Tripp Lite PDUMV30NET Specification Sheet

Model Number: PDUMV30NET
Single-Phase Switched PDU, 2.9kW 30A 120V, 0U Vertical Rackmount, 24 NEMA 5-15/20R outlets, NEMA
L5-30P input plug
Description
Tripp Lite Switched PDU / Power Distribution Unit offers advanced network control and monitoring with the ability to turn on, turn off, recycle or
lock-out power to each individual receptacle, monitor site electrical conditions and remotely monitor output power consumption. PowerAlert interface
supports remote control and custom notification of user-specified conditions via email, secure web, SNMP, Telnet or SSH interface. Individually
switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined
power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network
equipment is first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output
current consumption in amps is displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before
critical IT mains or branch breakers trip.
Applications
Ideal for network configurations requiring a switched, metered and monitored PDU supporting individual outlet rebooting, load shedding
and remote web/network current monitoring of critical networking components
Package Includes
Rackmount PDU
Rackmount brackets
Owner's manual
PDUMVROTATEBRKT mounting accessory
Features
120V Switched PDU with built-in web/network interface in 0U 70 inch / 178cm vertical rackmount form factor; 30A maximum capacity
(agency de-rated to 24 amps)
10 ft. / 3m cable with L5-30P input plug
24 switched NEMA 5-15/20R outlets
Supports power-on, power-off or reboot of each outlet on a real-time or programmable basis
Enables reboot of locked equipment, custom power-on/power-off sequences, load-shedding of optional loads and disabling unused outlets
Network interface provides PDU control and data regarding input voltage, frequency and loading information
Digital display reports load level information in amps in 3 segments (bank 1, bank 2 and total)
Display also supports IP-address self-identification and electronic 180 degree display rotation
Supports user-specified alarm notification thresholds
In-rack environmental reporting with optional ENVIROSENSE temperature / humidity sensor and rack access notification with up to 4
optional SRSWITCH door sensors
Highlights
Switched 30A 120V PDU; 70in / 178cm 0U Vertical Rackmount
Reports voltage, frequency & loading information via ethernet interface
Visual current meter; Toolless button mount installation
10 ft / 3m input cord with L5-30P input plug
24 switched NEMA 5-15/20R outlets; Cord retention brackets
Temperature, humidity and contact-closure monitoring options
