- Page 1 PLMS30 PLM3 LAVALIER MICROPHONES USER MANUAL PYLE AUDIO INC. http://www.pyleaudio.com sales@pyleaudio.com...
- Page 2 General PYLE PLMS30/PLM3 lavalier microphone is an ideal choice for stage performances as it sets you freefrom holding a microphone and lets you be totally yourself on the stage. With a small and light tie-clip you can enjoy the sound quality similar to the...
- Page 3 Model................PLMS30/PLM3 Element................Back Electret Condenser Polar Pattern...............Uni-directional Frequency Response............50Hz- 16KHz Sensitivity..............-45dB± 3dB Output Impedance............2000Ω± 30% Max.Input SPL.............130dB S/N Ratio..............>70dB Power Supply..............1.5V-10V Cable................Φ2*1.0M Dimension..............Φ12mm Color................Black Connector..........(PLMS30)SHURE type 4pin mini XLR (PLM3)Standard 3.5mm plug+1/4'’Atapter Accessories..............Windscreen,Tie-Clip Figure 1: Polar pattern Figure 2: Frequency response...
- Page 4 PYLE AUDIO INC. Address: 1600 63rd.Street Brooklyn N.Y. 11204,USA Tel: 718-535-1800, 1-888-318-PYLE Fax: 718-236-2400 URL: http://www.pyleaudio.com E-mail: sales@pyleaudio.com 2012-PYLEAUDIO-PLMS30-PLM3-A0001...
