Grizzly H6138 Instruction Sheet

Always wear safety glasses
during
serious personal injury!
Always disconnect tool from
air to prevent unexpected
operation during service!
Introduction
⁄ " drive accepts all
1 1
2
ets. Features pistol grip with trigger switch, for-
ward and reverse switch, 4 clutch settings, rubber
bumpers for protection against normal garage use
and a ⁄ " NPT male quick connect fitting. Sockets
1
4
not included
.
Inventory
A. Air Impact Wrench ...................................... 1
B.
⁄ " NPT Quick Connect Fitting (male) ........ 1
1
4
Operation
Tool requires 90 PSI to operate correctly.
To improve tool lifespan, use a filter/lubricator/
regulator as shown in Figure 2. Otherwise, lubri-
cate daily with a couple drops of pneumatic tool oil
directly into the air fitting as shown in Figure 3.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
EYE INJURY HAZARD!
use to prevent
INJURY HAZARD!
EXPLOSION HAZARD!
Never exceed 120 PSI!
⁄ " standard and metric sock-
2
COPYRIGHT © FEBRUARY, 2006 BY GRIZZLY INDUSTRIAL, INC.
#PC8007 PRINTED IN CHINA
MODEL H6138
⁄ " AIR IMPACT
1
2
WRENCH
INSTRUCTION SHEET
Figure 1. Model H6138.
Quick
Quick
Connector
Connector
Your
Tool
Quick
Coupler
Air Hose
Figure 2. Installing your tool.
Figure 3. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
Lubricator
Regulator
Air
Compressor
Quick
Filter
Coupler
