This manual contains important safety instructions for the gasoline engine powered
READ SAFETY WARNINGS AND OPERATING INSTRUCTIONS CAREFULLY.
When you call the help-line you will need to have the following information:
Date of Purchase:
Location of Purchase:
Serial # - Mower:
Serial # - Engine:
Serial # - Hydro Trans (L) _______________________
Serial # - Hydro Trans (R) _______________________
M
Owner's Manual
OWER
lawnmower models: 36FS, 54FS, 36FDS
SAVE THIS MANUAL.
Need Help?
Parts, Service
and Technical Assistance call:
1-919-550-3259
www.mower911.com
_______________________
_______________________
_______________________
_______________________
Mower and engine life are
extended greatly by performing
frequent lubrications, oil changes
and regular maintenance. To
protect your investment perform
routine maintenance.
