 2.33 MR 8,
CAN/CGA 2.17-M91
10850 117th Place N.E. Kirkland, WA 98033
TM
